Macman Hook-Up Diagram

To Synthesizer or Sound
Module MIDI Ins
OUT
1
The MIDI Data In and Out indicator LEDs are only operational
when the INTERFACE/THRU switch is IN and the red POWER
LED is lit. The MIDI LEDs will flash whenever MIDI data is
received or transmitted and can be very helpful when trouble
shooting your MIDI system. If the INTERFACE/THRU switch
is In and MIDI data is sent out from the computer, Macman's
MIDI Out LED will blink, indicating that data is being sent. If
your keyboard's MIDI Out is connected to the Macman MIDI In
and keys are played, the MIDI In LED should blink indicating
that data is being received.
From Synth
MIDI Out
OUT OUT
MIDI
MACMAN
MACINTOSH MIDI INTERFACE
IN
To Modem
or Printer
IN OUT
SERIAL
LED
OUT POWER
From Mac
Modem or
Printer
IN
