Function keys panel

1. Remote window
2. Analog variable increase
3. Menu
4. Analog variable decrease
5. Exchange between V1/V2
6. Power on/off
Press MENU to display the adjustments in this order.
Brightness-->Color-->Contrast-->Volume-->...

Methods of remote using

V1/V2 conversion
Analog variable decrease
Switch for mode
1
2
3
4
5
6
PLCM7200
Power ON/OFF
Analog variable increase
Menu button

Wire diagram

(Green)reverse car
(Red)battery+12v
(Black)grounding
(Yellow)video 1 input
(Yellow)video 2 input
PLAYER
PLCM7200
CAMERA
