Brite View BV-210 User Manual

200 mbps powerline ethernet bridge + switch
Hide thumbs Also See for BV-210:

Advertisement

BV-210/BV-254

User Manual

Powerline
Ethernet
Bridge +
Switch
Powerline Ethernet Bridge
Powerline Ethernet Switch
200 Mbps
1.1" Slimmest Design
Low Power Consumption
Best Performance
V. 1.0.1

Advertisement

Table of Contents
loading

Summary of Contents for Brite View BV-210

  • Page 1: User Manual

    BV-210/BV-254 User Manual Powerline 200 Mbps Ethernet 1.1” Slimmest Design Bridge + Low Power Consumption Switch Best Performance Powerline Ethernet Bridge Powerline Ethernet Switch V. 1.0.1...
  • Page 2: Table Of Contents

    ABLE OF CONTENT .....................2  RDERING INFORMATION .........................4  NCLUDED TEMS ..................5  MPORTANT AFETY NSTRUCTIONS ..........6  IRST THING YOUT NEED TO KNOW BEFORE INSTALLATION AC outlets connection ......................6  Connecting the Powerline Adapter to an Extention Cord..........8  Electrical Interference......................8  Electrical Wiring ........................8  ......................9  RODUCT UTLOOK ......................
  • Page 3: Ordering Information

    This BV-210/BV-254 User Manual describes how the powerline connects to the Ethernet Bridge (BV-210) and to the Ethernet Switch (BV-254). The BV-210 is a one-port Powerline Ethernet Bridge. The BV-254 is a four-port Powerline Ethernet Switch. Powerline technology lets you use your home's electrical system to transmit data signals, and it uses the electrical system as a network, with each electrical outlet serving as a node.
  • Page 4 The BV-254 Powerline 4-Port 200Mbps Ethernet Powerline Ethernet Switch Adapter turns any power outlet into a 4-port home (BV-254) network connection. The BV-254 adapter extends your network to provide 200Mpbs connections without the cost or hassle of running new wiring. Just plug the BV-254 Powerline 4-Port Ethernet Adapter directly into the wall outlet, and you are ready.
  • Page 5: Included Items

    NCLUDED TEMS OWERLINE OWERLINE THERNET WITCH THERNET OWERLINE THERNET RIDGE WITCH OMBO PACKAGE DUAL PACKAGE Two devices Combinational devices EVICE THERNET ABLE...
  • Page 6: Important Safety Instructions

    OTICE This product complies with IC: ICES-006; en conformité avec IC: NMB-006 MPORTANT AFETY NSTRUCTIONS This product is intended for connection to the AC power line. For installation instructions, refer to the Installation section. The following precautions should be taken when using this product.
  • Page 7: The First Thing Yout Need To Know Before Installation

    IRST THING YOUT NEED TO KNOW BEFORE INSTALLATION These powerline adapters sends data to and from each other over the existing electrical wiring in your home, and the network performance may be affected by electrical noises or the length of the electrical wiring in your house. Keep the following in mind when placing this powerline device at home.
  • Page 8 The following connections are NOT recommended, although current powerline communication technology can overcome most noise interference from other AC adapters or chargers.
  • Page 9: Connecting The Powerline Adapter To An Extention Cord

    Connecting the Powerline Adapter to an Extention Cord If you must connect this device to a power strip, please keep the following suggestions in mind: • Make sure the extension cord does not have a noise filter or a surge protector, as these features decrease the network signal strength over the electrical wiring.
  • Page 10: Product Outlook

    RODUCT UTLOOK A. Top View Powerline Ethernet Bridge Powerline Ethernet Switch Vent Holes (Do not block) Vent Holes (Do not block) Four Ethernet Ports Ethernet Port B. Side View...
  • Page 11 *1 : The “PLC Link/ACT “ LED indicator will turn on when the powerline link is detected. If the device is serving as a station, the LED indicator will flash to indicate powerline activity. If the device is serving as a CCo (Central Coordinator), the LED indicator will a solid light, even in the presence of powerline activity.
  • Page 12: Product Overview

