'06Camry_U (L/O 0507)
OPERATION OF INSTRUMENTS AND
CONTROLS
Air conditioning system
Manual air conditioning system
Controls
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air flow selector settings
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic air conditioning system
Controls
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air flow selector settings
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating tips
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side and rear vents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air conditioning filter
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2006 CAMRY from July '05 Prod. (OM33708U)
1
9
SECTION
−
178
181
181
184
188
188
191
192
177
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toyota ’06Camry_U
Summary of Contents for Toyota ’06Camry_U
-
Page 1: Operation Of Instruments And
’06Camry_U (L/O 0507) SECTION − OPERATION OF INSTRUMENTS AND CONTROLS Air conditioning system Manual air conditioning system Controls ..........Air flow selector settings . -
Page 2: Manual Air Conditioning System Controls
’06Camry_U (L/O 0507) Manual air conditioning system— —Controls 1. Fan speed selector 2. Temperature selector 3. Air flow selector 4. “A/C” button 5. Air intake selector 2006 CAMRY from July ‘05 Prod. (OM33708U) - Page 3 ’06Camry_U (L/O 0507) Fan speed selector If you want to return the setting to RECIRCULATE mode, press the air in- Turn the knob to adjust the fan speed—to take selector button once again. the right to increase, to the left to de- crease.
- Page 4 If this happens, take your ve- hicle to a Toyota dealer for service. Air intake selector Press the button to select the air source. 1. RECIRCULATE (indicator light is on)—...
-
Page 5: Air Flow Selector Settings
’06Camry_U (L/O 0507) —Air flow selector settings —Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly. - Page 6 ’06Camry_U (L/O 0507) If following another vehicle on a dusty Heating road, or driving in windy and dusty For best results, set controls as follows: conditions, it is recommended that the air intake selector be temporarily set to Fan speed—Any setting except “OFF” Temperature—Towards WARM RECIRCULATE, which will close off the (red zone)
- Page 7 ’06Camry_U (L/O 0507) Ventilation Defogging Defrosting For best results, set controls as follows: The inside of the windshield The outside of the windshield For best results, set controls as follows: For best results, set controls as follows: Fan speed—Any setting except “OFF” Temperature—Towards COLD Fan speed—Any setting except “OFF”...
-
Page 8: Automatic Air Conditioning System Controls
’06Camry_U (L/O 0507) Automatic air conditioning system— —Controls 1. Temperature selector 2. Air flow selector 3. Windshield air flow button 4. Fan speed selector 5. Air intake selector 6. “A/C” button 7. “OFF” button 8. “AUTO” button 2006 CAMRY from July ‘05 Prod. (OM33708U) - Page 9 ’06Camry_U (L/O 0507) “AUTO” button Temperature selector For automatic operation of the air condi- To increase the temperature, press the “ ” side, to decrease it, press the “ ” tioning, press the “AUTO” button. “AUTO” side. will appear on the display to show that the automatic operation mode has been “MAX.
- Page 10 ’06Camry_U (L/O 0507) 4. Floor/Windshield—Air flows mainly Windshield air flow button from the floor vents and windshield When this button is pressed, air flows vents. mainly from the windshield vents and This position allows the air intake to turns on the defogging function with the select FRESH automatically.
- Page 11 If the “A/C” button indicator flashes, there is a problem in the air conditioning system conditioning automatically shuts off. If this happens, take your ve- hicle to a Toyota dealer for service. 2006 CAMRY from July ‘05 Prod. (OM33708U)
- Page 12 ’06Camry_U (L/O 0507) —Air flow selector settings —Operating tips To cool off your Toyota after it has been parked in the hot sun, drive with the windows open for a few minutes. This vents the hot air, allowing the air conditioning to cool the interior more quickly.
- Page 13 ’06Camry_U (L/O 0507) If following another vehicle on a dusty Heating Air conditioning road, or driving in windy and dusty For best results, set controls as follows: For best results, set controls as follows: conditions, it is recommended that the For automatic operation—...
- Page 14 ’06Camry_U (L/O 0507) Ventilation Defogging and defrosting Press the “A/C” button for dehumidified heating or cooling. This setting clears the For best results, set controls as follows: —The inside of the windshield front view more quickly. For automatic operation— For best results, set controls as follows: On humid days, do not blow cold air —For automatic operation Press in the “AUTO”...
-
Page 15: Side And Rear Vents
’06Camry_U (L/O 0507) Side and rear vents Press the “A/C” button for dehumidified If air flow control is not satisfactory, check heating or cooling. This setting clears the the side and rear vents. The side and rear front view more quickly. vents may be opened or closed as shown. -
Page 16: Checking And Replacing The Air Conditioning Filter
’06Camry_U (L/O 0507) —Checking and replacing the Air conditioning filter— air conditioning filter The air conditioning filter may clog af- ter long use. The filter may need to be replaced if the air flow of the air condi- tioning and heater experiences extreme reductions in operating efficiency, or if the windows begin to fog up easily in FRESH mode. - Page 17 ’06Camry_U (L/O 0507) 1. Open the glove box. Remove the 2. Push in each side of the glove box 3. Remove the filter case from the filter screw with a Phillips−head screw- to disconnect the claws. outlet as shown in the illustration. driver and slide the hook as shown.
- Page 18 ’06Camry_U (L/O 0507) 4. Remove filter from the filter When installing the filter in the filter case. case, keep the “°UP” mark pointing up. 5. Inspect the filter on the surface. INFORMATION If it is the just moderately dusty, it may The air filter should be installed prop- be cleaned by blowing compressed air erly in position.
