TK-2160/ TK-3160 VHF FM TRANSCEIVER/ UHF FM TRANSCEIVER INSTRUCTION MANUAL...
Page 3
HANK We are grateful you chose KENWOOD for your land mobile radio applications. We believe this easy-to-use transceiver will provide dependable communications to keep personnel operating at peak efficiency. KENWOOD transceivers incorporate the latest in advanced technology. As a result, we feel strongly that you will be pleased with the quality and features of this product.
Page 4
Do not place the transceiver in excessively dusty, humid, and/or wet areas, nor on unstable surfaces. • If an abnormal odor or smoke is detected coming from the transceiver, switch OFF the power immediately and remove the optional battery pack from the transceiver. Contact your KENWOOD dealer.
UNPACKING AND CHECKING EQUIPMENT Note: The following unpacking instructions are for use by your KENWOOD dealer, an authorized KENWOOD service facility, or the factory. Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material.
PREPARATION ATTERY RECAUTIONS ◆ Do not recharge the battery pack if it is already fully charged. Doing so may cause the life of the battery pack to shorten or the battery pack may be damaged. ◆ After recharging the battery pack, disconnect it from the charger. If the charger power is reset (turned ON after being turned OFF), recharging will start again and the battery pack will become overcharged.
Page 9
• Do not incinerate or apply heat to the battery! If the insulator is melted, the gas release vent or safety function is damaged, or the electrolyte is ignited, the battery may generate heat or smoke, rupture, or burst into flame. •...
Page 10
• Do not use the battery pack if it is damaged in any way! The battery may generate heat or smoke, rupture, or burst into flame. • Do not solder directly onto the battery! If the insulator is melted or the gas release vent or safety function is damaged, the battery may generate heat or smoke, rupture, or burst into flame.
Page 11
• Do not charge the battery for longer than the specified time! If the battery pack has not finished charging even after the regulated time has passed, stop it. The battery may generate heat or smoke, rupture, or burst into flame. •...
Page 12
■ Characteristics of the Li-ion Battery Pack • As the battery pack is charged and discharged repeatedly, the battery capacity decreases. • Even if the battery pack is unused, the battery pack degrades. • It takes a longer time to charge the battery pack in cooler areas.
NSTALLING EMOVING THE PTIONAL ECHARGEABLE ATTERY ACK OR LKALINE ATTERY 1 Match the guides of the battery pack with the corresponding grooves on the upper rear of the transceiver, then firmly press the battery pack to lock it in place. 2 Flip the safety catch into place to prevent accidentally pressing the...
NSTALLING EMOVING LKALINE ATTERIES ◆ Do not install batteries in a hazardous environment where sparks could cause an explosion. ◆ Never discard old batteries in fire; extremely high temperatures can cause batteries to explode. ◆ Do not short circuit the battery case terminals. ◆...
NSTALLING THE PTIONAL NTENNA Screw the antenna into the connector on the top of the transceiver by holding the antenna at its base and turning it clockwise until secure. NSTALLING THE Note: When first installing the belt clip, you must remove the battery pack from the rear of the transceiver.
NSTALLING THE OVER OVER THE PEAKER ICROPHONE ACKS Note: When installing the speaker/ microphone jack cover, you must remove the battery pack from the rear of the transceiver. If you are not using a speaker/ microphone, install the cover over the speaker/ microphone jacks using the supplied screw.
GETTING ACQUAINTED Antenna Microphone Speaker The transceiver is shown with the optional KNB-24L battery pack. q q q q q LED indicator Lights red while transmitting. Lights green while receiving. Flashes orange while receiving a 2-Tone, DTMF, or FleetSync signal that matches the one set up in your transceiver.
r r r r r AUX key This is a PF (Programmable Function) key. Press it to activate its auxiliary function (below). The default setting for this key is None. t t t t t PTT (Push-to-Talk) switch Press this switch, then speak into the microphone to call a station.
