Page 1: Model Number
DISHWASHER Repair Parts List MODEL NUMBER MDB8600AWS When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... -
Page 2: Supplemental Information
Section: SUPPLEMENTAL INFORMATION Part No. Description Series Qty 99002563 MANUAL, USE & CARE (MDB-4) 16021814 TALL TUB SERVICE MANUAL N 99002907 GUIDE, ENERGY 99003119 GUIDE, ENERGY 99003348 GUIDE, ENERGY (REV C) 99002725 GUIDE, ENERGY 99002854 MISC. PARTS PACKAGE DAX3400AXX TOE PANEL SPACER KIT (BLK) DAX3200AXE TRIM STRIP KIT (WHT) DAX3200AXN... - Page 3 Section: CONTROL PANEL Model: MDB8600AWS DW11-84...
-
Page 4: Control Panel
Section: CONTROL PANEL Part No. Description Series Qty 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 99002787 PANEL, CONTROL (BLK) 99002573 VENT SEAL, CONTROL PANEL 99002577 HANDLE, LATCH (BLK) 99002751 SWITCH, DOOR 99002580 LATCH ASSEMBLY 99002576 HOUSING, BOARD (BASE) 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 99002978... - Page 5 Section: DOOR Model: MDB8600AWS DW12-68...
- Page 6 Section: DOOR Part No. Description Series Qty 99002771 PANEL, DECO (W/DAMPER-STNLS) 99002673 VENT HOUSING ASSEMBLY 3 N 99002604 CROSSBRACE, HINGE 3 N 99002604 CROSSBRACE, HINGE 99002929 BRACKET, HINGE (LT) 99001075 SCREW Note: SCREW, BRACKET W10124350 NOT REQUIRED PART OR SEE NOTE Note: ***SEE NOTE*** (IF YOU NEED THE LEFT OR RIGHTHINGE BRACKET FOR MODELS PRIORTO SERIES 16 ORDER 12002134) 99002930...
- Page 7 Section: RACK ASSEMBLY (UPR) Model: MDB8600AWS DW15-99...
- Page 8 Section: RACK ASSEMBLY (UPR) Part No. Description Series Qty 99002905 CAP, RACK (DARK GRAY) 99003019 RACK ASSEMBLY (UPR) 99002742 RACK ASSEMBLY (UPR) 99002712 VARILOCK (REAR) 99002714 CUP, VARILOCK 99002715 SPRING, VARILOCK 99002713 SUPPORT, VARILOCK 99002711 VARILOCK (FRT) 99002623 STOP, RACK (GRAY) 99002621 TRACK, RACK Y912798...
- Page 9 Section: TUB Model: MDB8600AWS DW13-94...
- Page 10 Section: Part No. Description Series Qty 99002629 BRACKET, WATER VALVE 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 99002553 SCREW-#8X7/16 HEX WASHER HEAD Note: SCREW, VALVE 99002628 VALVE, WATER 99002975 VALVE, WATER 911856 CLAMP, SPRING 99002852 HOSE, INJECTOR N 99002955 FOAM BLOCK, AIR/WATER INLET Note: (APPLY TO PLASTIC TUB BELOW AIR WATER INLET) 99002646 SEAL, AIR/WATER INLET...
- Page 11 Section: TUB Model: MDB8600AWS DW13-94...
- Page 12 Section: Part No. Description Series Qty Y913079 O-RING, HEATER 99002690 STRIP, TRIM/MOUNTING (LT) 99002692 SCREW, TRIM MOUNTING 99002723 STRIP, TRIM/MOUNTING (TOP) 99002691 STRIP, TRIM/MOUNTING (RT) 99002692 SCREW, TRIM MOUNTING 99002701 GAP SEAL, TOE KICK (BLK) 99002859 SUPPORT, FRONT (W/SEALS)(BLK) 912366 SCREW --++*** Note: SCREW, SUPPORT (BLK) 99002765 PANEL, TOE (W/DAMPER-BLK)
- Page 13 Section: WATER DISTRIBUTION ASSEMBLY Model: MDB8600AWS DW14-60...
- Page 14 Section: WATER DISTRIBUTION ASSEMBLY Part No. Description Series Qty 99002738 MANIFOLD, MAIN MULTI-LEVEL 99002643 BRACKET, MANIFOLD MOUNTING W10124350 NOT REQUIRED PART OR SEE NOTE Note: (PART NO LONGER NEEDED AT SERIES 25) 99002846 FILTER, OVER-PRESSURE (W/CVR) 99002674 STATION, DOCKING (W/FLAPPER) 99002676 WASH ARM, TOP (W/RETAINER) 99002753...
- Page 15 Section: PUMP & MOTOR Model: MDB8600AWS DW14-59...
-
Page 16: Pump & Motor
Section: PUMP & MOTOR Part No. Description Series Qty 99002654 CAP, WASH ARM 99002678 WASH ARM, LOWER (W/SHIELDS) 99002653 SHIELD, RADIANT 99002666 SCREW Note: SCREW, GUARD 99002655 GUARD, FILTER (GRAY) 99002677 DISCHARGE HOUSING ASSY (UPR) 99002664 SCREW, DISCHARGE HOUSING 99002741 WASH IMPELLER ASSEMBLY 99002660 SCREW, IMPELLER... - Page 17 Section: WIRING INFORMATION Model: MDB8600AWS 15003043...
- Page 18 Section: RACK ASSEMBLY (MIDDLE/LWR) Model: MDB8600AWS DW15-100...
- Page 19 Section: RACK ASSEMBLY (MIDDLE/LWR) Part No. Description Series Qty 99002905 CAP, RACK (DARK GRAY) 99002727 RACK ASSEMBLY (MIDDLE) 99003207 RACK ASSEMBLY (MIDDLE) 99002853 SNUGGER, RACK Y00000000 SEE NOTE Note: FOR RIGHT TINE ORDER FRONT TINE ASSY(PART 99003639) Y00000000 SEE NOTE Note: FOR LEFT TINE ORDER FRONT TINE ASSY(PART 99003639) 99002737 LATCH, FOLD AWAY TINE (FRT)