    RODUCT VERVIEW These powerline Ethernet adapters are virtually Ethernet cable and Ethernet hub replacement. Two of these powerline Ethernet bridges (or one bridge and one switch) can be used to replace an Ethernet cable, for connecting any computer to another computer, computer to a DSL/cable router, or a wireless AP to a DSL/cable device.
  • Page 13: Product Installation

    RODUCT INSTALLATION Setting Logical Network Group Users can set HomePlug AV devices into one or many logical network groups. Devices in the same logical network group will communicate with each other. Devices in different network group won’t communicate with each others. If you have a pair of powerline Ethernet adapters, either one in the pair can be “device A”...
  • Page 14: Remove A Device From A Logical Network Group

    Remove a Device from a Logical Network Group If device A and B are in the same logical network group but you want to remove device A from this logical network group, just follow the procedure in Step 1 by pressing the GROUP button on device A for 10 seconds.
  • Page 16: Application 2 - Computer To Dsl/Cable Router Connection

    Application 2 – Computer to DSL/Cable Router Connection Use brite-View powerline to establish communication between your computer and your router – even if they are in different rooms. Installation Options: Connect the computer to a brite-View powerline Ethernet bridge as shown in Room A. The other brite-View powerline Ethernet bridge can be placed in another room, connected to a broadband DSL/cable router shown in Room B.
  • Page 17 Note: Under decent powerline signal conditions, two devices can communicate with each other without problems even though the two rooms are not right next to each other. (See the FAQ section for more details.)
  • Page 18: Application 3 - Wireless Access Point Range Extensions

    Application 3 – Wireless Access Point Range Extensions Use brite-View powerline Ethernet adapters to extend your WiFi network and eliminate WiFi dead zone. Installation procedure: Connect one powerline Ethernet bridge to a wireless access point as shown in Room A. Then, connect the second included powerline Ethernet bridge or switch to a broadband DSL/cable router as shown in Room B.
  • Page 19: Business Installation

    Business Installation We DO NOT recommend these powerline devices for business operation due to the complexity of the network environment in business settings, although some businesses will find it an inexpensive networking solution.
  • Page 20: Specifications

    PECIFICATIONS Items Description device device Powerline Ethernet Bridge Powerline Ethernet Switch PHY Rate 200Mbps TCP: Up to 90 Mbps TCP: Up to 91 Mbps Effect Data Rate UDP: Up to 91 Mbps UDP: Up to 92 Mbps 2~28 MHz (With Mask) Frequency Band Access Methods CSMA/CA channel-access schemes...
  • Page 21: Faq (Frequently Asked Questions)

    FAQ (Frequently Asked Questions) What is the maximum powerline Ethernet devices communication distance? ANS: Powerline technology provides reliable communication coverage in a home setting; the limiting factor is often your home electrical system noise/interference. Powerline devices can communicate with each other within the distance of 340 feet in most homes. Even if the electrical wiring is very “noisy”, the two devices can still communicate with each other within the distance of 120 feet.
  • Page 22 device in a newly shipped dual or combo package are in same group. How many devices can be assigned to a single group? ANS: Please see S section for maximum number of devices that can be PECIFICATIONS assigned to a single logical network group. There can be multiple groups in the same electric wiring environment.
  • Page 23 HomePlug 1.0 HomePlug turbo HomePlug AV HD-PLC To understand what type of PLC standard this device use, please check it in the section. PECIFICATIONS...
  • Page 24: Trouble Shooting

    ROUBLE SHOOTING New devices are assigned to the same logical network group so they should have no problem communicating with each other. If two used devices cannot communicate with each other: • Check the logical network group to make sure they are using the same PLC configuration utility.
  • Page 25 • Pay special attention to the electrical noise generated by the following devices: Air conditioning – Florescent lights, particularly industrial grade lights – Refrigerators – Surge protectors and other line filters and conditioning – Blowers – Large electrical motors – Note These powerline devices are not designed for business use.