OPERATING BASICS ON/ OFF WITCHING OWER Turn the Power switch/ Volume control clockwise to switch the transceiver ON. Turn the Power switch/ Volume control counterclockwise to switch the transceiver OFF. DJUSTING THE OLUME Rotate the Power switch/ Volume control to adjust the volume. Clockwise increases the volume and counterclockwise decreases it.
AKING A 1 Make sure no parties are currently transmitting on your selected channel. 2 Press the PTT switch and speak into the microphone in your normal speaking voice. • For best sound quality at the receiving station, hold the microphone approximately 1.5 inches (3 ~ 4 cm) from your mouth.
SCAN Scan is useful for monitoring signals on the transceiver channels. When scanning, the transceiver checks for a signal on each channel and only stops if a signal is present. The transceiver will remain on a busy channel until the signal is no longer present.
EMPORARY HANNEL OCKOUT During Scan, if a key is programmed with the Scan Temporary Delete function, you can temporarily remove specific channels from the scanning sequence during Scan. When Scan stops at a channel, you can remove that channel from the scanning sequence by pressing the Scan Temporary Delete key.
2-TONE SIGNALLING 2-Tone Signalling is enabled or disabled by your dealer. This function opens the squelch only when the transceiver receives the two tones programmed in your transceiver, in succession. Transceivers that do not transmit the correct tones will not be heard.
DTMF SIGNALLING DTMF Signalling is either enabled or disabled by your dealer. This function opens the squelch only when the transceiver receives the DTMF code (3 to 10 digits) programmed in your transceiver. Each transceiver is normally programmed with a unique code.
FleetSync™ OPERATION FleetSync™ is a protocol owned by KENWOOD Corporation and is enabled or disabled by your dealer. This function opens the squelch only when the transceiver receives the Fleet code and ID code programmed in your transceiver. Calls that do not contain the correct codes will not be heard.
® SmarTrunk II OPERATION Note: SmarTrunk and SmarTrunk II are registered trademarks of SmarTrunk Systems, Inc., Hayward, California, U.S.A. Your dealer may set up some groups to operate using the SmarTrunk OMNI system or the SmarTrunk II system. An appropriate trunking board must be installed in order to access Trunking mode.
QUIET TALK (QT)/ DIGITAL QUIET TALK (DQT) Your dealer may have programmed QT or DQT signalling on your transceiver channels. A QT tone/DQT code is a sub- audible tone/code which allows you to ignore (not hear) calls from other parties who are using the same channel. When a channel is set up with a QT tone or DQT code, squelch will only open when a call containing a matching tone or code is received.
SCRAMBLER Whereas the Quiet Talk and Digital Quiet Talk functions (page 21) allow you to ignore unwanted calls, Scrambler allows you to hold a conversation in complete privacy. When activated, any other party listening in on your channel will be unable to understand your conversation.
VOX OPERATION VOX can be activated or deactivated by your dealer. VOX operation allows you to transmit hands-free. This feature can only be used if you are using a supported headset. When operating VOX, you must set a VOX Gain level. This setting allows the transceiver to recognize sound levels.
Page 30
To turn VOX operation OFF, enter the VOX Gain level setting (step 2, above) and press the PTT switch, then turn the transceiver power OFF and then ON again. Note: ◆ If a speaker/microphone is connected to the transceiver while the VOX function is switched ON and the VOX Gain Level is configured to a higher, more sensitive level, louder received signals may cause the transceiver to start transmission.
EMERGENCY CALLS If your transceiver has been programmed with the Emergency function, you can make emergency calls. Note: Only the AUX key can be programmed with the Emergency function. 1 Press and hold the key programmed as Emergency. • Depending on the delay time programmed into your transceiver, the length of time you must hold the Emergency key will vary.
ADVANCED OPERATIONS ELECTING AN UTPUT OWER Each channel is programmed with either high or low output power by your dealer. You can change the output power of only channels programmed as high. When you can reliably communicate with other parties without using high power, select low power by pressing the key programmed as RF Power Low.
