Instruction Manual: 4-8 zone F.A.C.P.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premier Elite and is the answer not in the manual?

Questions and answers

Summary of Contents for Zooper Premier Elite

  • Page 1 Instruction Manual: 4-8 zone F.A.C.P.
  • Page 2: Table Of Contents

    INSTRUCTION MANUAL – 4 to 8 ZONE FIRE ALARM PANEL INDEX INDEX ............................2 Introduction..........................3 Mains & Battery........................4 Connecting the mains......................4 Connecting the batteries......................4 Charger Short Circuit Protection...................4 Detectors & sounders ........................5 Wiring the detectors ......................5 Diode Bases...........................5 Zone Short Circuit Protection ....................5 Wiring the sounders ......................5 Setting a Sounder Activation Delay..................6 Other Connections........................7...
  • Page 3: Introduction

    There is no configuration, simply connect the detectors & sounders and apply power. The Premier Elite range also includes a low cost 1 & 2 zone version These panels are NOT covered in this manual. They have a separate manual.
  • Page 4: Mains & Battery

    12V / 2 Ah Charger Short Circuit Protection The Premier Elite has an intelligent charger, that senses if too much current is being drawn (for instance in the case of totally discharged batteries, or the charger leads being shorted together). In such an event, the Premier Elite 4-8 zone panel will turn off the power to its charger circuit.
  • Page 5: Detectors & Sounders

    Zone Short Circuit Protection The Premier Elite 4-8 zone panel has a higher zone output current than the 1-2 zone panels. This is to allow them to drive larger zones, and zone powered beam detectors etc.
  • Page 6: Setting A Sounder Activation Delay

    INSTRUCTION MANUAL – 4 to 8 ZONE FIRE ALARM PANEL Setting a Sounder Activation Delay On the Premier Elite there is the option to delay the sounder activation in the event of a fire. This might be useful in schools or clubs where the responsible person might want to verify the alarm, before having a “mass evacuation”...
  • Page 7: Other Connections

    The Premier Elite also has the following connections:- Fire Relay The Premier Elite has one volt free change over relay that operates on an alarm. It is rated at 1Amp, SELV. The relay remains operated until the panel has been reset.
  • Page 8: Display & Controls

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Display & Controls Here is the fascia for the Premier Elite. Operating Instructions To Reset From Fire Condition: After all detectors and manual call points have been Normal Operation: returned to normal, turn the key switch to the "CONTROLS Under normal conditions, the system will be silent and the green ENABLED"...
  • Page 9: Display

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Display The Premier Elite has the following LED indicators:- LEDs LIT LED CONDITION PANEL STATUS POWER CONSTANT GREEN The panel is supplied with power, and has no faults / fires (System Normal)
  • Page 10: Controls

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Controls The Premier Elite has the following controls:- BUTTON LABEL START/STOP Used to silence the sounders in an alarm, or to manually start the sounders to evacuate building SILENCE FAULT TONE Used to silence the panel`s internal buzzer in a fault or alarm condition.
  • Page 11: Alarm Condition & Resetting An Alarm

    7. Record findings in the fire alarm log book. Resetting from an alarm condition After the relevant action has been taken, the Premier Elite fire alarm panel can be reset by the following:- Press Stop/Start sounder button (BUTTON 1). This will silence the external sounders.
  • Page 12: Fault Display & Fault-Finding

    Most of these faults will need to be checked by an engineer, but the system can be checked for a removed detector by the responsible person. All faults in the Premier Elite are NON-LATCHING. IE they can not be reset with the reset button. They will clear automatically when the fault has been fixed.
  • Page 13: Zone Fault

    • If a panel does not report a fault when an detector is removed, check with your supplier if the detector is compatible with the Premier Elite. Short Circuit Fault (Gen S/C LED will be lit) •...
  • Page 14: Earth Fault

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Earth Fault An EARTH fault indicates that something is shorting to earth (usually through the cable screen). Disconnect the earth screens one at a time to determine the problem line. (Note: connecting other equipment , eg an oscilloscope or PC, to the panel can give an earth fault) The voltage between battery –Ve and earth should be 14-16 volts.
  • Page 15: Disablement

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Disablement The Premier Elite 4-8 zone allows any zone, or the sounder circuit to be disabled to aid commissioning and assist routine maintenance work. When a zone (or sounder cct) is disabled, the panel will not respond to any fault or fire signals it receives from that zone.
  • Page 16: Test Mode

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Test Mode To aid commissioning and assist routine maintenance check, a non-latching ‘one man test’ facility is available. When a detector or manual call point is triggered on any zone in Test, the Alarm sounders operate for approximately seven seconds on and seven seconds off.
  • Page 17: Optional Repeater Driver

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Optional Repeater Driver The Premier Elite has a connection to fit an optional Zonal Output Card. The card fits next to the display PCB on the fire alarm panel door. Zonal...
  • Page 18: Battery Calculation

    =0.163 + 0.55 + 0.04 + 0 + 0.0033 + 0.0002 =0.757 Amps = PREMIER ELITE QU + 22 X MAXITONE QU + 7 X MCP QU + 34 X OPT QU + 4 x HT QU =0.050 + 22x0 + 7x0 + 34x0.0001 + 4x0.00005 =0.050 + 0 + 0 + 0.0034 + 0.0002...
  • Page 19: Specifications

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Specifications Electrical Specifications ELECTRICAL DESCRIPTION VALUE MAINS VOLTAGE 230V AC +/- 10% @ 50/60 Hz BATTERY VOLTAGE 24V DC (2 X 12V SLA BATTERY) SYSTEM VOLTAGE 24V DC NOMINAL (18 – 32 V) SYSTEM VOLTAGE RIPPLE 2V PK-PK MAX CHARGER SIZE...
  • Page 20: Log Book

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL Log Book MAINTENANCE WORK DATE TIME ZONE / LOCATION REASON FOR WORK WORK CARRIED OUT ADDITIONAL WORK REQUIRED SIGNED PAGE 20 Approved Document No: GLT.MAN-118 Issue : 1 Author: NRPJ Date: 15/11/2006...
  • Page 21: False Alarms

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL FALSE ALARMS DATE TIME ZONE / CAUSE (IF KNOWN) MAINTENANCE MAINTENANCE CATEGORY OF FURTHER SIGNED LOCATION OR ACTIVITIES IN VISIT NEEDED FINDINGS FALSE ALARM ACTION ALARM AREA (YES/NO) REQUIRED PAGE 21 Approved Document No: GLT.MAN-118 Issue : 1 Author: NRPJ...
  • Page 22: All Other Events

    INSTRUCTION MANUAL– 4 to 8 ZONE FIRE ALARM PANEL ALL OTHER EVENTS DATE TIME ZONE / LOCATION DETAILS OF EVENT ACTION DATE INITIALS (INCLUDING CAUSE IF KNOWN) REQUIRED COMPLETED PAGE 22 Approved Document No: GLT.MAN-118 Issue : 1 Author: NRPJ Date: 15/11/2006...
