Digital Mixers
Compact 40-Input, 25-Bus
Digital Mixing Console with
16 Programmable MIDAS
Preamps, 17 Motorized Faders,
Channel LCD's, FireWire*/USB
Audio Interface and iPad/iPhone*
Remote Control
Compact 40-input channel, 25-bus
digital mixing console for Studio and
Live application
16 MIDAS-designed, fully
programmable mic preamps for
audiophile sound quality
17 Fully automated motorized
100 mm faders allow for instant
overview, powerful scene
management and DAW control
8 XLR outputs plus 6 additional line
in/outputs, 2 phones connectors and
a talkback section with integrated or
external mic
Individual and dynamic LCD Scribble
Strips on all channels and buses
creating easy assignment and
intuitive channel distinction
32 x 32 channel audio interface over
FireWire* and USB 2.0, with DAW
remote control emulating HUI*
and Mackie Control*
iPad* and iPhone* apps for
professional remote operation
available free of charge—no host
PC required
High-resolution 7" day-viewable
Color TFT for easy viewing of
workflow components and
parameters
Main LCR, 6 matrix buses and all
16 mix buses each featuring inserts,
6-band parametric EQ's and full
dynamics processing, plus 8 DCA and
6 mute groups
Virtual FX rack featuring 8 true-stereo
FX slots include high-end simulations
such as Lexicon 480L* and PCM70*,
EMT250* and Quantec QRS* etc.
X32 COMPACT
Compact 40-Input Channel,
25-Bus Digital Mixing Console with
16 Programmable MIDAS Preamps,
17 Motorized Faders, Channel LCD's,
FireWire*/USB Audio Interface and
iPad/iPhone* Remote Control
Lean Mean Mixing Machine
What happened to the X32? It's there...
just a little bit smaller. The X32 COMPACT
delivers the best of the flagship X32
console in a slightly smaller package
for installs at smaller venues, houses of
worship, theaters or discerning
audiosmiths who may not need as many
local inputs or motorized faders.
Powered by MIDAS & KLARK TEKNIK
When we began development
on the X32 COMPACT, we called on
our sister companies, MIDAS and
KLARK TEKNIK, recognized the world
over for their digital consoles and EQ/FX
processing, for implementation support.
The programmable, high-grade mic
preamps found in the X32 COMPACT
are based on a genuine MIDAS design,
all the way down to their A/D converters.
The resulting design ensures superior
common mode rejection ratio (CMRR) and
extremely low harmonic distortion (THD).
The X32 COMPACT is an amazingly clean
amalgam of high technology merged with
superb user-friendly features.
We also received brilliant support from
MIDAS and KLARK TEKNIK in designing
X32 COMPACT's GUI (graphical user
interface), a major advancement in digital
mixing made easy, productive, and well...
fun! They also drew on their extensive
experience in FPGA (Field Programmable
Gate Array) coding for rock-solid, ultra-low
latency digital channel patching—giving
the X32 COMPACT the capacity to handle
up to 168 sources on 168 destinations,
including the two AES50 ports. You can
expect to see more collaboration between
BEHRINGER and MIDAS in the very
near future.
You're Well Connected
Ultimate connectivity remains the
battle cry of the X32 COMPACT with its
40 inputs, 25 buses, 16 programmable
MIDAS-designed mic preamps,
FireWire* and USB 2.0 recording capability.
Not sure which X32 is right for you?
We totally get it. That's why the entire X32
family is designed to be beautifully scalable
through the powerful AES50 ports built
right in. Connect the powerhouse S16
digital snakes to these inputs to add an
additional 16 mic preamps to your setup.
Travel Light... Travel Far
Need another X32 for side of
stage or the broadcast control booth?
X32 COMPACT packs all the features
with the same great 7" TFT screen and
customizable LCD scribble strip so you
can take on the world of sound with all
the firepower you'll ever need – without
hauling a world of outboard gear and
analog snake cables.
