Denver DHD-160 User Manual

Digital video disc player

Advertisement

Quick Links

Safety Precautions

The lightning flash with an arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DUE TO THE HIGH RISK OF FIRE
WARNING:
OR ELECTRIC SHOCK, DO NOT OPEN THE CABINET DANGEROUS HIGH VOLTAGES ARE
PRESENT INSIDE THE ENCLOSURE. ONLY QUALIFIED SERVICE PERSONNEL SHOULD
ATTEMPT THIS.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WID
FULLY INSERT.
P l a y t h e t i t l e o
This Digital Video Disc Player employs a Laser System. To prevent direct exposure
to the laser beam, do not try to open the enclosure. Visible laser radiation emits when
open and interlocks are defeated. Use of controls or adjustments or performance of
procedures other than those specified herein may result in hazardous radiation
exposure.
To ensure proper use of this product, please read this owner manual carefully and
retain for future reference. Should the unit require maintenance, contact an authorized
service location, or contact our company office. Only qualified service personnel should
remove the cover.
FCC NOTICE:
This equipment has been tested and found to comply with the limits for a Class B digital
device. Pursuant with the FCC Rules, Part 15. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,if not
installed and used in accordance with the instructions,may cause harmful interference
to radio communication,However,this is no guarantee that interference will not occur
in a particular installation.If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on,the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
FCC Caution:
To assure continued compliance,(example-use only shielded interface
cables when connecting to computer or peripheral devices).Any changes or
modifications not expressly approved by the party responsible for compliance
WA R N I N G:
Changes or modifications made to this equipment, not expressly approved by us or
parties authorized by us will void all the manufacture warranties.
DO NOT STARE INTO B E A M.
1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
u s e r c a n
