Summary of Contents for Vaillant VIHSGB210
- Page 1 Operating instructions For the operator Operating instructions Solar heating system with auroSTOR Solar hot water system GB, IE...
-
Page 2: Table Of Contents
Cleaning the cylinder ..........9 Fault finding ..............9 Inspection and maintenance ....... 10 Recycling and disposal .......... 10 Unit ................10 Packaging ..............10 Customer service and manufacturer's guarantee ..............11 Vaillant service ............11 Vaillant guarantee ............11 Technical data ............12 Operating instructions for auroSTOR 0020111120_02... -
Page 3: Notes On The Documentation 1
> Store these operating instructions and all other appli- cable documents in such a way that they are available whenever required. Vaillant Ltd. supports the Benchmark Initiative. Symbols used A benchmark checklist for commissioning gas- fired boilers is attached to these installation ins- The symbols used in the text are explained below. -
Page 4: Safety Instructions
The purpose of the Vaillant solar heating system is to provide a solar-supported hot water supply. Vaillant auroSTOR VIH S GB 210/2 S, VIH S GB 260/2 S, Risk of death from Danger! and VIH S GB 310/2 S solar cylinders are unvented, indi-... -
Page 5: Basic Safety Instructions
The temperature of the stored water could reach high temperatures after solar charging and your Vaillant solar installer will have fitted a tempering valve so as to pre- vent this reaching the hot water taps. Should excessively hot water reach your hot taps contact your installer immediately. -
Page 6: Description Of The Unit
One of the following controllers may be used Solar heating system depending on the design of your system: The Vaillant solar heating system is a closed hydraulic system in which the special heat transfer fluid of the – Vaillant auroMATIC VRS 560 solar controller or solar heating system transfers the heat to the water –... -
Page 7: Operation 4
Operating the solar heating system not even need to make any adjustments when you go on holiday. Danger! Observe the following to ensure your Vaillant solar heat- Risk of scalding and bursts due to inap- ing system works perfectly: propriate alterations! >... -
Page 8: Setting The Hot Water Temperature
4 Operation Setting the hot water temperature If the auroSTOR has been installed in a cupboard used for airing clothes, make sure that clothing The hot water temperature is set to the required value and other objects are not placed on the cylinder, by the competent person during the cylinder commis- control devices, pipes or other system compo- sioning process. -
Page 9: Cleaning The Solar Collector And Cylinder
Operation 4 Cleaning the solar collector and cylinder 4.6.1 Cleaning the solar collectors There is actually no need to clean the collectors. Like skylights, solar collectors do get dirty. However, they are kept reasonably clean naturally by rainfall. 4.6.2 Cleaning the cylinder >... -
Page 10: Inspection And Maintenance
Unit It is important that your hot water cylinder is serviced annually. You must not dispose of your Vaillant auroSTOR or any We recommend entering into a maintenance agreement. of its accessories in normal domestic rubbish. Make sure that the old unit and any accessories are disposed of properly. -
Page 11: Customer Service And Manufacturer's Guarantee 7
Please contact Vaillant Service Solutions (0870 6060 777) for further details. Vaillant guarantee Vaillant provides a full parts and labour guarantee for this appliance. The appliance and all associated pipe work and controls must be installed by suitably competent persons in... -
Page 12: Technical Data
8 Technical data Technical data Unit VIH S GB 210/2 S VIH S GB 260/2 S VIH S GB 310/2 S Total capacity litres Actual capacity litres 209,4 254,4 297,2 Hot water capacity (upper coil) litres 104,8 142,0 144,2 Hot water capacity (solar coil) litres 203,3 246,1... - Page 13 Technical data 8 Unit VIH S GB 210/2 S VIH S GB 260/2 S VIH S GB 310/2 S Electrical connections Immersion heater (according to EN BS 60335) 2.7 kW, 230 V, 50 Hz Length of immersion heater inch Two port motorised valve 230/240 V, 50 Hz Cylinder thermostat 230/240 V, 50 Hz...
- Page 16 Supplier Manufacturer...
