  • Page 1 USER MANUAL...
  • Page 2: Getting Started

    Getting Started Thanks for puchasing the iFrogz Coda Forte headphones! The Coda Forte features Bluetooth technology and offers high-fidelity audio. Begin charging the Coda Forte by connecting the included USB cable to the head- phones. Plug the other end of the cable into a computer or a USB power adapter. Let the headphones charge for approximately 2 hours until the red light turns off.
  • Page 3 The Coda Forte Power/Play Button Up & Down Buttons USB port LED Indicator 3.5mm port Microphone Driver: 40mm Microphone Sensitivity: -38db ± 3db Battery Capacity: 360mAh Contiuous Working Hours: 8-10 hours Charging Time: 2 hours Operating Distance: 8-10M...
  • Page 4 Functionality Power/Play Button Turn on Coda Forte and Pair - Hold for 8 seconds Turn on Coda Forte - Hold for 3 seconds Turn off Coda Forte - Hold for 3 seconds Pause/Unpause Music - Press once Take Call - Press once while ringing Hang Up - Press once while talking Ignore Call - Hold for 2 seconds while ringing...
  • Page 5: Down Button

    Functionality Up Button Move backward 1 track - Press once Turn up volume - Hold down to desired volume Down Button Move forward 1 track - Press once Turn down volume - Hold down to desired volume Charging - Solid red Fully charged Pairing Mode - Alternating red and blue...
  • Page 6 Pairing with an iPhone/iPad/iPod Touch • After charging the Coda Forte, open the Settings app • Tap Bluetooth and ensure Bluetooth is turned on • On the Coda Forte, hold down the power button for 8 seconds The headphones will make several tones during this process. Keep holding the button for the full 8 seconds. •...
  • Page 7 Pairing with an Android phone/tablet • After charging the Coda Forte, open the Settings panel • Turn on Bluetooth, then tap the word “Bluetooth” to enter the settings window • On the Coda Forte, hold down the power button for 8 seconds The headphones will make several tones during this process.
  • Page 8 Pairing with a Macintosh computer • After charging the Coda Forte, open System Preferences • Click on Bluetooth under the Internet & Wireless section • Make sure Bluetooth is on by checking the “on” box • Press the “+” button in the lower-left corner of the window •...
  • Page 9: Troubleshooting

    Troubleshooting There is popping or clipping when listening to music Try turning down the volume on the Coda Forte itself, then turn up the volume on the music source (computer, phone, tablet, etc.) Music sounds muffled or it is playing in mono Make sure that your device is using “iFrogz Coda Forte Stereo”...
  • Page 10 FCC NOTE Headset model: Coda Forte BT FCC ID: QTGCDFORTE Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pur- suant to Part 15 of the FCC Rules.
  • Page 12 www.ifrogz.com...

This manual is also suitable for:

Coda forte