BACKGROUND OPERATIONS Your dealer can activate a variety of transceiver functions to perform without any additional operation on your part. (TOT) IMER The Time-out Timer is used to prevent any caller from using a channel for an extended period of time. If you continuously transmit for a period of time that exceeds the programmed time (default = 60 seconds), the transceiver will stop transmitting and an alert tone will sound.
ATTERY ARNING Low Battery Warning alerts you when the battery needs to be recharged or replaced. While transmitting or receiving, the LED will blink red when the battery power is low. If programmed by your dealer, a tone may also sound. (BCL) HANNEL OCKOUT...
Page 35
TK-2160/TK-3160 VHF FM 트랜시버/UHF FM 트랜시버 사용 설명서...
Page 36
감사합니다 감사합니다 감사합니다 감사합니다! 본 KENWOOD 육상 모바일 무선 장비를 선택해주셔서 감사합 니다. 본 트랜시버는 사용이 편리하며, 개인이 사용했을 때 효율 성을 극대화 시킬 수 있도록 설계되었습니다. KENWOOD 트랜시버는 최신의 발전된 기술을 자랑합니다. 따 라서 본 제품의 품질과 기능에 반드시 만족하실 것입니다.
Page 37
구 근처에 두지 마십시오. 과도하게 먼지가 쌓인 곳, 습하거나 젖은 곳 또는 표면이 울 • 퉁불퉁한 곳에 트랜시버를 두지 마십시오. 트랜시버에서 이상한 냄새나 연기가 나면, 즉시 전원을 끄고 • 배터리 팩 (옵션) 을 분리하십시오. 그런 다음 KENWOOD 판매 업체에 연락하십시오.
Page 38
목차 목차 목차 목차 목차 장비 확인 ..............1 부속품 ..............1 사전 준비 ..............2 배터리 팩에 관한 주의사항 ......... 2 충전용 배터리 팩 (옵션) 또는 알카라인 배터리 케이스 장착/분리 ..........7 알카라인 배터리 장착/분리 ......... 8 안테나 (옵션) 장착 ..........9 벨트...
Page 39
DTMF 신호 ............18 작동 ............ 19 ™ FleetSync 수신 ..............19 송신 ..............19 작동 ..........20 ® SmarTrunk II QUIET TALK (QT)/DIGITAL QUIET TALK (DQT) ..21 스크램블러 ............22 VOX 작동 ............... 23 비상 호출 ............... 25 고급...
Page 40
확인 확인 장비 장비 확인 주의 주의: 다음의 포장을 풀 때의 지침은 KENWOOD 판매처, 승인된 주의 주의 주의 KENWOOD 서비스 센터나 공장에서 사용하기 위한 것입니다. 트랜시버의 포장을 조심스럽게 푸십시오. 포장재를 버리기 전에 아래 표에 나열된 항목을 확인하시기 바랍니다. 표에 있는 항목...
Page 41
사전 사전 사전 준비 준비 준비 준비 사전 사전 준비 배터리 배터리 팩에 팩에 관한 관한 주의사항 주의사항 배터리 배터리 팩에 배터리 팩에 팩에 관한 관한 관한 주의사항 주의사항 주의사항 ◆ 배터리 팩이 완전히 충전되어 있는 경우, 재충전하지 마십시오. 배 터리...
Page 42
배터리를 배터리를 소각하거나 소각하거나 가열하지 가열하지 마십시오 마십시오 배터리를 배터리를 소각하거나 배터리를 소각하거나 소각하거나 가열하지 가열하지 가열하지 마십시오 마십시오 마십시오! • 절연체가 녹을 때, 가스 배출구 또는 안전 기능에 손상이 오거나 전해질이 발화 할 수 있습니다. 또한 배터리가 과열 또는 파열되거 나...
