- Page 1 DM-3200 SONAR DM-3200 DAW Control Mackie Control emulation for SONAR 4.x Version 1.11 DM-3200 SONAR...
-
Page 2: Table Of Contents
DM-3200 SONAR Summary ................................3 Setting up the DM-3200............................. 3 Enabling MIDI devices in SONAR ........................ 3 Adding a Control Surface..........................3 Configuration ..............................4 LCD screen ................................ 6 Channel Strip..............................6 SEL key limitation............................6 Top panel buttons ............................... 7 Pan ................................. -
Page 3: Summary
This manual describes using the DM-3200’s control surface features with SONAR 4.x. 2. Setting up the DM-3200 At the DM-3200’s REMOTE > EXT.CTRL screen, add two MC for SOANR devices. Similarly, add one MC for SONAR device in the REMOTE > MACHINE. CTRL screen. -
Page 4: Configuration
The Configure Layout button changes to Press Again When Done. The first line in the Mackie Control display section in the DM-3200 LCD screen reads "Use VPot 1 to assign channel numbers" and "1-8" is displayed on the 2nd line as control target tracks. - Page 5 DM-3200 SONAR Check to see that CH:01-08 is displayed in the upper left and select Track1-8 with Vpot1 (CH1 LED Ring Encoder). Touch any fader on channels 9-16 and the CH:09-16 screen is displayed in the upper left and select Track9-16 with Vpot1 (CH9 LED Ring Encoder).
-
Page 6: Lcd Screen
Sends out a touch-sense Master track message. touch Master fader Master fader Controls the Master fader. SEL key limitation With SONAR, the SEL key is not available for selecting tracks. Switching between channel groups 1-8 and 9-16 is possible on the DM-3200 LCD screen. DM-3200 SONAR... -
Page 7: Top Panel Buttons
DM-3200 SONAR 5. Top panel buttons The table below provides an overview of the top panel buttons-related SONAR-ready functions. DM-3200 Modifier SONAR function Note Sets parameters to be controlled by the Ring encoder. See Section 5.1 below. Sends Sets parameters to be controlled by the Ring encoder. -
Page 8: Transport
DM-3200 SONAR 6. Transport The table below provides an overview of the transport-related SONAR-ready functions. DM-3200 Modifier SONAR function Note Rewind Rewind Activates the Rewind and Slow rewind functions. Fast forward Fast forward Activates the Fast Forward and Slow fast forward functions.
