Single Stage Condensing Gas Furnaces
InSTAllATIon InSTrUCTIonS
GUH92A (92.1% AFUE)
Upflow / Horizontal Furnace
• Failure to follow safety warnings exactly could result in serious injury or property damage.
• Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbors phone.Follow the gas suppliers instructions.
• If you cannot reach your gas supplier, call the fire department.
Do noT DESTroY. PlEASE rEAD CArEFUllY & KEEP In A SAFE PlACE For FUTUrE rEFErEnCE.
GUH95A & GUH95C (95.0% AFUE)
Upflow / Horizontal Furnace
WArnInG
FIrE or EXPloSIon HAZArD
WHAT To Do IF YoU SMEll GAS
92.1% Through 95.0% AFUE
GDD92A (92.1% AFUE) &
GDD95A (95.0% AFUE)
Downflow Furnace
Advertisement
Table of Contents
Related Manuals for Heat Controller GDD95A
Summary of Contents for Heat Controller GDD95A
- Page 1 Single Stage Condensing Gas Furnaces 92.1% Through 95.0% AFUE InSTAllATIon InSTrUCTIonS GDD92A (92.1% AFUE) & GUH92A (92.1% AFUE) GDD95A (95.0% AFUE) Upflow / Horizontal Furnace GUH95A & GUH95C (95.0% AFUE) Downflow Furnace Upflow / Horizontal Furnace WArnInG FIrE or EXPloSIon HAZArD •...
-
