American DJ
Thank you for purchasing this American DJ® product. Please read the manual before installing or
1
6
1. Fan
2. Power leD Indicator
3. CHDR Warning label
4. Projection Aperture
5. non Interlocking Housing label
6. Mini plug external Power supply
7. Power Switch
SPECIFICATIONS: Diode: 4.9mW, Weight 1.5 lbs., Dimensions: 6.8" (l) x 5.5" (W) x 4.7" (H)
Caution!
No user serviceable parts inside do not attempt repairs. In the event your unit should
fail, contact AmericanDJ®. For service parts visit http://parts.americandj.com
Customer Support:
answer any question should you encounter problems during your set up or initial operation. You may also visit
us on the web at www.americandj.com for any comments or suggestions. Service Hours are Monday through
Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time. Please see other side at the bottom for more information.
Voice: (800) 322-6337
This Laser product complies with the CDRH/BRH Radiation Performance Standards. 21 CFR
Subchapter J.
WARNING!
This Product must not be used for audience scanning. To prevent fire or
shock hazard, do not expose this product to a high temperature or high humidity area.
®
using your new unit.
5
8
7
8. Auto Speed Control
9.Mode Select
10.Program select knob
11.Program gain knob
Supply Voltage: AC 120V adapter AC, 240V adapter
American DJ
provides a toll free customer support line, to provide set up help and to
®
Fax: (323) 582-2610
American DJ
™
Owners Manual
CAUTION! Unit should be mounted in a
manner that the emiited beam will not strike
the audience.
2
WARNING: Never Look Directly INTO Laser Beam
4
CAUTION: Use of controls, adjustments, or procedures other than
those specified herein may result in hazardous
3
11
10
9
This Laser product complies with the
"DAngeR
when open. AVOID DIRECT EYE
eXPoSURe." For Class llla acces-
sible laser radiation with an irradiance
greater than 2.5 x 10
non Interlocking Housing label
e-mail: support@americandj.com
®
loS AngeleS, CA. 90058
radiation exposure.
CHDR Warning label
(located on bottom) (4)
AVOID EXPOSURE
Laser light is emitted
from this aperture
Aperture label
(located inside)
CDRH/BRH radiation performance
standards. 21 CFR Subchapter J.
Cetification label
(located inside)
- laser radiation
Wcm
-3
-2
(located on bottom) (7)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American DJ BAT
Summary of Contents for American DJ BAT
- Page 1 American DJ ™ Owners Manual ® Thank you for purchasing this American DJ® product. Please read the manual before installing or using your new unit. CAUTION! Unit should be mounted in a manner that the emiited beam will not strike the audience.
- Page 2 The Bat™ by American DJ® a new revolution in laser scanner effects! This portable, take anywhere 4.9 mW green laser has 16 pre-set geometric patterns. The Bat™ has three modes of operation: Au- to Speed, Music Mode, & Manual control; up to 100 images may be created in Manual control. This compact, affordable laser is great for mobile DJ’s, home Karaoke, small clubs, and special effects...
- Page 3 LASER WARNINGS AND SAFETY CAUTION IMPORTANT! When installing this projector, make sure that it is mounted in a manner that prevents the audience from looking directly into the beam, and the beam from striking the audience. NON-INTERLOCKED HOUSING WARNING The Galaxian 3D contains high power laser devices internally. Do not open the laser housing, due to the potential exposure to unsafe levels of laser radiation.
- Page 4 Never leave this device running unattended. The operation of a class 3R laser show is only allowed if the show is controlled by a skilled and well- trained operator, familiar with the data included in this manual. The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use.
