American Dryer Corp. AD-670 Phase 7 Installation Manual

Phase 7 / gas only
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AD-670 Installation Manual
WARNING: For your safety the information in
this manual must be followed to minimize the
risk of fire or explosion or to prevent property
damage, personal injury or death.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
103100GS/tcosta
Phase 7 / Gas Only
For replacement parts, contact the reseller from which the dryer
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette notice
pour réduire au minimum le risque d'incendie
ou d'explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
— Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
• Ne pas tenter d'allumer d'appareils.
• Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment.
• Évacuez la pièce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur
de gaz depuis un voisin. Suivez les
instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
— L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien qualifié
ou par le fournisseur de gaz.
was purchased or
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 113049

Advertisement

Table of Contents
loading

Related Manuals for American Dryer Corp. AD-670 Phase 7

Summary of Contents for American Dryer Corp. AD-670 Phase 7

  • Page 1 AD-670 Installation Manual Phase 7 / Gas Only WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 Important For your convenience, log the following information: “IMPORTANT NOTE TO PURCHASER” POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. AD-670 Phase 7...

  • Page 3: For Your Safety

    YOU MUST DISCONTINUE AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY BEFORE ANY COVERS, GUARDS, OR DOORS ARE REMOVED OR OPENED TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 4 The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY OR FIRE COULD RESULT. DRYER MUST NEVER BE OPERATED WITHOUT THE LINT DRAWERS IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I IMPORTANT INFORMATION ... 3 A. Receiving and Handling ... 3 B. Safety Precautions ... 4 SECTION II SPECIFICATIONS AND DIMENSIONS ... 6 A. Specifications ... 6 B. Dimensions ... 7 SECTION III INSTALLATION PROCEDURES ... 8 A.
  • Page 6 SECTION VII DATA LABEL INFORMATION ... 29 A. Data Label... 29 SECTION VIII GAS TRAIN AND BURNER DESCRIPTION AND OPERATION ... 31 A. Pilot Gas Supply Line ... 31 B. Main Gas Supply Line ... 33 C. Lo-Fire Gas Supply Line Loop ... 34 SECTION IX COMPONENT SYSTEM DESCRIPTIONS ...

  • Page 7: Important Information

    IMPORTANT INFORMATION A. RECEIVING AND HANDLING The dryer is shipped in three (3) pieces with protective stretch wrap, protective cardboard corners, and top covers as a means of preventing damage in transit. Upon delivery, the individual pieces and/or packaging, and wooden skids should be visually inspected for shipping damage.

  • Page 8: Safety Precautions

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the safety guards, service panels, or service doors removed or open.
  • Page 9 WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage plastics or rubber and may be a fire hazard. 7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and area around the back of the dryer.

  • Page 10: Specifications And Dimensions

    SPECIFICATIONS AND DIMENSIONS A. SPECIFICATIONS Maximum Capacity (Dry Weight) Basket Diameter Basket Depth Basket Volume Blower Motor Basket Motor Door Sill Height, Level Compressed Air Volume (1-way / 2-way tilt) Compressed Air Connection S.A.F.E. Water Connection* Voltage Available Heat Input Approx.

  • Page 11: Dimensions

    AD-670 1 Door Tilting/2 Door Tilting B. DIMENSIONS NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.

  • Page 12: Installation Procedures

    INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 &...

  • Page 13: Fresh Air Supply Requirements

    B. FRESH AIR SUPPLY REQUIREMENTS When the dryer is operating, it draws in room air, heats it, passes this air through the basket (tumbler), and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the make-up air is inadequate, drying time and efficiency will be adversely affected.

  • Page 14: Exhaust Requirements

    NOTE: Component failure due to dry cleaning solvent fumes will VOID THE WARRANTY. C. EXHAUST REQUIREMENTS IMPORTANT: Each AD-670 must be individually exhausted to the outdoors. 1. General Exhaust Ductwork Information Exhaust ductwork should be designed and installed by a qualified professional. Improperly sized ductwork...
  • Page 15 IMPORTANT: Exhaust back pressure measured by a Magnehelic in the exhaust duct must be no less than 0 and must not exceed 1.0 inch (2.48 mb) of water column (W.C.). NOTE: When the exhaust ductwork passes through a wall, ceiling, or roof made of combustible materials, the opening must be 2-inches (5.08 cm) larger than the duct (all the way around).