Page 43
배터리가 배터리가 배터리가 조금이라도 조금이라도 조금이라도 조금이라도 손상된 손상된 손상된 손상된 경우 경우 경우 경우 사용하지 사용하지 사용하지 사용하지 마십시오 마십시오 마십시오! 마십시오 배터리가 배터리가 조금이라도 손상된 경우 사용하지 마십시오 • 배터리가 과열 또는 파열되거나 연기 또는 불꽃이 일어날 수 있습 니다.
Page 44
지정된 지정된 시간 지정된 시간 시간 보다 시간 보다 보다 오래 보다 오래 오래 배터리를 오래 배터리를 배터리를 배터리를 충전하지 충전하지 충전하지 마십시오 충전하지 마십시오 마십시오! 마십시오 지정된 지정된 시간 보다 오래 배터리를 충전하지 마십시오 • 규정 시간이 지났는데 배터리 팩의 충전이 완료되지 않았다 하더 라도...
Page 45
■ 리튬 리튬 리튬 이온 리튬 이온 이온 이온 배터리 배터리 배터리 배터리 팩의 팩의 팩의 팩의 특성 특성 특성 특성 리튬 이온 배터리 팩의 특성 배터리 팩이 충전과 방전을 반복할수록 배터리 성 • 능이 떨어집니다. 배터리 팩을 사용하지 않더라도, 배터리 팩의 성능 •...
Page 46
충전용 충전용 충전용 배터리 배터리 배터리 팩 팩 팩 팩 팩 ( 옵션 배터리 옵션 옵션 옵션) 또는 또는 또는 알카라인 또는 알카라인 알카라인 배터리 알카라인 배터리 배터리 배터리 충전용 충전용 배터리 옵션 또는 알카라인 배터리 케이스 케이스 장착 장착 분리...
Page 47
알카라인 알카라인 배터리 배터리 장착 장착 분리 분리 알카라인 알카라인 배터리 알카라인 배터리 배터리 장착 장착 장착/ 분리 분리 분리 ◆ 불꽃이 튈 수 있는 위험한 환경에서 배터리를 장착하지 마십시오. ◆ 다 쓴 배터리를 소각하지 마십시오. 높은 온도 때문에 배터리가 폭 발할...
Page 48
안테나 안테나 ( 옵션 안테나 옵션 옵션) 장착 옵션 장착 장착 장착 안테나 안테나 옵션 장착 안테나의 밑 부분을 잡고 시계 방향으로 끝까지 돌려, 트랜시버 상단에 위치한 연결부에 단단히 조이십시오. 벨트 벨트 클립 벨트 클립 클립 클립 장착 장착 장착 장착...
Page 49
스피커 스피커/ 마이크 스피커 마이크 마이크 마이크 잭 잭 잭 잭 잭 커버 커버 커버 장착 커버 장착 장착 장착 스피커 스피커 마이크 커버 장착 주의 주의 주의: 스피커/마이크 잭 커버를 장착할 경우, 트랜시버 뒤쪽의 배터리 주의 주의 팩을 분리해야 합니다. 스피커/마이크를...
Page 50
익숙해지기 익숙해지기 익숙해지기 익숙해지기 익숙해지기 안테나 마이크 스피커 그림의 트랜시버에는 KNB-24L 배터리 팩 (옵션) 이 장착되어 있습니다. 표시등 표시등 q q q q q LED 표시등 표시등 표시등 송신 중에는 붉은색이 점등 되며, 수신 중에는 녹색이 점등 됩니다. 트랜시버에 설정된 2-톤, DTMF 또는 FleetSync 신호 를...
Page 51
r r r r r AUX 키 키 키 키 키 본 키는 PF (Programmable Function, 설정 가능한 기능) 키입 니다. 보조 기능을 활성화 하려면 이 키를 누르십시오. 기본 설정은 없음 으로 되어 있습니다. 스위치 스위치 t t t t t PTT (Push-to-Talk) 스위치 스위치...
