Installation Guidelines

To fit the

Alpha CombiMax 350 and 600

in a remote location from the boiler

For Technical help or for Service call ...

ALPHA HELPLINE

Tel: 0870 3001 964

Nepicar House, London Road,

Wrotham Heath, Sevenoaks,

Kent TN15 7RS

These guidelines must be used in conjunction with the Installation instructions provided

with the selected combination boiler and CombiMax.

Only a CombiMax produced after February 1999 can be installed remote from the boiler.

Table of Contents

Do you have a question about the Alpha CombiMax 350 and is the answer not in the manual?

Page 1: Installation Guidelines
Installation Guidelines To fit the Alpha CombiMax 350 and 600 in a remote location from the boiler For Technical help or for Service call ... ALPHA HELPLINE Tel: 0870 3001 964 Nepicar House, London Road, Wrotham Heath, Sevenoaks, Kent TN15 7RS These guidelines must be used in conjunction with the Installation instructions provided with the selected combination boiler and CombiMax.
Page 2 INTRODUCTION The Alpha CombiMax has been designed to fit onto the left hand side of an Alpha 240/280 boiler. However, it is now possible (using a CombiMax 350 or 600 produced after February 1999, i.e. from Serial No. A906) to install it up to a distance of 1 metre from the boiler in the positions shown in Fig.
Page 3: Installation Information
The casing components supplied with the CombiMax cannot be used when it is fitted in a remote location from the boiler. 2.4 DHW Expansion Vessel Fit the expansion vessel near the top of the storage cylinder using the flexible hose supplied. See Fig. 3. Alpha CombiMax Remote Location...
Page 4: Filling Loop
The filling loop should be discarded and its connections on the cold mains inlet valve (CombiMax) and heating return valve (boiler) sealed, using ½" BSP threaded caps (not applicable to Alpha 240X). See Fig. 4. 2.6 Connecting Pipework The boiler and CombiMax must be connected together as shown in Fig.