  • Page 17: Electrical Requirements

    D. ELECTRICAL REQUIREMENTS It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms to local and state regulations or codes. In the absence of such codes, ALL electrical connections, materials, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO.
  • Page 18 WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to the dryer components due to improper voltage connections will automatically VOID THE WARRANTY. NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.

  • Page 19: Gas Requirements

    E. GAS REQUIREMENTS It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms to local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION.
  • Page 20 2. Technical Gas Data a. Gas Specifications Pressure @ Hi-Fire Gas Valve* Pressure @ Gauge P1* Pressure Into Internal Regulator Shaded areas are stated in metric equivalents * Measured at the gas valve pressure tap when the gas valve is on. b.
  • Page 21 3. Piping /Connections ALL components/materials must conform to National Fuel Gas Code Specifications ANSI Z223.1-LATEST EDITION, or in Canada, CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas Plumbing), as well as local codes and ordinances and must be done by a qualified professional.

  • Page 22: Compressed Air Requirements

    1/2 psig (3.5 kPa). F. COMPRESSED AIR REQUIREMENTS The AD-670 requires compressed air to tilt the dryer, open and close the load doors, clean lint from the fan, and actuate the sprinkler valve. The dryer cannot operate without a supply of compressed air.

  • Page 23: Preoperational Tests

    G. PREOPERATIONAL TESTS ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.
  • Page 24 NOTE: Mechanical functions of the dryer are not allowed during the ON time. The blower (fan) must be OFF to perform mechanical functions. However the “STOP/CLEAR” key may be pressed at any time to end the Wrinkle Guard cycle. Mechanical functions of the dryer are allowed during the OFF time.

  • Page 25: Preparation For Operation/Start-Up

    12. Make a complete operational check of ALL safety-related circuits (i.e., lint drawer, door, and sail switches on gas models). 13. A reversing basket (tumbler) should never be operated with less than a 442 lb (200 kg) load (dry weight). The size of the load will affect the coast-down and dwell (stop) times.

  • Page 26: Shut Down Instructions

    NOTE: Lint drawer must be ALL the way in place to activate the safety switch otherwise the dryer will not start. 9. Check bolts, nuts, screws, terminals, and fittings for security. 10. Check to ensure air supply (80 PSI [5.51 bars]) is connected to the dryer. I.

  • Page 27: Routine Maintenance

    ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location. Maximum operating efficiency is dependent upon proper air circulation.
  • Page 28 MONTHLY Empty the compressed air filter bowl. Apply high-temperature grease to the four (4) 2-3/16” diameter basket (tumbler) drive shaft pillow block bearings. (Use Shell Alvania #2 grease or its equivalent.) Retighten setscrews in the collars of the four (4) 2-3/16” diameter basket (tumbler) drive shaft bearings. Clean any lint accumulation from the gas valve burner area at the right side of the dryer, the fan (impellor) motor, and the fan (impellor) bearings located in the dryer base.

  • Page 29: Adjustments

    B. ADJUSTMENTS 7 DAYS AFTER INSTALLATION AND EVERY 6 MONTHS THEREAFTER Inspect bolts, nuts, screws (bearing setscrews), grounding connections, and nonpermanent gas connections (i.e., unions, shutoff valves, and orifices). Fan (impellor) V-belts, along with the motor and drive chains should be examined and replaced if necessary.

  • Page 30: Service/Parts Information

    SERVICE/PARTS INFORMATION A. SERVICE 1. Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the reseller from whom the ADC equipment was purchased. If the reseller cannot be contacted or is unknown, contact the ADC Service Department for a reseller in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.

  • Page 31: Warranty Information

    WARRANTY INFORMATION A. RETURNING WARRANTY CARDS 1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.
  • Page 32 2. Each part must be tagged with the following information: a. Model number and serial number of the dryer from which part was removed. b. Nature of failure (be specific). c. Date of dryer installation. d. Date of part failure. e.

