Luma MF24B 24 Owner's Manual

24” commercial misting fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT SAFETY INFORMATION: Please carefully read this manual
before attempting to install or use this misting fan. For your safety, comply
with all safety instructions and warnings contained in this owner's manual
to prevent personal injury or property damage.
To view the full line of Luma Comfort products, please visit
www.lumacomfort.com.
Owner's Manual
MF24B 24" Commercial Misting Fan

Advertisement

Table of Contents
loading

Related Manuals for Luma MF24B 24

Summary of Contents for Luma MF24B 24

  • Page 1 For your safety, comply with all safety instructions and warnings contained in this owner’s manual to prevent personal injury or property damage. To view the full line of Luma Comfort products, please visit www.lumacomfort.com.

  • Page 2: Table Of Contents

    Contents Introduction ........................1 Product Benefits ......................1 Important Safety Information ................... 1 Assembly Instructions ..................... 2 Step 1: Assembling the Stand Pole ................2 Step 2: Connecting the Back Panel ................3 Step 3: Connecting the Water Line ................4 Step 4: Connecting the Fan Head to the Stand Pole ..........

  • Page 3: Introduction

    Introduction Thank you for purchasing this misting fan from Luma Comfort, the world leader in home appliances and home comfort products. This owner’s manual provides specific operating instructions for your misting fan. Use the misting fan only as instructed in this owner’s manual.

  • Page 4: Assembly Instructions

    Assembly Instructions DO NOT plug in the fan before assembly. This misting fan comes in 2 separate boxes. Carefully remove all packaging materials and retain for future storage/use. Make sure there is no residual foam left in any of the components. A screwdriver and wrench will be required to assemble this misting fan. Step 1: Assembling the Stand Pole a.

  • Page 5: Step 2: Connecting The Back Panel

    Step 2: Connecting the Back Panel a. Refer to diagram 2. Find the rectangular panel located on the back of the stand pole. Remove this back panel from the stand pole by completely unscrewing it from the stand pole. Set it aside. b.

  • Page 6: Step 3: Connecting The Water Line

    Step 3: Connecting the Water Line a. Refer to diagram 3. Locate the metal pipe and fan head and attach the fan head onto the pipe. The fan head should have 2 water hoses (1 large and 1 small) and 1 electric wire with male connector plug connected to it.

  • Page 7: Step 4: Connecting The Fan Head To The Stand Pole

    Step 4: Connecting the Fan Head to the Stand Pole a. Refer to diagram 4. Place the stand pole/base on a level surface. b. Take the water hoses and electric wire from the fan head/pipe and thread them through the top of the stand pole.

  • Page 8: Step 5: Assembling The Water Tank

    Step 5: Assembling the Water Tank a. Refer to diagram 5. Take the water pump and place it in the pump slot. b. Locate the water tank and place it on the fan base, making sure to line up the pump opening with the pump slot so that they fit together.

  • Page 9: Operating Instructions

    Operating Instructions 1. This misting fan can operate with optimal output in temperatures up to 104°F. 2. Lift up the tank cover and fill the tank with clean water. 3. Connect the fan to a power supply. 4. Turn on the fan by pressing the red power switch. 5.

  • Page 10: Technical Support

    Technical Support Luma Comfort is committed to providing a premier service experience. If you are experiencing any technical issues with your product related to either setup or operation, please contact our product support team at 1-866-737-6390 or support@lumacomfort.com. Product Specifications...

  • Page 11: Warranty

    Luma Comfort products are warranted to be free from defects in workmanship or materials for one (1) year from the date of purchase. If the product is found to be defective within this period, Luma Comfort, at its sole option, will repair or replace any components that fail during normal operation. The repairs or replacement will be made at no charge to the customer for parts and labor, assuming that the customer shall be responsible for all transportation costs to and from Luma Comfort.
