- Page 1 M + 48 INSTALLATION MANUAL...
- Page 2 PREMIER M PLUS 48 INSTALLATION MANUAL. PREMIER M 48 OVERVIEW. The Premier M plus 48 is the latest large size conventional panel from Zeta Alarm Systems. Its Features include: - • Designed to EN54 Parts 2 & 4. • It is available in sizes from 24 to 48 zones in 4 zone increments. •...
-
Page 3: Table Of Contents
PREMIER M PLUS 48 INSTALLATION MANUAL. CONTENTS INTRODUCTION…….…………………………………………………………… HANDLING THE PCBS USING THIS MANUAL ABOUT THE PREMIER M PLUS 48 FACP & INTEGRAL PSE DESIGNING THE SYSTEM EQUIPMENT GUARANTEE FIRST FIX GUIDELINES…………………………………………………………. RECOMMENDED CABLE TYPES AND THEIR LIMITATIONS MAINS WIRING RECOMMENDATIONS DETECTOR CIRCUIT WIRING DIAGRAM SOUNDER CIRCUIT WIRING DIAGRAM AUXILIARY OUTPUT WIRING... -
Page 4: Introduction
PREMIER M PLUS 48 INSTALLATION MANUAL. THIS FIRE ALARM CONTROL PANEL IS CLASS 1 EQUIPMENT AND MUST BE EARTHED This equipment must be installed and maintained by a qualified and technically experienced person. 1.1 HANDLING THE PCBS If the PCBs are to be removed to ease fitting the enclosure and cables, care must be taken to avoid damage by static. -
Page 5: First Fix Guidelines
PREMIER M PLUS 48 INSTALLATION MANUAL. 2. FIRST FIX All wiring must be installed to meet BS5839: Pt1: 2002 and BS 7671 (Wiring Regs) standards. Other National standards of fire alarm system installation should be adhered to where applicable. 2.1 RECOMMENDED CABLE TYPES AND THEIR LIMITATIONS Screened cables should be used throughout the installation to help shield the Panel from outside interference and ensure EMC compatibility. -
Page 6: Sounder Circuit Wiring Diagram
PREMIER M PLUS 48 INSTALLATION MANUAL. An End of Line capacitor (provided in the Panel) must be connected across the terminals of the last device on each circuit to allow the wiring to be monitored. It is polarity sensitive, and connected with the “–“... -
Page 7: Auxiliary Output Wiring
PREMIER M PLUS 48 INSTALLATION MANUAL. 2.5 AUXILIARY OUTPUT WIRING 2.5.1 Auxiliary Fire Output (AUX): Voltage free changeover contacts. Changes over in any fire condition, and is used for driving local fire fighting equipment such as sprinkler systems, magnetic door holders, air conditioning shut off, etc. -
Page 8: Mounting The Fire Alarm Panel
PREMIER M PLUS 48 INSTALLATION MANUAL. 3. MOUNTING THE FIRE ALARM PANEL It is recommended that the panels door be removed to avoid accidental damage. Also, the termination PCB could be removed and stored in a safe place, while fixing the back box to the wall. 3.1 PLANNING CABLE ENTRY Fig.2 below shows the location of the cable entries to facilitate planning of wiring (home runs) to be brought to the panel. -
Page 9: Connecting Mains & Battery Power
PREMIER M PLUS 48 INSTALLATION MANUAL. 4 CONNECTING MAINS & BATTERY POWER The panel should be connected to 220-240V AC by 4.1 CONNECTING THE MAINS POWER a 5A rated spur to the fuse box with 1mm to 2.5mm INLET MAINS 3-core cable. -
Page 10: Field Device Termination
PREMIER M PLUS 48 INSTALLATION MANUAL. 5. FIELD DEVICE TERMINATION 5.1 TERMINATING THE DETECTION AND ALARM (SOUNDER) CIRCUITS. All cables entering the enclosure should have brass cable glands, which will ensure a good ground to the EMC enclosure coating. The Detector and Sounder circuits should be connected to the appropriate connector block on the Termination PCB as shown in Figure 6 below. -
Page 11: Configuring The Panel
PREMIER M PLUS 48 INSTALLATION MANUAL. 6. CONFIGURING THE PANEL 6.1 SOUNDER ACTIVATION DELAY 6.2.1 DECIDING TO USE A DELAY A delay of up to nine minutes from the Fire Alarm Panel being triggered, to its Alarm sounder outputs being activated, can be programmed into the panel by the Engineer. This is a particularly useful feature for schools, nightclubs and other public places where the nuisance and panic caused by a false alarm must be avoided. -