  • Page 33: Data Label Information

    SECTION VII DATA LABEL INFORMATION A. DATA LABEL Contact American Dryer Corporation When contacting American Dryer Corporation certain information is required to insure proper service/parts information from ADC. This information is on the data label that is affixed to the left side of the main electrical cabinet located in the right hand electrical enclosure.
  • Page 34 THE DATA LABEL 1. MODEL NUMBER The model number is an ADC number, which describes the size of the dryer and the type of heat (gas, electric, or steam). 2. SERIAL NUMBER The serial number allows ADC to gather information on your particular dryer. 3.

  • Page 35: Gas Train And Burner Description And Operation

    GAS TRAIN AND BURNER DESCRIPTION AND OPERATION The ADG-670’s atmospheric burner system is responsible for supplying the dryer with it’s heat input. It is a high/low system with a firing rate of 2.2 million BTUs per hour (554,400 kcal/hr) on hi-fire and 450,000 BTUs per hour (113,400 kcal/hr) on lo-fire.
  • Page 36 2. 1/2” N.P.T. Pilot Solenoid Valve – This is an on/off solenoid valve which is used to allow gas to flow through the line when pilot is called for and then discontinues gas when the heat cycle has been completed. There is no adjustment needed to this valve for natural or liquid propane (L.P.) gases.

  • Page 37: Main Gas Supply Line

    B. MAIN GAS SUPPLY LINE The main gas supply line is a 2” N.P.T. line, which feeds the gas required for both high and lo-fire. 1. Main Gas Valve - The main gas valve is a double solenoid gas valve containing two (2) safety shutoff valves in one (1) housing.

  • Page 38: Lo-Fire Gas Supply Line Loop

    C. LO-FIRE GAS SUPPLY LINE LOOP The lo-fire gas supply line loop is a 3/4” line, which is responsible for supplying the burner system with the gas required during lo-fire operation. 1. Adjustable Orifice - The adjustable orifice found in the lo-fire gas supply line controls the flow of gas to the burner during lo-fire.

  • Page 39: Component System Descriptions

    SECTION IX COMPONENT SYSTEM DESCRIPTIONS A. BASKET (TUMBLER) DRIVE SYSTEM There are two (2) drive assemblies. Each drive assembly consists of a 5 HP (3.72 kw) drive motor, which is connected to the drive shaft by two (2) “B” section V-belts, driving a shaft-mounted (5.6 to 1 ratio) gear reducer. This produces a basket (tumbler) speed of approximately 31.5 r.p.m.

  • Page 40: Basket (Tumbler)

    C. BLOWER SYSTEM The impellor (fan) used in the AD-670 dryer is a 22” (55.88 cm) diameter backwardly inclined plug fan. It spins in a counterclockwise (CCW) direction looking from the left side of the dryer.
  • Page 41 6. Access and Burner Door Switches These switches are located behind each of the six (6) doors found on the AD-670 dryer. ALL the doors must be closed and securely latched for the dryer to operate.

  • Page 42: Phase 7 Opl System Diagnostics

    PHASE 7 OPL SYSTEM DIAGNOSTICS IMPORTANT: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 43 CALL FOR SERVICE - Indicates a board failure. FRONT DOOR NOT CLOSED - A front door is open when it should be closed. REAR DOOR NOT CLOSED - A rear door is open when it should be closed. CHECK CONTROL POWER - Indicates control power is off. EXHAUST HIGH TEMP FAULT - Indicates the temperature in the basket (tumbler) is above 225º...

  • Page 44: I/O Board Input And Output L.e.d. Indicators

    B. I/O BOARD INPUT AND OUTPUT L.E.D. INDICATORS...
  • Page 45 INPUTS: (RED) FDRC - Front Door Closed FDRO - Front Door Open TBOL - Basket (Tumbler) Overload FNOL - Fan Overload RDWN - Rear Down FDWN - Front Down RDRC - Rear Door Closed RDRO - Rear Door Open FAN - Blower Fan On 10.
  • Page 46 RDRO – (RED L.E.D.) This L.E.D. will indicate the status of the Rear Doors. If the doors are open, then the L.E.D. is ON. FAN – (RED L.E.D.) This L.E.D. will indicate the status of the Blower Fan. If the fan is on, then the L.E.D.
  • Page 47 Input/Output (I/O) Board Output Description (“Green” light emitting diode [L.E.D.]) R_HEAT – (GREEN L.E.D.) ALERT – (GREEN L.E.D.) FWD – (GREEN L.E.D.) REV – (GREEN L.E.D.) AIR JET – (GREEN L.E.D.) FAN – (GREEN L.E.D.) F_HEAT – (GREEN L.E.D.) PGR1 – (GREEN L.E.D.) PGR2 –...
  • Page 48 16. OCL5 – (GREEN L.E.D.) 17. OCL6 – (GREEN L.E.D.) 18. OCL7 – (GREEN L.E.D.) 19. OCL8 – (GREEN L.E.D.) 20. EOC – (GREEN L.E.D.) This L.E.D. will indicate the status of the Open Collector #5 output. If the request to turn on the Open Collector #5 is made, then the L.E.D. is ON. (Programmable and Defaulted to Rear Down.) This L.E.D.

