Flush mount template

Advertisement

Quick Links

FLUSH MOUNT TEMPLATE
OUTSIDE EDGE OF POCKET
Dashed lines indicate the actual
outline of the pocket. Cut along
bold line to provide clearance for
Detent Plate operation.
GARMIN International Part # 190-00183-01 Rev. A. Printed in Taiwan
CUT ALONG BOLD LINE
CUT ALONG BOLD LINE
TRIM ALONG DASHED LINE
3/8"
DRILL A HOLE FOR
A PLACE TO BEGIN CUTTING
