USER'S GUIDE
H22PX – HawkEye
This depth sounder should not be used as a navigational aid to
prevent grounding, boat damage, or personal injury. Always operate
the boat at slow speeds in unfamiliar water, or if you suspect
shallow water or submerged objects.
Visit our Customer Service Center on our website for
®
Handheld Sonar System
Thank you for purchasing a HawkEye® product,
and welcome to the innovations of NorCross
Marine Products, Inc.
many years of trouble-free operation of your
W
:
ARNING
I
:
NFORMATION
To ensure safety and
Advertisement
Table of Contents
Related Manuals for Norcross HawkEye H22PX
Summary of Contents for Norcross HawkEye H22PX
- Page 1 ® H22PX – HawkEye Handheld Sonar System Thank you for purchasing a HawkEye® product, and welcome to the innovations of NorCross Marine Products, Inc. To ensure safety and many years of trouble-free operation of your product, please read this manual carefully before using this product.
- Page 2 PARTS SUPPLIED IN PACKAGING: The Following Parts should be included in your H22PX Sonar Packaging: Sensor • H22PX Handheld Sonar System • Battery Cap • Battery Holder (inside the battery compartment) • Lanyard (attached to the Battery Cap) • FreedomClub Card •...
- Page 3 BASIC OPERATION: Switching the Readings from English to Metric Remove the battery holder as per the instructions in the “Installing the Batteries” section. While looking into the battery compartment, use a small screwdriver, or other slender object, to reach into the battery compartment and move the switch to the LEFT for Metric readings, or to the RIGHT for English readings.
- Page 4 This device has a temperature accuracy rating of plus or minus 5%. The temperature probe may take up to 90 seconds to adjust to extreme changes in temperature. If you desire to have instant temperature readings you may want to consider purchasing the NorCross® Infrared Marine Thermometer (IR101SP). SHOOTING THROUGH A BOAT HULL The H22PX advanced sonar capabilities allow it to “Shoot-...
- Page 5 To Shoot Thru Ice: Clear away snow to expose the ice surface. Place a small amount of liquid water on the ice and set the transducer side of the device on the water. If there are any air pockets between the device and ice, or the water below the ice, the device will not work properly and will require you to try another spot, or cut a hole in the ice to use.
- Page 6 CARE AND M AINTENANCE Care for Your H22PX Clean the device with fresh water and dry off before storing. Remove the batteries from the device to prevent battery leakage and corrosion. Store the depth sounder in a cool, dry place. Never leave it in temperatures over 158º...
- Page 7 function properly if there is air between the sonar sensor and the water surface; keep this in mind when using the device through a boat hull or ice. I See Fish Under the Sonar Sensor, but Nothing Appears on the Display As with the depth reading, the fish finder will not detect any objects that are closer than 2.5 ft from the sonar sensor.
- Page 8 (E) customerservice@norcrossmarine.com (I) www.norcrossmarine.com VER.04 ARNING © 2010 NorCross Marine Products Inc., All Rights Reserved. ALL unauthorized copying of the content of this document without the expressed written consent of NorCross Marine Products, Inc is strictly forbidden. w w w . h a w k e y e e l e c t r o n i c s . c o m...