Page 12: Delay Indication And Override
PREMIER M PLUS 48 INSTALLATION MANUAL. 6.2.3 DELAY INDICATION AND OVERRIDE If a delay is set, the fire panel will light the General Disablement LED and Sounder Delay LED to indicate that the sounders are delayed. If an alarm occurs, the fire LEDs will light as usual, but the sounders will not start until the delay period has expired. -
Page 13: Zone Disablement
PREMIER M PLUS 48 INSTALLATION MANUAL. 7. ZONE DISABLEMENT 7.1 WHY USE ZONE DISABLEMENT To aid commissioning and assist routine maintenance checks, any of the zones or the sounder circuits can be disabled. When a zone (or sounder circuit) is disabled, the panel will not respond to any fault or fire signals it receives from that zone. -
Page 14: Why Use Zone Test
PREMIER M PLUS 48 INSTALLATION MANUAL. 8. ZONE TEST 8.1 WHY USE ZONE TEST To aid commissioning and assist routine maintenance check, a non-latching ‘one man test’ facility is available. When a detector or manual call point is triggered on any zone in Test, the Alarm sounders operate for approximately four seconds on and four seconds off. -
Page 15: General Fault Finding
PREMIER M PLUS 48 INSTALLATION MANUAL. 9. GENERAL FAULT FINDING 9.1 ZONE FAULTS The Zone Faults are non-latching faults. That is, if the fault has been cleared, the panel will automatically reset itself. Open circuit faults will be indicated by zone(s) fault LED being lit steady, the internal Fault Buzzer will sound and the General Fault LED will be lit. -
Page 16: Earth Faults
PREMIER M PLUS 48 INSTALLATION MANUAL. 4.Wrong Charging Voltage. The charging voltage should be 28.4V off load at 20 C. If it has been altered, reset using potentiometer VR1 5. Overcharged Batteries. Remove the batteries and measure the voltage. If it is reading over 27.4 then the batteries are overcharged. -
Page 17: Standby Battery Calculation Guide
PREMIER M PLUS 48 INSTALLATION MANUAL. 10. STANDBY BATTERY CALCULATION In order to calculate the standby battery size required, the following formula can be used:- Battery Size (Standby time in Amp Hours) = 1.25 x [(T ) + (T x (I Where: = Maximum time in hours required for the alarm [½... -
Page 18: Pcb Termination Connections
PREMIER M PLUS 48 INSTALLATION MANUAL. 11. PCB TERMINATION CONNECTIONS. 11.1 CONNECTIONS 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 ZONES ZONES ZONES 1 TO 8 9 TO 16 17 TO 24 BUILT IN BUILT IN BUILT IN 11 12... -
Page 19: Fuses
PREMIER M PLUS 48 INSTALLATION MANUAL. ZONE 12 + & - Connect to zone 12 ZONE 13 + & - Connect to zone 13 ZONE 14+&- Connect to zone 14 ZONE 15 + & - Connect to zone 15 ZONE 16 + & - Connect to zone 16 ZONE 17 +&- Connect to Zone 17... -
Page 20: Enclosure Specifications
PREMIER M PLUS 48 INSTALLATION MANUAL. 12. PANEL SPECIFICATIONS 12.1 ENCLOSURE SPECIFICATIONS DESCRIPTION VALUE ENCLOSURE SIZE 680 x 480 x 135 mm TOP CABLE ENTRIES 40 x 19mm DIA GROMMETED ENTRIES BOTTOM CABLE ENTRIES 10 x 19mm KNOCKOUT ENTRIES REAR CABLE ENTRIES 2 SNAP OUTS, 1X 100x35mm and 1 X 70x35 mm 12.2 ELECTRICAL SPECIFICATIONS ELECTRICAL DESCRIPTION... - Page 21 PREMIER M PLUS 48 INSTALLATION MANUAL. PAGE 21 Approved Document No: GLT.MAN-120 Issue : 1.2 Authorised: GH Date: 2/11/2007...
- Page 22 PREMIER M PLUS 48 INSTALLATION MANUAL. 12. PANEL SPECIFICATIONS 12.1 ENCLOSURE SPECIFICATIONS DESCRIPTION VALUE ENCLOSURE SIZE 480 x 395 x 100 mm TOP CABLE ENTRIES 20 x 19mm DIA GROMMETED ENTRIES BOTTOM CABLE ENTRIES 10 x 19mm KNOCKOUT ENTRIES REAR CABLE ENTRIES 2 SNAP OUTS, 60 x 20mm 12.2 ELECTRICAL SPECIFICATIONS ELECTRICAL DESCRIPTION...
