Model No. WETL27905.1

Serial No.

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts,

please call:

08457 089 009

or write:

ICON Health & Fitness, Ltd.

Customer Service Department

Unit 4

Revie Road Industrial Estate

Revie Road

Beeston

Leeds, LS118JG

email: csuk@iconeurope.com

CAUTION

Read all precautions and in-

structions in this manual before

using this equipment. Save this

manual for future reference.

Serial

Number

Decal

USER'S MANUAL

Table of Contents

Need help?

Do you have a question about the Cadence 900 Treadmill and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo Cadence 900 Treadmill

Page 1 Model No. WETL27905.1 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 or write: ICON Health &...
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: A PART IDENTIFICATION CHART, an EXPLODED DRAWING, and a PART LIST are attached in the centre of this manual. WESLO is a registered trademark of ICON IP, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure ASTA approved BS1362 type should be fitted that all users of this treadmill are adequately to the fuse carrier.
Page 4 22. Inspect and properly tighten all parts of the this manual. Never remove the motor hood un- treadmill regularly. less instructed to do so by an authorised ser- vice representative. Servicing other than the 23. Never insert any object into any opening. procedures in this manual should be performed by an authorised service representative only.
Page 5: Before You Begin
And when you’re not exercising, the unique treadmill is WETL27905.1. The serial number can be CADENCE 900 treadmill can be folded up, requiring found on a decal attached to the treadmill (see the less than half the floor space of other treadmills.
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
Page 7 3. Open part bag B. Hold an Upright Spacer (59) against one side of the Frame (96) as shown. Insert a 4” Frame Bolt (54) into the indicated hole in the Upright Spacer and the Frame. Next, tighten a 3/4” Tek Screw (9) into 55 12 the Upright Spacer and the Frame.
Page 8 6. Set the console assembly onto the Left and Right Handrails (13, 40). Be careful not to pinch the Wire Console Assembly Harness (65). Tighten two Pulse Bar Screws (37), with two #10 Star Washers (108), through the brackets on the Handrails and into the Pulse Bar (39).
Page 9 9. Lower the Handrails (40, 13) until they are touching the floor. 40, 13 See drawing 9a. Position the Handrails (40, 13) so the treadmill Frame (96) is centered between them. Firmly tighten the four 3” Bolts (58) and the two 4” Frame Bolts (54).
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed.
Page 11 Clip FEATURES OF THE CONSOLE To use the manual mode of the console, follow the steps beginning on page 12. To use a speed program, The treadmill console offers a selection of features see page 14. ETWE27905 designed to make your workouts more effective and enjoyable.
Page 12 HOW TO TURN ON THE POWER pressed, the speed setting will change by 0.1 mph. If a button is held down, the speed setting Plug in the power cord will change in increments of 0.5 mph. (see page 10). Next, locate the on/off switch on the To stop the walking belt, press the Stop button.
Page 13 Pulse display—This Important: If a “d” ap- display shows your pears in the Speed dis- heart rate when you play, the console is in use the pulse sensor the “demo” mode. This (see step 6). mode is intended to be used only while a Fat/Calories treadmill is displayed in a store.
Page 14 The program will continue in this way until the last HOW TO USE A SPEED PROGRAM period ends. The walking belt will then slow to a stop. Insert the key into the console. To change the incline setting during the program, press the Incline buttons.
Page 15: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
Page 16 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the frame down until it is past the latch pin. Then, slowly release the latch knob.
Page 17: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
Page 18 Locate the Reed Switch (16) and the Magnet (10) on 3 mm the left side of the Pulley (101). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 3 mm (1/8 in.).
Page 19: Conditioning Guidelines
CONDITIONING GUIDELINES is to burn fat, adjust the speed and incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed and incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle...
Page 20 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. 3/4” Screw (38)–9 3/4” Tek Screw (9)–2 Wheel Nut (64)–2 3/8” Washer 3/8” Star (12)–2 Washer (55)–2 Silver Ground...
Page 21: Ordering Replacement Parts
To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL27905.1) • the NAME of the product (WESLO CADENCE 900 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
Page 22 PART LIST—Model No. WETL27905.1 R1105A No. Qty. Description No. Qty. Description No. Qty. Description Hood Cage Nut Access Door #8 Washer 1” Bolt Cable Tie Clamp Foot Rail 1/4” Washer Frame U-nut Belt Guide 1/4” Star Washer 8” Cable Tie 1/2”...
