Video | SR Megapixel and HD Lenses
SR Megapixel and HD Lenses
www.boschsecurity.com
As CCTV cameras can now capture even higher picture
resolutions through the use of HD sensor technology
and advanced processing, the lenses also need to have
an optical resolution that allows the camera to work at
its optimal point.
This range of Super Resolution (SR) megapixel lenses
is designed to provide improved image resolution and
sharpness, and better depth of field while avoiding the
diffraction issues which can occur with megapixel
sensors.
They provide long and reliable operation with no
maintenance. These varifocal lenses range from wide-
angle to telephoto to cover virtually all applications in
CCTV observation systems.
System overview
This series of SR megapixel lenses includes varifocal
lenses with SR-iris control. They are compact, rugged,
and available in 1/2.5‑inch and 1/2‑inch image formats.
The extent of the range means that an installer is
always able to select the most appropriate lens for
both camera and application.
These lenses come with a standard C or CS mount for
use with a variety of cameras. The iris control
connection is a four-pin standard plug that fits directly
SR megapixel optical resolution
u
High-quality optics
u
1/2.5-inch and 1/2-inch formats
u
Reliable, robust construction
u
Focal length options
u
into the camera's iris output. The lenses deliver
impressive optical quality due to their mega pixel
resolution, contrast reproduction, and coating.
The mechanical construction is designed to withstand
both frequent iris control operations and the
environmental stress of security installations. For
flexible, high-quality, reliable lenses that match a HD
camera's performance, this series is the ideal solution.
Certifications and approvals
Region
Certification
Europe
CE
VLG-3V3813-MP
CE
VLG-2V1803-MP5
CE
VLG-4V0940-MP5
