- Page 1 2 ZONE, 1AREA EXTINGUISHANT CONTROL PANEL OPERATION AND INSTALLATION MANUAL...
- Page 2 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL INTRODUCTION The Premier EX Plus is a 2 zone, single area panel for controlling the release of extinguishing gases in the event of a fire. It has first & second stage sounder (400 mA each) and relay outputs, and has a 1 amp bottle output to drive the extinguishant.
-
Page 3: Operation
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL OPERATION Normal Operations With the “CONTROL” Key in the “ON” position and under normal conditions the system will be silent and the green “POWER LED” illuminated. The power LED will pulse when the EX plus is connected to an addressable loop. The system may either be in “Automatic”... -
Page 4: Indications & Controls
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL INDICATIONS & CONTROLS PANEL INDICATIONS The Premier EX Plus has the following LED indications:- * Power Green Stage sounder fault Yellow * Charger fault Yellow * Timer fault Yellow * Battery fault Yellow * Bottle fault Yellow... -
Page 5: Fixing The Back Box To The Wall
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL FIXING THE BACK BOX TO THE WALL Figure 2: Plan view inside the enclosure without PCBs. Side view for surface / flush installation. 12 x 19mm grommet cable entries 73mm 355mm 60 x 20mm 60 x 20mm back cable back cable... -
Page 6: Connecting The Mains Power
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL CONNECTING THE MAINS POWER INLET MAINS The panel should be connected to 220-240V AC by a 3A rated SUPPLY spur to the fuse box with 1.5mm to 2.5mm 3-core cable. Nothing else should be connected to this supply The connections are:- Live to fuse, Earth to centre connection,... -
Page 7: Wiring Connections
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL WIRING CONNECTIONS DETECTION ZONE WIRING The Premier EX Plus has 2 conventional detection zones which are wired as:- Zone - 2k7 END of LINE RESISTOR Zone + SOUNDER CIRCUIT WIRING Connect electronic sounders as shown. SND+ SND- SOUNDER... - Page 8 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL BOTTLE CIRCUIT WIRING Depending on the solenoid or actuator used, a polarising diode and a Back EMF protection diode may need to be fitted BOTTLE + BOTTLE - SOLENOID VALVE End of Line Resistor REMOTE INPUT CIRCUIT WIRING The Premier EX Plus has the following Remote Inputs:-...
- Page 9 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL SET UP BOTTLE OUTPUT TIMER DELAY. This panel may be shipped with the timer setting in the “fault condition”. This is to force the user to select a timer delay, rather than relying on a default setting. TIME DELAY SWITCH 5 SWITCH 6...
- Page 10 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL CONFIGURATION FOR CONNECTING MULTIPLE SOLENOID. Occasionally the panel may be required to connect to more than one solenoid valve. To connect to 2 valves (total output less than 1.5A) In this scenario, it is possible to fit the 2 circuits into the bottle output, and replace the single 10K end of line with 2 x 47K end of line resistors (&...
-
Page 11: Fault Finding
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL FAULT FINDING ZONE FAULT Zone Open Circuit • Check for breaks in the cable • Check that correct value EOL is fitted • Check that no heads have been removed Zone Short Circuit •... -
Page 12: Battery Fault
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL CHARGER FAULT • Check that mains is present. • Check mains fuse • Check Charger fuse BATTERY FAULT • Check that 2 x 12V SLA batteries are connected in SERIES. • Check battery voltage •... -
Page 13: Enclosure Specifications
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL ENCLOSURE SPECIFICATIONS The premier EX Plus enclosure is made from flame retardant ABS. It is suitable for surface mounting, or semi flush mounting. It has numerous cable entry points as listed below. DESCRIPTION VALUE ENCLOSURE SIZE... -
Page 14: Electrical Specifications
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL ELECTRICAL SPECIFICATIONS Mains Voltage 230 Vac. 59/60Hz +15%, -10%. Charger Voltage 25 – 30 Vdc (set internally to 27.6V) Battery Voltage 24V SLA (2 x 12V) Battery Space 7.0 AH maximum Mains Supply Protection 3.15 AF HRC 20 x5mm fuse Charger Voltage Protection 1.6 AT 20 x 5mm glass fuse... - Page 15 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL ANALOGUE VALUES (RETURN CODES) When the Premier EX Plus is connected to an addressable loop, it will reply with an analogue value depending on its condition. The following table shows what each analogue value means:- ANALOGUE PANEL CONDITION INDICATION ON CENTRAL...
-
Page 16: Stand By Battery Calculation
PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL STAND BY BATTERY CALCULATION In order to calculate the standby battery size required, the following formula can be used:- Battery Size (Standby time in Amp Hours) = 1.25 x [(T ) + (T x (I Where: = Maximum time in hours required for the alarm [½... - Page 17 PREMIER EX PLUS – OPERATION & INSTALLATION MANUAL CONNECTIONS NO CM NC NO CM NC NO CM NC 2 3 4 5 6 13 14 15 AC AC Conn Label Function HOLD/ABORT TO CONNECT AN ABORT SWITCH TO STOP THE BOTTLE OUTPUT AUTO / MAN TO CONNECT A REMOTE SWITCH TO TOGGLE...
