Creek Audio OBH-22 Operating Instructions

CREEK OBH-22 SPECIFICATION
INPUT IMPEDANCE
OUTPUT IMPEDANCE
SEPARATION
ATTENUATION
INPUTS
OUPUTS
RELAY MUTING FACTOR
POWER REQUIREMENTS
POWER CONSUMPTION
DC CONNECTOR TYPE
INPUT & MUTE INDICATION
SIZE
WEIGHT
Creek Audio Ltd reserves the right to change or modify
the specification of its products without prior warning.
Creek Audio Ltd
12 Avebury Court, Mark Road, Hemel Hempstead HP2 7TA, England
Telephone: +44 (0) 1442 260146
E-mail: info@creekaudio.com
Web: www.creekaudio.com
< 20 kΩ Ω
20 kΩ Ω
> 80 dB's @ 1kHz
0 - 90 dB's
3 Stereo pairs, inc Tape
2 Stereo pairs, 1 fixed, 1 variable
> 90dB's
24v @ 60 mA
2W max
2.1 mm female DC jack
2 LED
150 x 100 x 66 mm
6" x 4" x 2 1/2"
610 g, 1.3 lb
Designed and made in the UK.
Fax: +44 (0) 870 622 0846
Creek OBH-22
Thank you for purchasing the OBH-22 Infra-red remote control passive Pre-Amp.
You are now in possession of a State of the Art product. The functions and operation
of the OBH-22 are extremely simple. However, the following notes are provided to
explain all aspects of its design and use.
OVERVIEW
The function of the OBH-22 is to provide input selection
and volume adjustment to your Hi-Fi system from your
armchair, via infra-red remote control. The unit consists
of a high quality motorised volume potentiometer, and
two stereo relays which select the desired input and tape
output, together with a muting relay that can short the
signals to ground. A built-in micro-controller decodes the
infra-red signals transmitted by the handset and
translates them into commands which activate the
motorised potentiometer and the muting and input
selection relays.
controller turns itself off to avoid any possibility of
interfering with the main music signal. LED's are used to
indicate the status and mode of operation.
SRC2 Remote
The OBH-22 is purely passive and does not introduce
Handset
any gain or distortion into the signal path. It is therefore
suitable to be used as a control Pre-Amp, provided the
sensitivity of the power amp that is being used is high
enough to be driven directly from the source. i.e. CD or
Tuner etc.
manually at any time, whether the OBH-22 is powered or
not, but without power only Line 1 can be utilised.
Operating
Instructions
After each operation, the micro-
The volume control can be operated
