selectorXL
BALANCED XLR SWITCHER/ROUTER
Features
Silent A/B switching at mic levels thru both XLR outputs
Advanced circuitry eliminates popping, noise and level changes
Dipswitches provide full configuration of switching modes
Outputs are protected from external Phantom power
Full 48VDC phantom power to input jack
PS24AC wall power supply included (required for Phantom power)
99 Ling Road . Rochester, NY 14612
Bright LEDs indicate output ON status
Phone 585 663-8820 . Fax 585 865-8930
Heavy-duty steel enclosure
Email: sales@whirlwindusa.com
Easy access for battery replacement
http://www.whirlwindusa.com
3 year warranty
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whirlwind XLR
Summary of Contents for Whirlwind XLR
- Page 1 BALANCED XLR SWITCHER/ROUTER Features Silent A/B switching at mic levels thru both XLR outputs Advanced circuitry eliminates popping, noise and level changes Dipswitches provide full configuration of switching modes Outputs are protected from external Phantom power Full 48VDC phantom power to input jack PS24AC wall power supply included (required for Phantom power) 99 Ling Road .
- Page 2 ICs capable of noise levels almost dipswitches. Outputs A and B are male XLRs and as low as physics allow. With these amplifiers the input is a female XLR. buffering the microphone, it is difficult to measure (or hear) any contribution in noise or distortion...
- Page 3 Switching Mode Configuration Operation of the SelectorXL is completely configurable by changing the settings of the 8 internal dipswitches. The footswitch can be set for either Momentary (press and hold) or Alternate (push on, push off) action. The A and B outputs can be set to turn on when the switch is pushed (push to talk), mute when the switch is pushed (push to mute) or to be always on.
- Page 4 If Battery life 30 hours of it is determined a manufacturing defect has occurred, continuous use whirlwind will repair or replace the unit at our option and pay (toggling) the postage back to you.