Page 52
기본 기본 작동 기본 작동 작동 작동 기본 기본 작동 전원 전원 켜기 전원 켜기 켜기 켜기/ 끄기 끄기 끄기 끄기 전원 전원 켜기 끄기 전원 전원 스위치/볼륨 전원 볼륨 볼륨 볼륨 컨트롤을 시계 방향으로 돌려서 트랜시버를 전원 전원 볼륨 켜십시오.
Page 53
호출하기 호출하기 호출하기 호출하기 호출하기 1 선택한 채널에서 현재 아무도 통신하고 있지 않음을 확인합 니다. 2 PTT 스위치를 누르고 보통 목소리 크기로 말하십시오. 수신 스테이션에서 최고의 음질을 수신하려면, 입에서 마이크 • 를 약 3~4cm 떨어뜨리고 말하십시오. 3 PTT 스위치를 놓으면 수신이 시작됩니다. 수신하기...
Page 54
스캔 스캔 스캔 스캔 스캔 스캔은 트랜시버 채널의 신호를 모니터할 때 유용합니다. 스캔 시 트랜시버는 각 채널의 신호를 점검하며, 신호가 존재할 경우 에만 멈춥니다. 트랜시버는 신호가 없어질 때까지, 교신 중인 채널에 고정됩니 다. 신호 드롭-아웃과 스캔 재개 사이의 딜레이 시간은 판매 업 체에서...
Page 55
임시 임시 채널 임시 채널 채널 채널 록아웃 록아웃 록아웃 록아웃 임시 임시 채널 록아웃 스캔 시, 스캔 임시 삭제 기능이 설정된 키가 있다면, 스캔 도중 에 특정 채널을 스캔하지 않도록 임시로 설정할 수 있습니다. 특 정 채널에서 스캔이 중단될 경우, 스캔 스캔...
Page 56
2- 톤 톤 톤 톤 톤 신호 신호 신호 신호 신호 2-톤 신호은 판매 업체에서 활성화 또는 비활성화 해 놓았을 수 있습니다. 트랜시버가 자신 안에 프로그램된 2 개의 톤을 연속으 로 수신할 경우에만 스퀄치가 열립니다. 해당 톤을 송신하지 않 는 트랜시버는 들리지 않습니다. 판매...
신호 신호 신호 DTMF 신호 신호 DTMF 신호는 판매 업체에서 활성화 또는 비활성화 합니다. 트랜 시버가 자신 안에 프로그램된 DTMF 코드 (3 에서 10 자리 숫자) 를 수신할 경우에만 스퀄치가 열립니다. 일반적으로 각 트랜시버 에는 고유한 코드가 프로그램 되어 있습니다. 따라서 프로그램된 코드가...
작동 작동 FleetSync™ 작동 작동 FleetSync™ 는 KENWOOD Corporation 의 프로토콜로써, 판매 업체에서 활성화 또는 비활성화 해 놓을 수 있습니다. 트랜시버 가 자신 안에 프로그램된 Fleet 코드와 ID 코드를 수신할 경우에 만 스퀄치가 열립니다. 해당 코드가 포함되지 않은 호출은 들리...
작동 작동 작동 작동 작동 ® SmarTrunk II 주의 주의: SmarTrunk 및 SmarTrunk II 은 SmarTrunk Systems, Inc., Hayward, 주의 주의 주의 California, U.S.A. 의 등록 상표입니다. 판매 업체에서 SmarTrunk OMNI 시스템 또는 SmarTrunk II 시스 템을 사용해 몇몇 그룹을 설정할 수 할 수 있습니다. 트렁킹 모드 를...
QUIET TALK (QT)/DIGITAL QUIET TALK (DQT) 판매 업체에서 트랜시버 채널에 QT 또는 DQT 신호를 설정해 놓 았을 수 있습니다. QT 톤/DQT 코드는 같은 채널을 사용하는 다 른 상대방의 호출을 무시 (듣지 않음) 할 수 있도록 해주는 가청 치 (들을 수 있는 음량) 이하의 톤/코드입니다. QT 톤...
