Evolution System Access Module
SYSTMBBSAM01
NOTE: Read the entire instruction manual before starting the
installation.
This symbol → indicates a change since the last issue.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS .....................................................1
INSTALLATION CONSIDERATIONS .......................................1
INTRODUCTION ..........................................................................1
INSTALLATION........................................................................1-3
Check Equipment and Job Site...........................................1
Component Location and Wiring Considerations ..............2
Connect Power Source ........................................................2
Radio Test............................................................................2
Install Components ..............................................................2
Connect Evolution Systems ................................................2
Connect Water Sensor.........................................................2
System Start-Up...................................................................3
PIN Number.........................................................................3
RS-232 Connector ..........................................................................3
Updating System Profile ................................................................3
Troubleshooting..............................................................................3
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service, maintenance,
or use can cause fire, electrical shock, or other conditions that may
cause personal injury or property damage. Consult a qualified
installer, service agency, or your distributor or branch for infor-
mation or assistance. The qualified installer or agency must use
factory authorized kits or accessories when modifying this product.
Refer to the individual instructions packaged with the kits or
accessories when installing. Follow all safety codes and wear
safety glasses. Have fire extinguisher available. Read these in-
structions thoroughly and follow all warnings or cautions attached
to the unit. Consult local and state building codes and Sheet Metal
and Air Conditioning National Association (SMACNA) for special
installation requirements.
Installation and
Start-Up Instructions
EVOLUTION SYSTEM ACCESS MODULE
SYSTMBBSAM01
A97038
—1—
Cancels: NEW
This is the safety-alert symbol
the equipment and in the instruction manual, be alert to the
potential for personal injury. Understand the signal words DAN-
GER, WARNING, and CAUTION. These words are used with
the safety-alert symbol. DANGER identifies the most serious
hazards, which will result in severe personal injury or death.
WARNING signifies a hazard, which could result in personal
injury or death. CAUTION is used to identify unsafe practices,
which may result in minor personal injury or product and property
damage. NOTE is used to highlight suggestions which will result
in enhanced installation, reliability, or operation.
INSTALLATION CONSIDERATIONS
Before the actual installation of a System Access Module can
begin, determine the mounting location. A radio test must be
performed with the System Access Module in the intended
mounting location. See below on how to perform a radio test. The
System Access Module is powered with a 24 VAC transformer
(included). A 120VAC supply must be near the mounting location
of the System Access Module. Provisions must be made to secure
the transformer to the outlet. The D-wire (24 VAC) from the
Evolution system MUST NOT be used to power the System
Access Module. Use this instruction to guide the actual installation
process after the Evolution system(s) have been installed. One
System Access Module is capable of handling two Evolution
systems.
INTRODUCTION
An Evolution System Access Module allows remote connectivity
for up to two Evolution systems within the same building. The
Evolution system owner as well as authorized dealer can monitor
and control the system via the internet as well as by telephone. The
System Access Module communicates through a two-way radio
via
the
Skytel
paging
http://www.skytel.com/coverage/telemetry_coverage.htm to check
coverage for the installation site. The coverage must be listed as
"Full Service" for the System Access Module to function properly.
Please note that Skytel is continuously expanding their service area
so coverage may not be indicated by the web site. The System
Access Module can also monitor a dry-contact sensor to provide a
warning for the presence of water in the building, or some other
use. If the sensor is active, the Evolution system will not be
disabled or shut down.
INSTALLATION
I. CHECK EQUIPMENT AND JOB SITE
INSPECT EQUIPMENT — File claim with shipping company,
prior to installation, if shipment is damaged or incomplete.
II SAM01-0-1
05-05
. When you see this symbol on
network.
Please
visit:
