FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/
PARA USO EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK
RDS MP3/WMA/AAC CD Receiver
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
YAMAGATA (Wuxi) Co., Ltd.
Block 28-25, Changjiang Nanlu, WND, jiangsu, China
CDE-9881R/
CDE-9881RB
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L 'USO
Si prega di leggere prima di utilizzare il
attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa igenom
denna användarhandledning.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117,
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
R
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Phone 02-725-13 15
Designed by ALPINE Japan
Printed in China (Y)
68-08564Z05-A
EN
DE
FR
ES
IT
SE

Advertisement

Table of Contents
loading

Related Manuals for Alpine CDE-9881R

Summary of Contents for Alpine CDE-9881R

  • Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 1-1-8 Nishi Gotanda, 161-165 Princes Highway, Hallam Viale C. Colombo 8, 20090 Trezzano Shinagawa-ku,...

  • Page 2: Table Of Contents

    ENGLISH Contents About MP3/WMA/AAC ......... 13 Sound Setting Operating Instructions Adjusting Bass/Treble/Balance (Between Left and Right)/Fader (Between Front and Rear)/ Defeat ............14 WARNING Setting the Bass Control ......... 14 Setting the Treble Control ....... 15 WARNING ..........3 Adjusting the High Pass Filter ......15 CAUTION ..........
  • Page 3 ® iPod (Optional) Playback ............19 Searching for a desired Song ......19 Quick Search ........... 20 Direct Search Function ........20 Select Playlist/Artist/Album/Podcast/Genre/ Composer ............ 20 Random Play Shuffle (M.I.X.) ....21 Repeat Play ............. 21 Displaying the Text ......... 21 Information In Case of Difficulty ........

  • Page 4: Operating Instructions

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. or death. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Centre for repairing. DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.
  • Page 5 We Irregular Shaped Discs recommend not using these accessories on discs played in Alpine CD players. Be sure to use round shape discs only for this unit and never use any special shape discs.
  • Page 6 On handling Compact Discs (CD/CD-R/CD-RW) • Do not touch the surface. • Do not expose the disc to direct sunlight. • Do not affix stickers or labels. • Clean the disc when it is dusty. • Make sure that there are no bumps around the disc. •...

  • Page 7: Getting Started

    Detaching Getting Started Turn off the unit power. Press (OPEN) to open the front panel. Rotary encoder (OPEN) SOURCE/ To close the front panel, press the left side until it locks as shown in the figure below. (MUTE) Accessory List •...

  • Page 8: Initial System Start-Up

    (MUTE) again will bring the audio back to its previous level. Controllable with Remote Control This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

  • Page 9: Radio

    Presetting Stations Manually Radio Select the radio band and tune in a desired radio station you wish to store in the preset memory. SOURCE/ TUNE/A.ME BAND/TA Press and hold, for at least 2 seconds, any one of the preset buttons (1 through 6) into which you wish to store the station.

  • Page 10: Rds

    Recalling Preset RDS Stations Press FUNC./SETUP so that the indicator Rotary encoder lights up. BAND/TA /ENT Press 1 AF to activate the RDS mode. Press FUNC./SETUP to activate the normal mode. indicator goes out. Make sure that the indicator light goes out, then press the preset button in which your desired RDS station is preset.

  • Page 11: Pi Seek Setting

    PI SEEK Setting Receiving Traffic Information While Playing CD or Radio Press and hold FUNC./SETUP for at least 2 seconds to activate the SETUP mode. Press and hold BAND/TA for at least 2 seconds so that the “TA” indicator lights up. Turn the Rotary encoder to select the PI SEEK mode, and then press /ENT.

  • Page 12: Cd/Mp3/Wma/Aac

    After pressing (OPEN) to open the front panel, CD/MP3/WMA/AAC press to eject the disc. • Do not remove a CD during its eject cycle. Do not load more than one disc at a time. A malfunction may result from doing either. •...

  • Page 13: Random Play)

    M.I.X. (Random Play) File/Folder Name Search (concerning MP3/WMA/AAC) Press 5 in the play or pause mode. The tracks (files) on the disc will be played back in random Folder and file names may be searched and displayed during playback. sequence. During MP3/WMA/AAC playback, press /ESC to To cancel M.I.X.

  • Page 14: About Mp3/Wma/Aac

    Supported playback sampling rates and bit rates About MP3/WMA/AAC Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, 16 kHz, 12 kHz, 11.025 kHz, 8 kHz CAUTION Bit rates: 8 - 320 kbps Except for private use, duplicating audio data (including MP3/ WMA/AAC data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright Sampling rates: 48 kHz, 44.1 kHz, 32 kHz...

  • Page 15: Sound Setting

    Order of files Sound Setting Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be what is expected. Verify the writing order in the software ’ documentation. The playback order of the folders and files is as Rotary encoder follows.

  • Page 16: Setting The Treble Control

    Setting the Bass Centre Frequency Setting the Treble Level -1 Press BAND/TA to select the desired bass centre Turn the Rotary encoder to select the desired frequency. treble level (–7~+7). You can emphasize the treble level. 80 Hz 100 Hz 200 Hz 60 Hz 80 Hz...

