- Page 1 GLDH Parts List 18-December-2008 This parts list is current as of the above revision date. Form Number: 92-42810-GLDH...
-
Page 2: Table Of Contents
Table of Contents Model Explanation ..............Page 3 Parts Numbers Panels - Miscellaneous 04-07 . -
Page 3: Model Explanation
MODEL NUMBER EXPLANATION 90% EFFICIENCY DOWNFLOW/HORIZONTAL CONDENSING PLACEHOLDER HEATING INPUT DESIGNATION 40 = 45,000 BTU/HR 60 - 60,000 BTU/HR E = Electric 75 = 75,000 BTU/HR N = NOX 90 = 90,000 BTU/HR 105 = 105,000 BTU/HR 120 = 120,000 BTU/HR DRIVE NOMINAL COOLING/REVISION LEVEL 3 = 3 Ton 4 = 4 Ton... -
Page 4: Panels - Miscellaneous
MODEL GLDH GLDH GLDH GLDH Notes HEATING CAPACITY VARIATIONS PANELS, SHEET METAL, MISCELLANEOUS Blower/Filter Door AS-67890-11 AS-67890-11 AS-67890-11 AS-67891-11 Burner Door AS-61866-09 AS-61866-09 AS-61866-09 AS-61867-09 Induced Draft Blower w/Gasket See Electrical Group Gasket - Induced Draft Blower See Electrical Group Connector/Transition 68-24047-10 68-24047-10... -
Page 5: Panels - Miscellaneous
MODEL GLDH GLDH GLDH GLDH Notes HEATING CAPACITY 105E 120E VARIATIONS PANELS, SHEET METAL, MISCELLANEOUS Blower/Filter Door AS-67891-11 AS-67891-11 AS-67891-11 AS-67892-11 Burner Door AS-61867-09 AS-61867-09 AS-61867-09 AS-61868-09 Induced Draft Blower w/Gasket See Electrical Group Gasket - Induced Draft Blower See Electrical Group Connector/Transition 68-24047-11 68-24047-11... -
Page 6: Parts Bag
MODEL GLDH Notes HEATING CAPACITY BLOWER DESIGNATION PARTS BAG Complete Parts Bag Assembly AS-100717-03 1/2 in. PVC Pipe - 4 in. 68-22024-04 1/2 in. Tee 68-21980-02 PVC Vane 68-23473-01 PVC Wind Vane - 2 1/2 in. 68-24049-01 Drain Tube - 6 3/4 in. 68-24026-04 Elbow 68-24121-01... -
Page 7: Electrical Group
MODEL GLDH GLDH GLDH GLDH Notes HEATING CAPACITY VARIATIONS ELECTRICAL GROUP Induced Draft Blower w/Gasket 70-24033-01 70-24033-01 70-24033-01 70-24033-01 Gasket - Induced Draft Blower 68-24016-01 68-24016-01 68-24016-01 68-24016-01 Limit - Manual Reset ( Burner Compartment) 47-22861-01 47-22861-01 47-22861-01 47-22861-01 Limit - Main Limit (Heat Exchanger Panel) 47-25350-09 47-25350-07 47-25350-01 47-25350-09 Pressure Switch 42-24196-01 42-24196-04 42-24196-01 42-24196-01... -
Page 8: Blower Group
MODEL GLDH GLDH GLDH GLDH Notes HEATING CAPACITY VARIATIONS BLOWER GROUP Blower Assembly (Includes items 45-48 and 53) AS-61697-38 AS-61697-93 AS-61697-93 AS-61697-95 Motor Mount Leg (4) AE-61698-02 AE-61698-02 AE-61698-02 AE-61698-02 Blower Motor 51-26141-01 51-24144-01 51-24144-01 51-24146-01 Blower Housing AS-61674-14 AS-61674-14 AS-61674-14 AS-61674-14 Blower Wheel... -
Page 9: Heat Exchanger-Burner Group
MODEL GLDH GLDH GLDH GLDH No. Notes HEATING CAPACITY VARIATIONS HEAT EXCHANGER, BURNER / MANIFOLD GROUP Stk Limit - Manual Reset ( Burner Compartment) See Electrical Group Stk Limit - Main Limit (Heat Exchanger Panel) See Electrical Group Stk Heat Exchanger AS-67818-22 AS-67818-23 AS-67818-24... -
Page 10: Gas Controls
MODEL GLDH GLDH GLDH Notes GAS CODE GAS CONTROLS Integrated Furnace Control Board (IFC) 62-25338-01 62-24140-04 62-24140-04 Gas Valve - Natural Gas 60-100394-02 60-22866-01 60-23490-01 Stk,1 Gas Valve - LP See Note 1 See Note 1 See Note 1 Ignitor 62-24141-04 62-24141-04 62-24141-04... -
Page 11: Orifice Selection Chart
90% GAS FURNACE - ORIFICE SELECTION CHART - NATURAL GAS CAUTION: Selection of the correct Natural Gas Orifice requires the following information for the specific installation: 1) Altitude in of the installation (ft.). 2) Average energy content of the Natural Gas fuel from the local supplier (BTU/cu. ft.). For detailed information and instructions for Orifice selection, see the Gas Furnace LP Conversion Kit Index 92-21519-59 and the latest edition of the National Fuel Gas Code Handbook, or the National Standard of Canada, Natural Gas and Propane Installation Code, CAN B149.1. -
Page 12: Exploded View
Exploded View 18-December-2008 92-42810-GLDH Page 12 of 16... -
Page 13: Horizontal Installation Parts
Horizontal Installation Parts 18-December-2008 92-42810-GLDH Page 13 of 16... -
Page 14: Blower Assembly
Blower Assembly 18-December-2008 92-42810-GLDH Page 14 of 16... -
Page 15: Burner Assembly
Burner Assembly 18-December-2008 92-42810-GLDH Page 15 of 16... -
Page 16: Notes
NOTES Stk It is recommended that stock be maintained for this part. N/A Not Applicable 1 Order Gas Valve for Natural Gas along with LP Conversion Kit 1900 Wellworth Jackson, MI 49203...