스크램블러 스크램블러 스크램블러 스크램블러 스크램블러 QT (Quiet Talk) 및 DQT (Digital Quiet Talk) 기능 (페이지 21) 을 사용하여 원치 않는 호출을 무시할 수 있는 반면, 스크램블러 기 능은 완벽하게 보안을 유지할 수 있게 해줍니다. 이 기능을 작동 시키면, 교신 시 여러분의 채널에 있는 다른 모든 상대방은 교신 내용을...
작동 작동 작동 VOX 작동 작동 VOX 는 판매 업체에서 활성화 또는 비활성화 할 수 있습니다. VOX 를 사용하면 핸즈프리로 송신이 가능합니다. 이 기능은 지 원되는 헤드셋을 사용할 경우에만 가능합니다. VOX 작동 시 VOX 게인 레벨을 설정해야 합니다. 이 설정으로 트랜시버는...
Page 63
VOX 작동을 끄려면, VOX 게인 레벨 설정 (위의 단계 2 참조) 을 입력하고 PTT 스위치를 누른 다음, 트랜시버의 전원을 껐다가 다시 켜십시오. 주의 주의: 주의 주의 주의 ◆ VOX 기능이 작동 중이고 VOX 게인 레벨이 더욱 민감한 레벨로 설정된 경우, 스피커/마이크가 트랜시버에 연결되어 있다면, 조금 큰...
Page 64
비상 비상 호출 호출 비상 호출 호출 비상 비상 호출 트랜시버에 비상 기능이 설정된 경우, 비상 호출을 할 수 있습니 다. 주의 주의: 비상 기능은 AUX 키에만 설정할 수 있습니다. 주의 주의 주의 비상 비상으로 설정된 키를 누르시고 떼지 마십시오. 비상...
Page 65
고급 고급 작동법 작동법 고급 고급 작동법 고급 작동법 작동법 출력 출력 파워 파워 선택하기 선택하기 출력 출력 파워 출력 파워 파워 선택하기 선택하기 선택하기 판매 업체에서는 각 채널의 출력 파워를 하이나 로우로 설정할 수 있습니다. 그러나 여러분은 하이로 설정된 채널의 출력 파워 만을...
배터리 배터리 부족 배터리 부족 부족 부족 경고 경고 경고 경고 배터리 배터리 부족 경고 배터리 부족 경고는 사용자가 배터리를 재충전 또는 교체해야 할 경우 나타납니다. 송신 또는 수신 시 배터리가 부족할 경우 LED 가 붉은색으로 깜박입니다. 판매 업체에서 설정한 경우, 경 고음이...
熟悉本機 天線 麥克風 揚聲器 圖中所示對講機裝有 KNB-24L 電池組。 q q q q q LED 指示燈 發射時閃紅光。接收時閃綠光。 在接收與本機設定一致的雙音、DTMF 或 FleetSync 信號 時,閃橘黃色光。如果經銷商編入程式,在電池不足而進行 發射時,閃紅光。 w w w w w 選擇頻道 轉動按鈕來選擇 1 號至 16 號頻道。 e e e e e 電源開關/音量控制旋鈕 按順時針方向轉動它,打開對講機。繼續轉動來調整音量。 要關閉對講機時,按逆時針方向旋轉到底。...
r r r r r 輔助鍵 這是一個 PF (可編程功能) 鍵。按下它來開啟它的輔助功能 (如下所示)。此鍵無默認設置。 t t t t t PTT (按下通話) 開關 按下後對著麥克風講話來呼叫對方電臺。 y y y y y 側端 1 鍵 這是一個 PF (可編程功能) 鍵。按下它來開啟它的輔助功能 (如下所示)。此鍵無默認設置。 u u u u u 側端 2 鍵 這是一個...
