Summary of Contents for Samsung N128
- Page 1 N128/N138 SAMSUNG User Guide The image shown on the cover may differ from the product.
-
Page 3: Table Of Contents
Contents Chapter 1. Getting Started Chapter 3. Settings and Upgrade Cautions Regarding OS Support LCD Brightness Control Before You Start BIOS Setup Safety Precautions Entering the BIOS Setup Proper Posture During Computer Use 20 The BIOS Setup Screen Important Safety Information Setting a Boot Password Replacement Parts and Accessories Changing the Boot Priority... - Page 5 Chapter 1. Getting Started Cautions Regarding OS Support Before You Start Safety Precautions Proper Posture During Computer Use Important Safety Information Replacement Parts and Accessories Regulatory Compliance Statements WEEE SYMBOL INFORMATION Basic Items Overview Front View Status Indicators Right View Left View Back View Bottom View...
-
Page 6: Cautions Regarding Os Support
Do not install an illegal copy or a copy that has already been installed on another For the installation procedures and any issues with the operating systems or applications not supplied by Samsung Computer, contact the corresponding software company. The company will not provide a replacement or refund due to the reason and if our service engineer visits you due to this problem, a service charge will be applied. -
Page 7: Before You Start
The information in this document is subject to change without notice due to improving the performance of the product. Samsung Electronics shall not be liable for any data loss. Please take care to avoid losing any important data and backup your data to prevent any such data loss. - Page 8 Performance Restrictions Online games and some games (2D,3D) may not be supported and Full HD video and some high bit rate HD video playback may be slow and stutter on this computer. There is one memory slot provided on this computer. It supports GB memory max. To upgrade to GB memory, replace the current memory with a GB memory module.
-
Page 9: Safety Precautions
Safety Precautions For your security and to prevent damage, please read the following safety instructions carefully. Since this is commonly applied to Samsung Computers, some pictures may differ from actual product. Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. - Page 10 Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Power Related The power plug and wall outlet figures may differ depending on the country specifications and the product model. Do not touch the main plug If the power cord or power Plug the power cord firmly or power cord with wet...
- Page 11 Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. AC Adapter Usage Precautions Do not bend the power Do not place heavy objects Connect the power cord to cord excessively or do or step onto the power the AC adapter firmly.
- Page 12 Please use an authorized or even an explosion. Do not close the LCD panel battery and adapter approved by Samsung and put the computer into Electronics. your bag to move it when it is still turned on.
- Page 13 Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Usage Related Never heat the battery If liquid leaks out of the Disconnect all cables or put the battery into a battery or there is a funny connected to the fire.
- Page 14 Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Upgrade Related Do not place any container If the computer is broken Never disassemble the filled with water or or dropped, disconnect the power supply or AC chemicals over or near the power cord and contact a adapter.
- Page 15 Warning Failing to follow instructions marked with this symbol may cause personal injury and even fatality. Custody and Movement Related Use only authorized Follow the instructions When carrying the parts (multi-plug, battery for the relevant location notebook computer with and memory) and never (e.g.
- Page 16 Do not place a heavy or expose it to heat (e.g. Use only a battery object over the product. inside a vehicle during the authorized by Samsung summer). Electronics. This may cause a problem with the computer. In There is a danger of...
- Page 17 Close the LCD panel If the computer emits only after checking if the smoke, or there is a burning Authorized Samsung Repair notebook computer is smell, disconnect the Centers will carry out safety turned off. power plug from the wall checks after a repair.
- Page 18 To connect a device that computer cleansing the product or parts. is not manufactured or solution when cleaning authorized by Samsung The device may be the product and only use Electronics, enquire at damaged or you may be the computer when it is your service center before injured.
- Page 19 Caution Failing to follow instructions marked with this symbol may cause slight injury or damage to the product. Custody and Cautions on Preventing Data Loss (Hard Disk Movement Related Management) When moving the product, Take care not to damage the data on a hard disk drive. turn the power off and ■...
-
Page 20: Proper Posture During Computer Use
Proper Posture During Computer Use Maintaining a proper posture during computer use is very important to prevent physical harm. The following instructions are about maintaining a proper posture during computer use developed through human engineering. Please read and follow them carefully when using the computer. - Page 21 Eye Position Hand Position Keep the monitor or LCD away from your Keep your arm at a right angle as shown by eyes by at least 50cm. the figure. Keep the line from your elbow to your Adjust the height of the monitor and the hand straight.
- Page 22 Volume Control (Headphones and Use Time (Break Time) Speakers) Take a break for 10 minutes or more after a 50-minute period when working for Check your volume first to listen to music. more than one hour. Illumination Do not use the computer in dark locations.
-
Page 23: Important Safety Information
Important Safety Information Safety Instructions Openings in the computer case are Your system is designed and tested to meet provided for ventilation. Do not block the latest standards for safety of information or cover these openings. Make sure technology equipment. However, to ensure you provide adequate space, at least 6 safe use of this product, it is important that inches (15 cm), around the system for... - Page 24 Care During Use The Instruction On Safety Operation of NotePC Do not walk on the power cord or allow anything to rest on it. When installing and operating devices Do not spill anything on the system. The please refer to safety requirements in the best way to avoid spills is to not eat or user guide.
-
Page 25: Replacement Parts And Accessories
“Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Performance Standard. Contact the Samsung Helpline for Should the unit ever need servicing, contact information on how to dispose of batteries an authorized service location. - Page 26 Connect and Disconnect Power Cord Requirements the AC adapter The power cord set (wall plug, cable and AC adapter plug) you received with your The socket-outlet shall be installed near the computer meets the requirements for use equipment and shall be easily accessible. in the country where you purchased your Do not unplug the power cord out by pulling equipment.
-
Page 27: Regulatory Compliance Statements
Regulatory Compliance Statements Wireless Guidance (If fitted with 2.4G band or 5G band) Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4GHz/5GHz Band, may be present (embedded) in your notebook system. The following section is a general overview of considerations while operating a wireless device. Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections). - Page 28 Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations require wireless devices to be turned off while traveling in an airplane. 802.11ABGN (also known as wireless Ethernet or Wifi) and Bluetooth communication devices are examples of devices that provide wireless communication. ...
- Page 29 United States of America USA and Canada Safety Use On Aircraft Caution Requirements and Notices Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices Do not touch or move antenna while the unit because their signals could is transmitting or receiving.
- Page 30 Unintentional Emitter per FCC Part 15 If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet helpful: This device complies with Part 15 of the FCC “Something About Interference.” Rules.
- Page 31 Intentional emitter per FCC Part 15 Wireless devices are not user serviceable. Do not modify them in (If fitted with 2.4G band or 5G band) any way. Low power, Radio LAN type devices (radio Modification to a wireless device frequency (RF) wireless communication will void the authorization to use it.
- Page 32 FCC Part 68 The telephone company may make changes in its facilities, equipment, operations, or (If fitted with a modem device.) procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advanced This equipment compiles with part of the notice in order for you to make necessary FCC rules.
- Page 33 Canada Unintentional Emitter per ICES-003 The maximum allowed antenna gain for use with this device is 6dBi in order to comply with the E.I.R.P limit for the 5.25- to 5.35 and This digital apparatus does not exceed the 5.725 to 5.85 GHz frequency range in point- Class B limits for radio noise emissions to-point operation.
- Page 34 Telecommunications per DOC notice To avoid electrical shock or (for products fitted with an IC- equipment malfunction do not attempt to make electrical ground compliant modem) connections by yourself. Contact the appropriate inspection authority or an electrician, as appropriate. The Industry Canada label identifies certified equipment.
- Page 35 Samsung Electronics Suzhou Computer CO., No. 198, Fangzhou Road, Suzhou Industrial Park, Jiangsu Province, 215021, China Tel:+86-512-6253-8988 For the web or the phone number of Samsung Service Centre, see the Warranty or contact the retailer where you purchased your product.
- Page 36 European Radio Approval Information (for products fitted with EU-approved radio devices) This Product is a Notebook computer; low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4GHz/5GHz band, may be present (embedded) in your notebook system which is intended for home or office use.
- Page 37 Hereby, Samsung, declares that this Notebook PC is in compliance with English the essential requirements and other relevant provisions of Directive 1999/5/EC. Por medio de la presente Samsung declara que el Notebook PC cumple Español con los requisitos esenciales y cualesquiera otras disposiciones aplicables [Spanish] o exigibles de la Directiva 1999/5/CE.
- Page 38 överensstämmelse med de väsentliga egenskapskrav och övriga [Swedish] relevanta bestämmelser som framgår av direktiv 1999/5/EG. Íslenska Hér með lýsir Samsung yfi r því að Notebook PC er í samræmi við [Icelandic] grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC. Norsk Samsung erklærer herved at utstyret Notebook PC er i samsvar med de...
- Page 39 European Economic Area General Restrictions European standards dictate maximum radiated transmit power of 100 mW effective isotropic radiated power (EIRP) and the Local Restriction of 802.11b/802.11g Radio frequency range 2400 – 2483.5 MHz. Usage The low band 5.15 - 5.35 GHz is for indoor [Note to integrator: The following statements use only.
- Page 40 European Telecommunication This equipment has been approved to Council Decision 98/482/EEC - “CTR 21” for Pan- Information (for products fitted with European single terminal connection to the EU-approved modems) Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different Marking by the symbol indicates...
-
Page 41: Weee Symbol Information
This Perchlorate warning applies only to primary CR (Maganese Dioxide) Lithium coin cells in the product sold or distributed ONLY in California USA. “Perchlorate Material- special handling may apply, See www.dtsc.ca.gov/hazardouswaste/ perchlorate.” Contains Mercury, Dispose According to Local, State or Federal Laws. For details see lamprecycle.org, eise.org, or call 1-800-Samsung. -
Page 42: Basic Items
The items included in the package may vary depending on your selection of the optional items. Some items may be replaced with similar products and the color of some items may differ from that in this document. N128 N138 Computer... -
Page 43: Overview
Optional items may be changed or may not be provided depending on the computer model. The actual color and appearance of the computer may differ from the pictures used in this guide. Front View (N128) (N138) Camera Lens (Optional) Using this lens, you can take still pictures and record video. Keyboard A device to enter data by pressing the keys. -
Page 44: Status Indicators
Status Indicators (N128) (N138) Caps Lock This turns on when the Caps Lock key is pressed allowing capital letters to be typed without holding the Shift button down. Hard Disk Drive Indicates that the hard disk drive is running. Wireless LAN This turns on when the wireless LAN is operating. -
Page 45: Right View
Right View (N128) (N138) You can connect USB devices to the USB port such as a keyboard/ USB Port mouse, digital camera, etc. You can connect a Kensington lock to the Security Lock Port to Security Lock Port prevent the computer from being stolen. -
Page 46: Left View
Charging a device through a Chargeable USB takes longer than using a regular charger. Press the F2 key when the Samsung logo appears in the booting sequence to enter the BIOS Setup, select Advanced > USB Charge In Sleep Mode, and set it to Enable. -
Page 47: Back View
Back View (N128) (N138) Battery This is a Lithium-Ion rechargeable battery that supplies power to the computer. Bottom View (N128) (N138) Battery Latches The latch used to remove or install the battery. Memory Compartment Cover The main memory is installed inside the cover. -
Page 48: Turn On The Computer
Turn on the computer Attaching the Battery Battery preparation. Attaching the Battery. Connect the AC adapter Connect the AC adapter. Connect the power cable. Power AC Adapter Cable DC-in Jack Charge the battery fully when using the computer for the first time. ... -
Page 49: Turn On The Computer
Turn on the computer Charge the battery fully when using the computer for the first time. Lift up the LCD panel. Slide the Power Switch to turn the computer on. Press the Fn+ key to increase the LCD brightness. You can only use this function after installing Windows XP and installing the Easy Display Manager program with the system software media disk. -
Page 50: Using Sleep Mode
Using Sleep Mode You can use the Sleep mode after installing Windows XP. Sleep mode enables switching the computer to Standby mode in order to minimize power consumption and enables users to use the computer instantly by pressing any key on the mouse or keyboard. - Page 51 Chapter 2. Using the computer Keyboard Touchpad CD Drive (ODD, Optional) Connecting the CD Drive Inserting and Ejecting a CD Multi Card Slot Adjusting the Volume...
