Summary of Contents for Wintal STB5HD
-
Page 2: Table Of Contents
Table of Contents I.GENERAL INFORMATION................3 1. Preface ....................3 2. Main Features ..................3 3. For Your Safety ..................4 4. General Operation of the Receiver ............4 II. GETTING STARTED..................5 1. Install Receiver..................5 2. Front Panel.................... 6 3. - Page 3 4.3 Timer Setting.................. 18 4.4 Factory Default................18 4.5 System Information ................ 19 IV. TECHNICAL SPECIFICATION ..............20 V. TROUBLE SHOOTING................. 22...
-
Page 4: I.general Information
I.GENERAL INFORMATION 1. Preface STB5HD provides beautiful High Defin ition and Standard Definition Television pictures from Australian Digital TV broadcasts. An attractive On Screen Display and Electronic Program Guides help simplify installation and day to day use. Full Closed Caption Subtitle and Teletext functions are included. -
Page 5: For Your Safety
As new software may change the function of a receiver it should not be installed unless specific upgrade instructions have been given by Wintal for this receiver. Should you experience any difficulties with the operation of your unit, please consult the relevant section of this manual or Trouble Shooting. -
Page 6: Getting Started
II. GETTING STARTED 1. Install Receiver Connection Connect a functional TV Antenna to “ANT IN” for your local TV channels. If in doubt call an experienced TV Antenna Installer. Connect your receiver to the AV display device you wish to use. Please refer to the TV user manual when making connection to the TV . -
Page 7: Front Panel
2. Front Panel The following controls are located at the right of the front mirror panel. Switch between operation and standby modes. Displays main menu and command box on screen. MENU: Confirm operation Change channels or move the cursor up/down in the menu. Adjust the volume or move the cursor left/right in the menu. -
Page 8: Rear Panel
3. Rear Panel Output video signal to VIDEO port on TV VIDEO: Connect to S-VIDEO port on TV S-VIDEO: Output high definition video signal to YPbPr ports on TV Y/Pb/Pr: Output left and right audio signal to R/L-AUDIO ports on TV AUDIO L/R: COAXIAL£º... -
Page 9: Remote Control
4. Remote Control:... - Page 10 Switch between operation and standby modes. : Mute or restore the sound. Number Keys: Number keys. Back to the previous channel. Display information about current and next TV program. INFO: Switch audio languages. AUDIO: Switch among left/right/stereo. Switch between TV and radio modes. Display Electronic Program Guide menu.
-
Page 11: Installing Batteries In Your Remote Control
Note: 1. Colour keys [Red] , [Green], [Yellow] and [Blue] operate Teletext functions and some other special functions in Menu. 2. Subtitle and Teletext functions are only available when broadcast. 4.1 Installing Batteries in your Remote Control Remove the battery cover from the remote control. Insert 2 x AAA size batteries inside the battery compartment. -
Page 12: Scan Your Channels
5. Scan your channels Check that ‘Select TV Type’ and ‘Select State’ match your screen shape and location. keys to change selection. Press the [OK] key to start Scan. As digital broadcasts are found each channel is identified on screen and its programs listed. You can cut the scan short by pressing the [OK] or [EXIT] keys. -
Page 13: Menu Structure
III. MENU STRUCTURE 1. Channel When you press the [Menu] key on the Remote Control unit the main Menu engages on screen. Starting from Channel mode, there are 4 sub-menu groups: ‘Channel’, ‘Scan’, ‘Guide’ and ‘Setup’. Channel Mode provides two options: 1) TV Channel List;... - Page 14 1.1.1 Favorite Press the [1] key to select Favorite function. keys Use the to select a Favorite storage location from ‘HD’ ‘ SD’ or ‘ MOVIES’ etc Use the keys to make a selection. Press the [OK] key and a red mark will show to right side of selected channel name.
- Page 15 1.1.3 Sort Press [3] to engage Sort. Navigate with keys. Programs can be Sorted by ‘Logical’ Channels, ‘Channel Name’ or ‘Frequency’ . Press [EXIT] or [MENU] to store. 1.1.4 Add / Delete Press [4] to enter Add / Delete Channel function. keys to select a channel to delete.
-
Page 16: Radio Channel List
1.2 Radio Channel List In ‘Radio Channel List’ you can also select [1] Favorite, [2] Edit, [3] Sort, [4] Add / Delete , [5] Move or [6] Search for channels by following the instructions above for TV Channel List. 2. Channel Scan Channel scan allows you to rescan for all channels. -
Page 17: Manual Scan By Frequency
2.2.1 Manual Scan by Frequency Input desired search frequency by using the numerical keypad on the remote control. Press [OK] to start search. Channel that is found will be saved into c hannel list. 2.2.2 Manual Scan by Channel Select desired search channel number by keys pressing the Press [OK] to start search. -
Page 18: Setup
Press the [OK] key on the program to add program into “Remind List ”. The unit will set a reminder to remind you about the up coming program which are added into the “Remind List” . ‘Simple Guide ’ shows abbreviated program information. -
Page 19: System Setting
match method of the receiver ’s video output to best match your TV or display (4:3 and 16:9). Screen Format: Select the desired format (Full and Letter). SPDIF Output: Select the desired digital audio output option (Off, PCM and AC3). 4.2 System Setting ‘System Setting’... -
Page 20: System Information
Yellow. Press the ‘OK’ key and receiver will reset. Factory Default password is 1 2 3 4. function carefully. Note: This function will reset all settings to default settings and clear all saved channel including favorite list. 4.5 System Information System information provides technical information including Product, Software Version, Hardware Version, and Loader version. -
Page 21: Technical Specification
IV. TECHNICAL SPECIFICATION TUNER Input frequency 174 to 860MHz UHF & VHF Bandwidth 7 or 8 MHz Input level -72 to -20dBm Input impedance CHANNEL DECODING Demodulation QPSK,16QAM,64QAM 1/2, 2/3, 3/4, 5/6, 7/8. Mode 8K or 2K Guard Band 1/4, 1/8, 1/16, 1/32 DEMULTIPLEXER Standard ISO/IEC 13818-1... - Page 22 POWER Input voltage AC100 to 240V, 50 to 60Hz Power consumption 15 W max AMBIENT ° ° C Operating temperature to 40...
-
Page 23: Trouble Shooting
V. TROUBLE SHOOTING Note : If you cannot solve the problem by referring to the above trouble shooting, please contact your local dealer. Problem Possible Causes What To Do The display on the Mains cable is not Check that the main cable is front panel does not connected.