  • Page 17: Other Functions

    About the indication display Other Functions When displaying Text, the following indicators are lit according to the mode. TITLE Blinks in search mode when the Rotary encoder is turned. Also blinks when operation, such as fast forward etc., is performed. Displaying the Text Lights up in SETUP mode.

  • Page 18: Setup

    Turn the Rotary encoder to select the desired SOURCE/ , BAND/TA, SETUP menu, and then press /ENT. • CDE-9881R: (e.g. Select SUBWOOFER) TYPE1: When the colour of the six buttons is green, the colour of the other is green .

  • Page 19: Scroll Type Setting

    Scroll Type Setting External Device SCROLL TYPE1 / SCROLL TYPE2 (Initial setting) Choose from two scrolling methods. Connecting to an External Amplifier Select the type you prefer. POWER IC ON (Initial setting) / POWER IC OFF SCROLL TYPE1: The characters scroll from right to left, a single When an external amplifier is connected, sound quality can be improved character at a time.

  • Page 20: Ipod ® (Optional)

    For example: Searching by Artist name ALPINE FULL SPEED™ Connection Cable (KCE-422i) (sold The following example explains how an ARTIST search is performed. separately). When this unit is connected by using the cable, the controls Another search mode can be used for the same operation, although the on the iPod are not functional.

  • Page 21: Quick Search

    Turn the Rotary encoder to select the desired Direct Search Function Song, and then press /ENT. • After pressing and holding /ENT for at least 2 seconds while The unit’s direct search function can be used to search for an album, in each hierarchy (except SONG hierarchy), all songs of the selected song, etc., more efficiently.

  • Page 22: Random Play Shuffle (M.i.x.)

    Random Play Shuffle (M.I.X.) Repeat Play The Shuffle function of the iPod is displayed as M.I.X. on this unit. Only Repeat One is available for the iPod. Shuffle Albums: Repeat One: The songs on each album are played back in proper order. A single song is repeatedly played back.

  • Page 23: Information

    CD insertion not possible. unit is at fault. Otherwise, make sure the rest of your system is properly • A CD is already in the CD player. connected or consult your authorized Alpine dealer. - Eject the CD and remove it. Basic •...

  • Page 24: Indication For Ipod Mode

    - Remove the disc by following these steps: Press the button again for at least 2 seconds. If the disc still does not eject, consult your Alpine dealer. • Caused by the iPod Software Version not being compatible with this unit.

  • Page 25: Specifications

    CHASSIS SIZE Specifications Width 178 mm (7") Height 50 mm (2") FM TUNER SECTION Depth 161 mm (6-3/8") Tuning Range 87.5-108.0 MHz NOSEPIECE SIZE Mono Usable Sensitivity 0.7 µV Alternate Channel Selectivity 80 dB Width 170 mm (6-3/4") Signal-to-Noise Ratio 65 dB Height 46 mm (1-13/16")

  • Page 26: Warning

    CDE-9881R/CDE-9881RB to the fuse box, make sure the fuse for the intended circuit of the CDE-9881R/ DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER CDE-9881RB has the appropriate amperage. Failure to do so may VEHICLE OPERATION, SUCH AS THE STEERING WHEEL OR result in damage to the unit and/or the vehicle.

  • Page 27: Installation

    Front Panel This unit When your vehicle has the Bracket, mount the long hex bolt onto the rear panel of the CDE-9881R/ Caution When you install this unit in your car, do not remove the CDE-9881RB and put the Rubber Cap on the hex detachable front panel.
  • Page 28 Slide the CDE-9881R/CDE-9881RB into the dashboard. When the unit is in place, make sure the locking pins are fully seated in the down position. This can be done by pressing firmly in on the unit while pushing the locking pin down with a small screwdriver.

  • Page 29: Connections

    Connections To iPod Antenna ISO Antenna Plug JASO Antenna Plug (Pink/Black) AUDIO INTERRUPT IN To vehicle phone (Blue/White) REMOTE TURN-ON To amplifier or equalizer (Orange) DIMMER To the instrument cluster illumination lead To power antenna (Red) IGNITION (Black) GND Ignition Key (Blue) POWER ANT BATTERY (Yellow)
  • Page 30 • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
  • Page 36 Produktinformations-Karte ist freiwillig. et en l’envoyant à Alpine, vous acceptez voluntario. Si Vd. nos la remite, será it to Alpine, your data will be tabulated Sollten Sie diese Karte vervollständigen, que ces informations soient utilisées par utilizada de modo confidencial para el into reference data for future Alpine so werden die Daten für zukünftige...
  • Page 37 Alpine, i Vostri dati saranno raccolti in un file di riferimento per lo sviluppo dei nuovi prodotti Alpine. In aggiunta Voi potrete ricevere in futuro informazioni riguardanti i nuovi prodotti o la richiesta di una Vostra opinione circa i prodotti o i servizi forniti da Alpine.
  • Page 38 S/NO. LABEL...
