- Page 1 S E R V I C E I0500097 IPL, CTH172, 2005-04, 544 08 58-01 96061000501 CTH172 Spare parts Ersatzteile Pièces détachées Reserve onderdelen Repuestos Reservdelar 544 08 58-01...
-
Page 2: Wheels And Tires
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 DECALS MAX + _ 90N MAX + _ 150N PART PART DESCRIPTION DESCRIPTION 532 14 54-98 Decal Read Owner’s Manual Sym 532 15 97-36 Decal Chassis Hot Muffl er... - Page 3 TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 SCHEMATIC 12VDC STARTER AMMETER BATTERY SOLENOID (OPTIONAL) STARTER FUSE 15 AMP WHITE BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ATT'MENT CLUTCH (PEDAL UP) (CLUTCH OFF) GREEN OPERATOR PRESENCE RELAY...
- Page 4 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 ELECTRICAL...
-
Page 5: Repair Parts
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 ELECTRICAL PART DESCRIPTION 532 14 49-27 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock 532 17 56-88 Harness Asm Light W/4152J... -
Page 6: Chassis And Enclosures
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 CHASSIS AND ENCLOSURES 26 25 chassis-laser_CRD_8... - Page 7 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 CHASSIS AND ENCLOSURES PART PART DESCRIPTION DESCRIPTION 532 17 46-20 Chassis 532 19 16-11 Screw 10 x 3/4 Single Lead-Hex 532 17 88-62 Backplate CRD 532 18 03-84...
- Page 8 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 DRIVE drive-hydro_CRD_Laser_12...
- Page 9 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Hydro Gear 321-0510 819 09 12-10 Washer 9/32 x 3/4 x 10 Ga. 873 90 06-00 Nut Lock Flg.
-
Page 10: Steering Assembly
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 STEERING ASSEMBLY steering_pl.lt_60... - Page 11 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 STEERING ASSEMBLY PART DESCRIPTION 532 19 36-51 Steering Wheel 532 18 47-06 Front Axle Assembly 532 16 98-40 Spindle Assembly, L.H. 532 16 98-39 Spindle Assembly, R.H. 532 12 49-31...
-
Page 12: Seat Assembly
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 SEAT ASSEMBLY seat_lt.knob_7(CRD) PART PART DESCRIPTION DESCRIPTION 532 18 49-95 Seat 532 12 12-48 Bushing Snap Blk Nyl 50 Id 872 05 04-12 Bolt Rdhd Sht Nk 1/4-20 x 1-1/2... -
Page 13: Optional Equipment
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-kohler_42 PART PART DESCRIPTION DESCRIPTION 532 17 08-05 Control Throt/Ck 532 12 34-87 Clamp Hose Blk 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2... -
Page 14: Mower Lift
REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 MOWER LIFT 17 18 20 lift-rh.1piece_9... - Page 15 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 MOWER LIFT PART DESCRIPTION 532 15 94-60 Washer Asm Inner Spring W/Plunger 532 15 94-71 Shaft Asm. Lift 532 10 57-67 Pin Groove 812 00 00-02 E Ring #5133-62 819 21 16-21 Washer 21/32 x 1 x 21 Ga.
- Page 16 REPAIR PARTS TRACTOR- -MODEL NO. CTH172 (96061000501), PRODUCT NO. 954 17 02-10 MOWER 107cm_deck-elect.(CRD)_2...
