1. IMPORTANT SAFETY INSTRUCTIONS ................................................................................. 4
2. COOKTOP MEASUREMENTS ............................................................................................... 5
3. POSITIONING THE COOKTOP AND LOCATION REQUIREMENTS .................................... 6
3.1 Type A installation measurements (Empty base) ............................................................................................ 7
3.2 Type B installation measurements (Complete base) ...................................................................................... 8
3.3 Gas supply requirements .............................................................................................................................. 10
3.4 Electrical requirements .................................................................................................................................. 11
4. INSTALLING THE COOKTOP ............................................................................................... 13
5. CHECKING OPERATION ...................................................................................................... 16
6. WIRING DIAGRAMS ............................................................................................................. 17
WARNING: For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, or to prevent property damage, personal injury or death.
Do not store or use gasoline or other flammable vapors and liquids near this or any other
appliance.
•
Do not attempt to switch on any appliances.
•
Do not touch any electrical switches.
•
Do not use any telephones in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
lf you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified engineer who is able to
install, commission and test the appliance
Table of Contents
WHAT TO DO IF YOU SMELL GAS
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smeg HB96CXU3
Summary of Contents for Smeg HB96CXU3
-
Page 1: Table Of Contents
Table of Contents 1. IMPORTANT SAFETY INSTRUCTIONS ................. 4 2. COOKTOP MEASUREMENTS ....................5 3. POSITIONING THE COOKTOP AND LOCATION REQUIREMENTS ........6 3.1 Type A installation measurements (Empty base) .................... 7 3.2 Type B installation measurements (Complete base) ..................8 3.3 Gas supply requirements .......................... -
Page 2: Important Safety Instructions
Important Safety Instruction 1. IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS – Your safety and the safety of others are very important. We have provided many important safety messages throughout this manual and on the appliance. Read all instructions before using the appliance and always obey all safety messages. RECOGNIZE SAFETY INFORMATION This is a safety alert symbol. -
Page 3: Cooktop Measurements
Instructions for the Installer 2. COOKTOP MEASUREMENTS... -
Page 4: Positioning The Cooktop And Location Requirements
Instructions for the Installer 3. POSITIONING THE COOKTOP AND LOCATION REQUIREMENTS NOTE: The following operation requires construction and/or carpentry work and must therefore be carried out by a competent technician. The cooktop may be installed on various materials, such as masonry, metal, solid wood, plastic laminated wood etc. -
Page 5: Type A Installation Measurements (Empty Base)
Instructions for the Installer 3.1 Type A installation measurements (Empty base) DISTANCES 866 mm 630 mm 210 mm 900 mm 904 mm 457 mm 762 mm MINIMUM 18 ” 30 ” ” ” ” ” ” 866 mm 650 mm 330 mm MAXIMUM 13 ”... -
Page 6: Type B Installation Measurements (Complete Base)
Instructions for the Installer 3.2 Type B installation measurements (Complete base) - Page 7 Instructions for the Installer DISTANCES 630 mm 210 mm 900 mm 904 mm 457 mm 762 mm MINIMUM 18 ” 30 ” ” ” ” ” 650 mm 330 mm MAXIMUM 13 ” ” CABINET BASE: Make two openings in the back of base that have the dimensions given alongside.
-
Page 8: Gas Supply Requirements
Instructions for the Installer 3.3 Gas supply requirements EXPLOSION HAZARD Use a new AGA or CSA-approved gas supply line. The supply line must be equipped with a manual shut-off valve. This valve should be located in the same room but away from the cooktop. It should be in a location where it can be easily opened and closed. -
Page 9: Electrical Requirements
Instructions for the Installer The regulator must be checked at a minimum water column of at least 1” W.C. above the set pressure. The inlet pressure to the regulator should be as follows for operation and checking the regulator setting: - NATURAL GAS: Set pressure at 4”... - Page 10 Instructions for the Installer 3.4.1 Recommended Grounding Method For your personal safety, this cooktop must be grounded. This cooktop is equipped with a 3-prong ground plug. To minimize possible shock hazard, the cord must be plugged into a mating 3-prong ground-type outlet, grounded in accordance with the National ANSI/NFPA 70 Electrical Code (latest edition*) or the Canadian Electrical Code (CSA)** and local codes and ordinances.
-
Page 11: Installing The Cooktop
Instructions for the Installer 4. INSTALLING THE COOKTOP Remove the styrofoam protection and lift the cooktop in order to extract it from the side protectors and the box. Connection to the gas mains should be made with a flexible metal pipe and conforming to the provisions defined by the current standard regulations in force. - Page 12 Instructions for the Installer FASTENING FOR TYPE A INSTALLATION: After cooktop positioned, overlap brackets (per side) underneath the cooktop (B). Tighten the fastening screws (C) provided to the support strips so that once they are tightened, the cooktop is securely fastened to the structure.
- Page 13 Instructions for the Installer Use a pipe-joint compound made for use with NATURAL and L.P. gas. lf a flexible metal pipe is used, make sure that the tubing is not kinked. Always use a pipe-joint compound made for use with NATURAL GAS and L.P. GAS between pressure regulator F and adaptor E and between pressure regulator F and pipe G.
-
Page 14: Checking Operation
Instructions for the Installer 5. CHECKING OPERATION After having fastened the top to the support structure, some simple procedures are required in order to check that it works properly. Check for any gas leaks near the cooktop connector, the pressure regulator and the safety valve. FIRE HAZARD WARNING Use a soapy solution to check that it is leak-tight. -
Page 15: Wiring Diagrams
Instructions for the Installer 6. WIRING DIAGRAMS The power cord on this appliance is equipped with a three pronge polarized plug (grounding) which fits in standard three pronged (grounding) wall outlets. When servicing the controls, label all wires prior to disconnection. WARNING Wiring errors can cause improper and dangerous operation.