  • Page 49: Troubleshooting

    IMPORTANT: YOU MUST DISCONNECT AND LOCKOUT THE ELECTRIC SUPPLY AND THE GAS SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 50 NOTE: SPRINKLER MUST HAVE POWER FOR THE DRYER TO OPERATE. B. Drive motor is not operating (does not start)... Microprocessor controller (computer) relay output indicator (either forward “FWD” or reverse “REV”) is on. 1. Blown drive motor contactor overloads. 2. Failed drive motor contactor. 3.
  • Page 51 V-belts are too tight. g. Dryer has an oversized load. h. Voltage to the dryer is incorrect...check dryer data label for specified voltage. 2. Failed overload protector... a. Incorrect overload setting. E. Impellor (fan) motor is not operating (does not start)... Microprocessor controller (computer) input/output (I/O) board “FAN”...
  • Page 52 2. Failed overload protector... a. Incorrect overload setting. 3. Blown drive motor and blower (fan and impellor) motor fuses or overloads. 4. Failed motors (both blower [fan and impellor] motor and drive motor). 5. Failed microprocessor controller (computer). G. Microprocessor controller (computer) display board light emitting diode (L.E.D.) display reads “BAD PROBE”...
  • Page 53 5. Front or rear doors are opened during cycle. 6. Failed microprocessor controller (computer) input/output (I/O) board. Microprocessor controller (computer) light emitting diode (L.E.D.) displays “Lint Drawer Open.” 1. Lint drawer is not closed ALL the way. 2. Lint drawer switch is out of proper adjustment. 3.
  • Page 54 2) Failure in drive motor circuit. b. Faulty rotation sensor. c. Broken wire or connection between rotation sensor and microprocessor controller (computer) display board. d. Failure in rotational sensor circuit, magnet missing, or gap too large. e. Basket (tumbler) rotation below 12 RPMS. Microprocessor controller (computer) reads “Exhaust High Temp Fault”...
  • Page 55 2. Impellor (fan/blower) out of balance... a. Excessive lint buildup on impellor (fan/blower)...check air jet. b. Failed impellor (fan/blower). 3. Loose motor mount. 4. Failed idler bearings or basket (tumbler) bearings. 5. V-belt(s) either too tight or too loose. 6. Basket (tumbler) drive wheels are worn or are loose. 7.

  • Page 56: Optional Sprinkler System Components

    SECTION XII OPTIONAL SPRINKLER SYSTEM COMPONENTS OPTIONAL SPRINKLER CIRCUIT COMPONENTS AUTO “EMERGENCY STOP” (E-Stop) RELAY This device, located in the front right electrical enclosure, supplies the main control voltage to the dryer. The dryer’s sprinkler circuit supplies or removes 120 VAC to the coil of this relay for the “EMERGENCY STOP”...
  • Page 57 SPRINKLER AND MAIN POWER CONNECTIONS There are two (2) individual power connections to the dryer that includes the sprinkler system option. 1. Main dryer power (3-phase [3ø]). 2. Dedicated sprinkler system circuit power (single-phase [1ø]). Both of these connections are at the voltage rating of the dryer and can be installed in the front right base electrical enclosure.
  • Page 58 Sprinkler Option Temperature Controller Settings NOTE: Refer to Controller’s User’s Manual for further information on controller options. Message Message Display Description SECr SECURITY CODE INPUT DEVICE º F OR º C DECIMAL POINT InPt INPUT FAULT TIMER SET POINT LOW SET POINT HIGH SPSt SET POINT STATE...
  • Page 60 ADC 113049 5 - 09/03/04-0...
