Eiki LC-XL200A Specifications

LC-XL200A
6,000 ANSI lumens bright with 90% uniformity and a 2000:1 contrast ratio.
Native XGA resolution. Compatible with inputs up-to UXGA and WUXGA.
Supports analog and digital video input in all color standards up-to 1080p.
Durable inorganic 3-panel LCD imaging engine with a high contrast ratio.
10-bit color processing, for superior color reproduction.
Power zoom and focus lens. Optional wide-angle and telephoto lenses.
Vertical and Horizontal power lens shift and digital keystone correction.
Includes a full set of analog and digital computer and video inputs.
Built-in 7 Watt amplifier and speaker system. Closed Caption decoding.
Wired LAN connection for monitoring and control. Optional PjNet interface.
Self-advancing cartridge air filter provides up-to 13,000 hours use.
Centered lens with 1-button release. Top-accessed lamp, side-accessed filter.
Variable power management option. Optional local or remote keylock.
Mechanical shutter for true black screen. Corner keystone correction.
Wireless/wired remote with mouse control.
3 year projector warranty.
Included Accessories:
Quick Start Guide, Owner's Manual on CD-ROM, VGA Computer Input Cable (Dsub15 to Dsub15), 10 ft (3 m) Detachable Power Cord,
Wireless Remote Control (with 2 AAA Batteries), Network Software on CD-ROM, Lens Cover, USB Cable for Computer Mouse Control.
Optional Accessories:
Replacement Lamp, Wideangle, Midrange and Telephoto Lenses, ATA-Style Shipping Case with Wheel and Telescoping Handle,
PjNet Network Interface, Ceiling Mount, Ceiling Post and Plate.
Brightness
Contrast Ratio
Illumination Uniformity
Resolution and Aspect Ratio
Color Reproduction p
Projection Lamp
Estimated Lamp Life
Total Pixels
Imaging System
Scanning Frequency
Pixel Clock
Lens
Lens Specs
Lens Ratios
Image Diagonal
Image Width
Throw Distance
Projector Elevation Adjustment (legs)
Maximum Pitch
Vertical Lens Shift (% of image height)
Horizontal Lens Shift (% of image height)
Vertical Keystone Correction
Horizontal Keystone Correction
Image Orientation
Local Control / Power Management
Remote Control
Wired Remote Control
Mouse Port
RS-232 Control
LAN Port
Optional Network Interface Port
Computer Input in Pixels
Analog 4x3 Inputs
Analog Wide Inputs
Digital 4x3 Inputs
Digital Wide Inputs
Video Formats
Video Input Analog
Video Input Digital
Image Signal Resizing
6,000 ANSI Lumens
(with standard AH-24741 lens)
XGA (1024x768), 4:3
10-bit (1.07 billion colors)
2,359,296 (1024x768) x 3
0.8 in (20 mm) Inorganic LCD Panels x 3
Auto: H Sync. 15-100 kHz, V Sync. 48-100 Hz
230 MHz Analog, 162 MHz DVI-D
Changeable - Power Zoom and Focus
Speed: f : 1.7-2.3; FL: 1.06-1.78 in (26.9-45.4 mm)
Zoom Max:Min: 1.7:1; Throw:Width 1.7-2.89:1
40-400 in (102-1,016 cm)
2.67-26.7 ft (0.81-8.1 m)
4.3-75.1 ft (1.3-22.9 m)
up-to 4° Up or Down
up-to 50% Up or Down
up-to 10% Left or Right
Digital: up-to 40° Up or Down
Digital: up-to 20° Left or Right
Normal, Reversed, Inverted
Full Function / Auto Shutdown
up-to 1600x1200 (4:3), 1920x1200 (16:10)
UXGA, SXGA+, SXGA, XGA, SVGA, VGA, MAC
WUXGA, WSXGA, WXGA
UXGA, SXGA+, SXGA, XGA, SVGA, VGA, MAC
WUXGA, WSXGA+, WSXGA, WXGA+, WXGA
NTSC / PAL / SECAM / NTSC 4.43 / PAL-M&N
480i/p, 575i/p, 720p, 1035i, 1080i/p
480p, 575p, 720p, 1035i, 1080i/p
Smart Scaling Technology
Lamp contains Mercury. Do not put in trash. Dispose of as Hazardous Waste, according to Local, State or Federal Laws.
EIKI® is a registered trademark of Eiki International Inc. Kensington is a registered trademark of ACCO Brands Corporation.
Crestron Roomview is a registered trademark of Creston Electronics, Inc.
Specifications subject to change without notice. ©2013 Eiki International Inc. Issued Nov. 12, 2013
Eiki International Inc., 30251 Esparanza, Rancho Santa Margarita, CA 92688-2132. Tel: 800-242-3454; Fax: 800-457-3454, Email: usa@eiki.com
In Canada: 310 First St., Unit 2, P.O. Box 156, Midland ON L4R 4K8. Tel: 800-563-3454, Fax: 800-567-4069, Email: canada@eiki.com
Specifications: Model LC-XL200A
Image Signal Inputs
2000:1 1a: Analog Computer
90% 1b: Digital Computer / Digital Video w/ HDCP
2: Analog Computer (RGBHV)
( ) Component Video, 3BNC p
330 Watts NSHA Composite Video, 1BNC
up-to 3,000 hours 3a: Component Video
Composite Video, 1RCA
3b: S-Video
Audio Signal Inputs
For Inputs 1 & 2
For Input 3
Outputs
Computer Monitor
Audio Output
Amplifier
Speaker
Fan Noise
up-to 360° Cabinet Size (HxWxD) - LC-XL200A
Cabinet Size (HxWxD) - LC-XL200AL
Weight - LC-XL200A
Weight - LC-XL200AL
Packaged Cabinet Size (HxWxD)
Packaged Weight - LC-XL200A
Packaged Weight - LC-XL200AL
Wireless/Wired x 1 Operating Temperature
MiniStereo x 1 Electrical Safety Compliance
USB Type B x 1 Electromagnetic Compatibility
Dsub9 x 1 Power Requirements
RJ45 x 1 Power Consumption
Dsub25 x 1 Heat
Security Facilities
UPC - LC-XL200A
UPC - LC-XL200AL
User Maintenance
Limited Warranty: to the original end use customer only
Projector
Lamp
LC-XL200A
6,000 ANSI Lumens / XGA / 3LCD
"Conference" Series Projector
High Contrast Durable Inorganic LCD Panels
Cost-Effective Large Venue Performance
Crestron RoomView™ & AMX Device Discovery Technology
Also available as LC-XL200AL without standard lens
6.46 x 19.27 x 17.12 in (16.4 x 48.9 x 43.5 cm)
6.46 x 19.27 x 14.61 in (16.4 x 48.9 x 37.1 cm)
12.5 x 26.8 x 22.9 in (31.8 x 68.1 x 58.1 cm)
Dsub15 x 1
DVI-D x 1
BNC x 5
RCA x 3
S-Video x 1
Stereo: MiniStereo x 2
RCA x 2 (L/R)
Dsub15 x 1
Variable, Stereo: MiniStereo x 1
Mono: 7 Watt
1.46 in (3.7 cm) x 1 (Mono)
as low as 31 dBA
21.6 lb (9.8 kg)
19.8 lb (9.0 kg)
35.0 lb (15.9 kg)
33.3 lb (15.1 kg)
41-95°F (5-35°C)
IEC / UL / cUL
FCC Class B, CE Mark
100-240V AC, 50/60 Hz
0.4 W in Eco Standby mode, up-to 490 W
up-to 1,672 BTU/hr
Kensington® Security Slot
4571194676082
4571194676204
Replace Filter Cartridge, Replace Lamp
*3 years / 6000 hours
*6 month ownership / 500 hours use
*(whichever occurs first)
