Twinning kit for use with furnace models using honeywell st9120 and st 9160 electronic fan controls

Advertisement

Quick Links

Honeywell ST9120 and ST 9160 Electronic Fan Controls
Please read these instructions completely before attempting installation.
!
Electrical shock hazard/Fire and/or explosion haz-
ard.
Turn off electric power supply at disconnect switch
or service panel before starting installation.
Turn off gas supply at field installed manual gas
valve before starting installation.
Failure to follow this warning can result in property
damage, personal injury and/or death.
!
Installation or repairs made by unqualified persons
can result in hazards to you and others. Installation
MUST conform with local building codes or, in the
absence of local codes, with the National Fuel Gas
Code NFPA 54/ANSI A223.1,1990 or latest edition. In
Canada, National Standard CAN/CGA B149- -1.
The information contained in this manual is in-
tended for use by a qualified service technician fa-
miliar with proper safety procedures and equipped
with the proper tools and test instruments.
Failure to carefully read and follow all instructions
in this manual can result in furnace malfunction,
property damage, personal injury and/or death.
This twinning kit is intended to permit two identical gas furnaces to
be installed connected to the same duct work. Air conditioning can
be added by using one air conditioning evaporator coil sized for
the total air flow capabilities of the two furnaces.
Single and Two Stage Heating
Single or two stage heating is obtainable using twinning kit
NAHA003WK01. Follow the instructions located in the Twinning
Kit Installation section for proper hookup of desired thermostat
staging.
Printed in U.S.A.
Twinning Kit NAHA003WK.01
For Use With Furnace Models Using

Furnace Installation

Refer to the Installation Instructions packed with the furnaces for
information about clearances, start--up and maintenance, gas
piping and vent installation.
CAUTION
Furnaces installed MUST be identical. They may be
installed on a raised platform or wood floor which
MUST be level. When side return is required, separate
return air drops MUST be made to both furnaces. Do
not use rear of furnace for the return air duct
connection.
CAUTION
Make sure blower motors are wired to operate on the
same speed tap.
CAUTION
Two furnaces must be plumbed with a single supply
gas shut off valve.
NOTE: When twinning kit has been installed, locate the adhesive
backed wiring diagram included in the kit and apply next to the
existing wiring diagrams in the furnaces.
TWINNING KIT INSTALLATION
The twinning kit contains (2) 36" wires of two different colors to
interconnect the electronic fan controls of the two furnaces. For
proper operation, and to avoid damage to the controls, be
sure to match Z1 to Z1 and Z2 to Z2 or C to C and H to H on
each fan control (see Figure 1 and Figure 2). The wires are
color coded to assist with this connection. Each wire is factory
terminated with a special crimped edge connector which will push
into mating connection positions on the edge of the circuit board
on each fan control. The length of these wires can be extended by
cutting and splicing sufficient additional wire to each lead.
An isolation relay is provided to protect the system's thermostat
from possible overloading due to the combined valve and control
load of the two appliances.
441 06 1003 02 (10/2001)

Advertisement

loading
Need help?

Need help?

Do you have a question about the NAHA003WK.01 ST9120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bryant NAHA003WK.01 ST9120

  • Page 1: Furnace Installation

    Twinning Kit NAHA003WK.01 For Use With Furnace Models Using Honeywell ST9120 and ST 9160 Electronic Fan Controls Please read these instructions completely before attempting installation. Furnace Installation Refer to the Installation Instructions packed with the furnaces for Electrical shock hazard/Fire and/or explosion haz- information about clearances, start--up and maintenance, gas ard.
  • Page 2: Installation Procedures

    Installation Procedures “G” and “Y” connections only. Interconnect the wiring from the “C” connections at the terminal blocks on each fan control. Note: The “Y” connection is not required if air Remove line power from both appliances before starting conditioning is not available. installation of the twinning kit.
  • Page 3: Isolation Relay

    Figure 1 Connection of Twinning Leads and Locating Isolation Relay On Furnace #1 Control Panel CONTROL PANEL (Located In Blower Compartment). Transformer ST9120C40 ELECTRONIC FAN CONTROL Twinning Leads ST9120 ISOLATION RELAY (SPST) DRILL TWO 1/8” Dia. CONTROL PANEL (Located In Blower Compartment). Transformer ELECTRONIC DATA...
  • Page 4 Figure 2 CONTROLS FOR ST 9210 & ST9160 ELECTRONIC FAN CONTROL ELECTRONIC FAN CONTROL (ST9120) (ST9120) Twinning Leads Connect Z1 To Z1 And Z2 To Z2. ELECTRONIC FAN CONTROL ELECTRONIC FAN CONTROL (ST9160) (ST9160) DATA DATA Twining Leads Connect H To H And C To C.
  • Page 5 Figure 3 Proper Connection of Twinning Leads for ST 9120 & ST 9160 FURNACE #2 FURNACE #1 Splice if Required,to obtain necessary length. Bushings ST9120 ST9120 Z2 TO Z2 ST9120C40 ST9120C40 Z1 TO Z1 Twinning Leads FURNACE #2 FURNACE #1 Splice if Required,to obtain necessary length.
  • Page 6 Proper Connection of Twinning Leads for ST 9120 Figure 4 441 06 1003 02 (10/2001)
  • Page 7 Figure 5 Proper Connection of Twinning Leads for ST 9160 Thermostat Wiring For Single Stage Heating ELECTRONIC ELECTRONIC FAN CONTROL FAN CONTROL FURNACE #1 FURNACE #2 WALL Connect H to H THERMOSTAT Connect C to C ISOLATION RELAY Thermostat Wiring For Two Stage Heating ELECTRONIC ELECTRONIC...
  • Page 8 Figure 6 ST 9120 Thermostat Wiring For Single Stage Heating And Two Stage Cooling ELECTRONIC FAN CONTROL FURNACE #1 WALL Connect Z1 To Z1 THERMOSTAT Connect Z2 To Z2 Y2 Y1 ELECTRONIC FAN CONTROL FURNACE #2 ISOLATION CONDENSERS RELAY Thermostat Wiring For Two Stage Heating And Single Stage Cooling ELECTRONIC...
  • Page 9 Figure 7 ST 9160 Thermostat Wiring For Single Stage Heating And Two Stage Cooling ELECTRONIC FAN CONTROL ELECTRONIC FURNACE #2 FAN CONTROL FURNACE #1 WALL Connect H to H THERMOSTAT Connect C to C Y2 Y1 ISOLATION CONDENSERS RELAY Thermostat Wiring For Two Stage Heating And Single Stage Cooling ELECTRONIC...
  • Page 10 Figure 8 Thermostat Wiring For Single Stage Heating And Cooling. ELECTRONIC FAN CONTROL FURNACE #1 Connect Z1 To Z1 WALL THERMOSTAT Connect Z2 To Z2 ELECTRONIC FAN CONTROL FURNACE #2 ISOLATION CONDENSER RELAY Thermostat Wiring For Two Stage Heating & Cooling ELECTRONIC FAN CONTROL...
  • Page 11 Figure 9 Thermostat Wiring For Single Stage Heating And Cooling ELECTRONIC FAN CONTROL ELECTRONIC FURNACE #2 FAN CONTROL FURNACE #1 WALL Connect H to H THERMOSTAT Connect C to C ISOLATION RELAY CONDENSERS Thermostat Wiring For Two Stage Heating & Cooling ELECTRONIC FAN CONTROL...
