Page 1: Table Of Contents
Owner’s Manual SLIMLINE BUILT-IN OVENS AND HOBS 600C CONTENTS 600S Unpacking 600ST Cupboard Design 600STW Electrical Installation Installation Under-Counter Installation Eye-Level Installation Hob Installation Safety Advice The Control Panel Conventional Oven Thermofan Oven Warmer Drawer Ringer Timer Solid Plates Ceran Smooth Top... -
Page 2: Unpacking
INTRODUCTION Congratulations on the purchase of this quality product. We trust that you will enjoy many years of trouble free use. Please read these instructions carefully before using the oven and hob. This manual will provide you with information on how to operate and care for your product in order that you gain the maximum benefit from it. -
Page 3: Installation
INSTALLATION Note: The oven cavity must vent through the front only. Avoid gaps between the • cavity sides and the underside of the worktop Insert the oven into the cupboard. • Open the door to expose the fixing holes in the side trims. •... -
Page 4: Eye-Level Installation
NOTE Defy Slimline undercounter ovens may be installed at eye level if so desired. This will require the purchase of a wiring extension kit (part No. 061120) from the nearest Defy Service Centre EYE-LEVEL INSTALLATION model 600C, optional for 600S and 600ST... -
Page 5: Safety Advice
• Avoid spilling fruit juice, particularly citrus, on the oven as it could damage the enamel. • Always keep the oven door gasket clean as this will enable the door to seal properly. THE CONTROL PANEL 600C Eye level oven 600S Under-counter oven... -
Page 6: Conventional Oven
CONVENTIONAL OVEN (Model 600C and 600S) Baking Set the oven thermostat to the required temperature. • The thermostat indicator light will glow and remain on until the oven has reached the • selected temperature. The light will then switch off. -
Page 7: Thermofan Oven
THERMOFAN OVEN Registered by Defy in 1978, Thermofan cooking differs from conventional cooking in that it uses the principle of forced convection within the oven. The advantages are: 1. Both trays may be used at the same time. 2. Different dishes can be cooked simultaneously without flavour or aroma transfer. -
Page 8: Warmer Drawer
Grilling The oven door must remain closed during grilling • Use only a wire shelf when grilling as the intense heat could warp the baking trays. • Set the oven thermostat to the grill position • Pre-heat the roast pan and broiler for 5 minutes under the grill element to help seal the •... -
Page 9: Solid Plates
To prevent rust, periodically apply some sewing machine oil or electrical hotplate • polish - available from Defy Service Centres. Extra attention is required in areas of high humidity or in close proximity to the sea. NOTE: THE WARRANTY DOES NOT COVER THE REPLACEMENT OR REPAIR OF RUSTED OR CORRODED PLATES. -
Page 10: Ceran Smooth Top
Clean the hob with a nylon pad and ‘Smooth top cleaner’. A sample tube of cleaner is • supplied with the unit and replacements are available from all Defy service centres. If necessary stubborn spills may be removed using the blade scraper provided. -
Page 11: Maintenance
Failure to observe this precaution would allow the element to rest on and possibly damage the oven enamel. (models 600C and 600S) General cleaning Switch off the electrical power supply before cleaning any part of the appliance. - Page 12 MAINTENANCE continued Lift-off oven door The oven door may be removed to improve oven access during cleaning Grasp the open door on Lift the door upwards and Flip the retainer clasps up both sides near the hinges outwards until it is free of and over the hook on the the hinge housing upper hinge arm .
-
Page 13: Problem Check
• SERVICE If you have followed the instructions and still have a problem, contact the nearest Defy Service Centre. They will be able to advise you on any aspect of the product or send a qualified technician to repair it. -
Page 14: Features
FEATURES Eye level oven 600 C 600 S 600ST 600 STW Under counter oven Warming drawer White or black cosmetics Thermofan oven Conventional oven Grill element Ringer timer Air vented “cool door” Full glass door Removable door Removable inner door glass Roast pan and broiler Baking trays Chromed wire shelves...
Need help?
Do you have a question about the 600C and is the answer not in the manual?
Questions and answers
The oven of our Defy Slimline 600 S gets extremely hot and eventually burns the food but the electrician tells us it is the thermometer which is not available anymore. Please advise
If the thermometer part is no longer available and the Defy Slimline 600 S oven is overheating, follow these steps:
1. Check Thermostat Function: The thermostat controls oven temperature. If it's faulty, the oven may overheat. A technician can test and possibly replace it with a compatible part.
2. Inspect Oven Selector Switch: Ensure the switch correctly engages with the desired cooking mode. A malfunctioning selector can cause incorrect temperature regulation.
3. Avoid Using Grill or Fan Modes Unintentionally: The oven has multiple modes (e.g., Thermofan bake, grill). Ensure the correct mode is selected for your cooking.
4. Contact Service Centre: If the thermostat or other parts are unavailable or if the issue persists, contact the nearest Defy Service Centre. A qualified technician may suggest a compatible part or repair solution.
Do not continue using the oven if it overheats, as this may be unsafe.
This answer is automatically generated
The heat of 3 of the 4 plates don't regulate. It stay very hot, no matter if the dail is on 1 or 8. What can I do?
If the heat of 3 out of 4 plates on a Defy 600C does not regulate properly, check the plate controls by turning the knobs to various settings to see if any heat level changes occur. If the issue persists, the plate regulators or thermostats may be faulty and require inspection or replacement. It is recommended to contact a qualified service technician or a Defy Service Centre for repair.
This answer is automatically generated