-
Page 52: Keyboard
CRT/LCD external monitor (or TV) is connected to the computer. Backlight Turns the LCD backlight on or off. Mute Mutes or cancels mute. Samsung System diagnosis, recovery and Internet consultation program, Samsung Magic Doctor Magic Doctor, will be launched. (Optional) - Page 53 Name Function You can select operation mode when you need maximum system performance or low-noise/low power consumption with one-click. Silent: Low-noise and low power consumption mode Normal: Normal Mode Speed: Maximum performance mode. The system operates in its maximum performance, and system resources are allocated to the currently active program with priority for maximum performance.
-
Page 54: Volume Control
Screen Brightness Control To adjust the LCD brightness press the Fn + key combination or the Fn + combination. The changed screen brightness is displayed at the center of the screen for a moment. You can use the screen brightness control keys after installing Windows and Easy Display Manager. -
Page 55: Touchpad
Touchpad The touchpad provides the same function as a mouse and the left and right buttons of the touchpad plays the role of the left and right buttons of a mouse. Before You Start! Use the Touchpad with your fingers. Using a sharp object may damage the ... -
Page 56: Cd Drive (Odd, Optional)
CD Drive (ODD, Optional) An optical disk drive is optional and may differ depending on your computer model. For detailed specifications, refer to the catalogue. Do not insert a cracked or scratched CD. Otherwise, the CD may break and damage the optical disk drive when the CD rotates at a high speed. -
Page 57: Inserting And Ejecting A Cd
Inserting and Ejecting a CD Press the Eject button of the CD drive. Status Indicator Emergency Hole Eject Button When the CD tray opens, insert a CD or DVD and push the tray in until it clicks. Push the CD tray inward until it clicks. The CD drive status indicator is turned on. A CD drive’s reading and writing speed may differ depending on the condition and type of the media. To eject a CD when the CD drive does not work or the computer is off, place the end of a paper clip ) into the Emergency Hole until the CD tray is ejected. -
Page 58: Multi Card Slot
Multi Card Slot Using the multi card slot, you can read and write data to a SDHC, MMC and SD card. You can use a card as a removable disk and conveniently exchange data with digital devices such as a digital camera, digital camcorder, MP3, etc. You can only use it after installing Windows XP. - Page 59 If the card includes data, backup the data However, depending on the before formatting it. adapter’s body material, some RS- MMC cards may not be recognized properly. Samsung recommends Click Start > My computer. checking the card is recognized correctly prior to purchasing. Right-click over a card drive with the touchpad and select Format.
-
Page 60: Adjusting The Volume
Adjusting the Volume You can adjust the volume using the keyboard and the volume control program. Adjusting the Volume using the For advanced volume control options, double-click the Volume icon , and Keyboard adjust the volume level in the volume control program. -
Page 61: Upgrade
Chapter 3. Settings and Upgrade LCD Brightness Control BIOS Setup Entering the BIOS Setup The BIOS Setup Screen Setting a Boot Password Changing the Boot Priority Upgrading Memory Battery Installing/Removing the Battery Charging the Battery Measuring the Remaining Battery Charge Extending the Battery Usage Time Using the Security Lock Port... -
Page 62: Lcd Brightness Control
To maintain the LCD brightness set by using the brightness control keys or through the Power Options, follow the procedures below. 1. Turn the computer on and press the F2 key when the SAMSUNG logo appears on the screen to enter the BIOS Setup. -
Page 63: Bios Setup
The BIOS Setup menus and items may differ depending on your computer model. Entering the BIOS Setup Turn the computer on. When the booting screen (SAMSUNG logo) appears, press the F2 key to enter the BIOS Setup. Press the F12 key while the booting screen(SAMSUNG logo) appears, the system will try to boot from the network. -
Page 64: The Bios Setup Screen
After a moment, the BIOS setup screen appears. The items in the BIOS setup may differ depending on the product. Setup Menu Help System Time [10:21:53] Help for the selected item System Date [07/30/200X] appears automatically. IDE Channel 0 Master XXXXXXXX CPU Type XXXXXXXX CPU Speed X.XX GHz Total Memory XXX MB Graphics Memory [Auto : Shared] BIOS Version XXXXXXXX MICOM Version XXXXXXXX... - Page 65 System Setup Keys In the Setup, you have to use the keyboard. Press to view the Setup Help. Up & Down Keys Press to move up and down. F5/F6 Press to change the item value. Press to load the default Setup settings. Press to return to a higher level menu or to move to the Exit menu.
