Norcross HawkEye H22FX User Manual

Handheld sonar system with integrated led flashlight
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
H22FX – HawkEye
safety and many years of trouble-free operation of your product, please read this
manual carefully before using this product.
SAFETY INFORM ATION:
Read this instruction manual carefully before attempting to install or operate
this device.
Periodically wipe the case with a dry cloth. Do not use abrasives or solvents
on this device.
Only qualified personnel should perform repairs or servicing not covered in
this manual.
The LCD used in the product is made of glass. Therefore, it can break when
the product is dropped or impacted.
Keep this product away from heat sources such as radiators, heaters, stoves
and other heat generating sources.
Do not store in extreme temperatures above 150° F (65° C).
Shade the LCD during storage. Do not expose LCD to direct sunlight for
extended periods of time.
NOTES, NOTICES, AND CAUTIONS
WARNING: Indicates a potential for property damage, personal injury or
death.
IMPORTANT: Indicates potential damage to the device and tells you how
to avoid it.
NOTICE: Indicates important information that helps you make better use
of the device and tells you how to correct a performance problem.
INFORMATION: Indicates resources to obtain the proper information to
help you make the most of your device.
w w w . h a w k e y e e l e c t r o n i c s . c o m
USER'S GUIDE
®
Handheld Sonar System with Integrated LED Flashlight
This depth finder should not be used as a navigational aid to
prevent grounding, boat damage, or personal injury. Always
operate the boat at slow speeds in unfamiliar water, or if you
suspect shallow water or submerged objects.
Thank
you for purchasing a HawkEye
product, and welcome to the innovations of
NorCross Marine Products, Inc.
W
:
ARNING
®
To ensure

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HawkEye H22FX and is the answer not in the manual?

Questions and answers

Related Manuals for Norcross HawkEye H22FX

Summary of Contents for Norcross HawkEye H22FX

  • Page 1 USER’S GUIDE H22FX – HawkEye ® Handheld Sonar System with Integrated LED Flashlight ® Thank you for purchasing a HawkEye product, and welcome to the innovations of NorCross Marine Products, Inc. To ensure safety and many years of trouble-free operation of your product, please read this manual carefully before using this product.

  • Page 2: Installing The Batteries

    3 ft (1 m). Permanent damage will occur if it is submerged deeper than 3 ft (1 m). PARTS SUPPLIED IN PACKAGING: The Following Parts should be included in your H22FX Sonar Packaging:...
  • Page 3 CHANGING THE LED LENS COLOR The H22FX is supplied with 4 interchangeable lenses that allow you to choose between white, red, blue, & green flashlight colors. To use it as a fish attractor, simply hang it off the side of your vessel while night fishing.

  • Page 4: Basic Operation

    BASIC OPERATION: Switching the Readings from English to Metric 1. Remove the battery holder as per the instructions in the “Installing the Batteries” section. 2. While looking into the battery compartment, use a small screwdriver, or other slender object, to reach into the battery compartment and move the switch to the LEFT for Metric readings, or to the RIGHT for English Switch...
  • Page 5 Obtaining Temperature Readings (Thermometer Mode) The H22FX has an integrated temperature sensor built into the sonar sensor housing. To Obtain Temperature Readings: 1. Activate the Depth Reading Mode. 2. Once on, flip the activation switch to the CENTER, and then back to the RIGHT within 1 second.
  • Page 6 OTICE Some boats have a hollow space between the floor and the hull bottom called a bilge. The H22FX will not “Shoot-Thru” in this type of boat unless it is placed directly against the hull surface that is in direct contact with the water.

  • Page 7: Using The Led Flashlight

    1. Activate the Depth Reading feature. 2. Place the device perpendicular to the water surface to obtain a correct depth reading. 3. Once a correct reading is obtained, move the H22FX around in a scanning motion (similar to using a flashlight).

  • Page 8: Care And Maintenance

    (available at any dive shop). Care for Your H22FX 1. Clean the device with fresh water and dry off before storing. 2. Remove the batteries from the device to prevent battery leakage and corrosion.
  • Page 9 NFORMATION If you have questions about this device please visit our Customer Service Center on our website or call us toll free at 888-766-7276. • Warranty Details Warranty Registration • Troubleshooting Product Knowledgebase • Product Specifications Parts & Accessories www.hawkeyeelectronics.com Nothing Happens When I Turn the Power On Make sure that you have installed a good set of batteries and aligned them as per the diagram within the battery compartment.

  • Page 10: Warranty

    sonar will mistake it for fish. Trash & debris may also give false readings. Adjusting the sensitivity setting to the lowest level may reduce these false readings, but if they do not go away, it is suggested that you discontinue use of the fish finder under these conditions.
  • Page 11 (F) 407-370-6880 (E) support@norcrossmarine.com (I) www.norcrossmarine.com ARNING © 2013 NorCross Marine Products Inc., All Rights Reserved. ALL unauthorized copying of the content of this document without the expressed written consent of NorCross Marine Products, Inc is strictly forbidden. w w w . h a w k e y e e l e c t r o n i c s . c o m...
  • Page 12 NOTES w w w . h a w k e y e e l e c t r o n i c s . c o m...