-
Page 66: Setting A Boot Password
Before You Start! Do not lose or forget your password. If you have forgotten your password, contact a Samsung service center. In this case, a service fee will be charged. Setting a Supervisor Password Enter a password, press <Enter>, re-... - Page 67 Setting Up a Boot Password Before configuring a user password, a supervisor password must have been configured. Deactivating the supervisor To setup a boot password, the administrator password also deactivates the user password (Set Supervisor Password) should password. be set in advance. In the Set User Password item, press Set the Password on boot item to Enabled.
-
Page 68: Changing The Boot Priority
Changing the Boot Priority This computer is configured to boot from an external-type ODD first. This chapter describes how to change the boot priority so that the computer boots from the hard disk drive first. Select the Boot menu in the BIOS Press the down key (↓) to move to the Setup. IDE HDD item and press the F6 key to move the item to the top. -
Page 69: Upgrading Memory
Upgrading Memory A memory is installed in the memory slot at the bottom of this computer. The procedures to replace the memory are described below. Before You Start! Replace new memory only after shutting the computer down completely. Do not replace memory when the computer is in Sleep mode. - Page 70 Insert a new memory module into Push the memory module down so that the memory slot at an angle of it is completely fixed. If the memory approximately 30 degrees aligning it to does not fit easily, push the memory the angle of the memory slot. module down while pulling the memory module latches outward. Close the memory compartment cover and fasten the screw. Memory Slot...
-
Page 71: Battery
Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. A Lithium-Ion smart battery is supplied with this computer. Before You Start! Carefully read and follow the precautions printed on the battery before using the battery. Precautions Use only chargers specified in the User Manual. -
Page 72: Charging The Battery
To install the battery again, slide the Charging the Battery battery into the system. The battery latches move inwards and fix the battery automatically. Attach the battery and connect the AC adapter to the DC-in jack of the computer. The battery will then start charging. When charging is complete, the Charge LED turns red. Status Charge LED Charging Amber Charging complete Green Check if the battery latch has been AC adapter not moved inwards. connected Measuring the Remaining Battery Charge You can view the battery charge status by completing the following procedures. -
Page 73: Extending The Battery Usage Time
In this case, the actual battery charge and the remaining charge display will be the same by discharging the battery completely using the Battery Calibration function, and then recharging it again. Disconnect the AC power adapter after turning off the computer. Restart your computer and press the F2 button when the Samsung logo appears, to start the BIOS Setup. - Page 74 Move to the Boot > Smart Battery Calibration item using the direction keys and press <Enter>. Highlight Yes in the Battery Calibration Confirmation window and press <Enter>. The Battery Calibration function is activated and the battery is forcefully discharged. To stop the operation, press the (Esc) button. This operation requires 3~5 hours depending on the battery capacity and the remaining battery charge.
-
Page 75: Using The Security Lock Port
Using the Security Lock Port You can connect a Kensington lock to the Security Lock port to prevent your computer from being stolen when you have to use the computer in a public place. To use this feature, you have to purchase the Kensington lock additionally. To use the Kensington lock, refer to the product manual. -
Page 77: Chapter 4. Appendix
Chapter 4. Appendix Product Specifi cations... -
Page 78: Product Specifications
Product Specifications The system specifications may differ depending on the derived models. For detailed system specifications, refer to the product catalogue. NP-N128/N138 Intel ATOM™ Processor Main Memory Memory type: DDR2 SODIMM Main Chipset INTEL 945GSE + ICH7-M Hard Disk Drive (Optional) 9.5mmH SATA HDD... - Page 79 Microsoft, MS-DOS, and Windows are registered trademarks of the Microsoft Corporation. All other product or company names mentioned herein are registered trademarks of their respective companies. ENERGY STAR® Partner As an ENERGY STAR® Partner, SAMSUNG has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
