Wheelock EN4 Installation Instructions

Indoor/outdoor strobe appliance enclosure

Advertisement

273 Branchport Avenue
Long Branch, NJ 07740
(800) 631-2148
www.wheelockinc.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Indoor/Outdoor Strobe Appliance Enclosure, Model EN4, is designed to be used with Wheelock's Series RSS Strobe Appliance. The
EN4 enclosure, rated as a NEMA 4 enclosure, provides protection from windblown dust, rain and snow. The EN4 enclosure is UL
Listed for use, both indoors or outdoors, in areas with a temperature range from 0˚ C (32˚ F) to 49˚ C (120˚ F). See Table 1 below for
UL listed candela (cd) ratings of the RSS Strobe when using the EN4 Enclosure.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. FAILURE
TO COMPLY WITH ANY OF THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN
IMPROPER APPLICATION, INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY
SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU
AND/OR OTHERS.
WARNING: DO NOT USE THE EN4 ENCLOSURE IN INSTALLATIONS WHERE TEMPERATURES MAY FALL
OUTSIDE OF THE UL LISTED TEMPERATURE RANGE
OR FAILURE OF, NOTIFICATION APPLIANCE MAY RESULT.
WARNING: DO NOT SET THE MULTI-CANDELA STROBE APPLIANCE ON THE 15cd SELECTION.
REDUCED LIGHT OUTPUT RATING FOR THE 15cd SELECTION WILL NOT MEET THE MINIMUM
REQUIREMENTS OF NFPA 72. USE SETTINGS OF 30cd OR HIGHER.

SPECIFICATIONS:

Table 1: UL Candela Ratings for Series RSS Strobe when using EN4 Enclosure.
Refer to Series RSS (P83500 and P83501), RSS Multi-Candela Wall (P83911) and RSS Multi-Candela Ceiling (P84394) Installation
Instructions for additional information.
Copyright 2003, 2004 Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
INDOOR/OUTDOOR STROBE APPLIANCE ENCLOSURE
Multi Candela Series
(Selectable)
Candela
Model No's
Setting
30cd, 75cd,
RSS-24MCW
110cd
30cd,
RSS-24MCC
75cd, 95cd
EN4
. All warnings are printed in bold capital letters.
TEMPERATURE [0˚ C (32˚ F) TO 49˚ C (120˚ F)]
Audible/Strobe
Combinations
(Non-Selectable)
Model No. *
RSS-2430W
RSS-2475W
RSS-24110W
RSS-2430C
RSS-2475C
RSS-24100C
AS DAMAGE TO,
Strobe
Candela
(cd)
Using EN4
21.0
52.5
77.0
21.0
52.5
70.0
THE
P83937 E
Sheet 1 of 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EN4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wheelock EN4

  • Page 1 Indoor/Outdoor Strobe Appliance Enclosure, Model EN4, is designed to be used with Wheelock’s Series RSS Strobe Appliance. The EN4 enclosure, rated as a NEMA 4 enclosure, provides protection from windblown dust, rain and snow. The EN4 enclosure is UL Listed for use, both indoors or outdoors, in areas with a temperature range from 0˚ C (32˚ F) to 49˚ C (120˚ F). See Table 1 below for UL listed candela (cd) ratings of the RSS Strobe when using the EN4 Enclosure.
  • Page 2: Mounting Information

    MOUNTING INFORMATION: HORIZONTAL CENTERLINE OF ENCLOSURE CENTERLINE MOUNTING HEIGHT 80" FRONT VIEW OF ENCLOSURE INSERT THE (4) EXTERNAL MOUNTING TABS INTO ENCLOSURE SLOTS AS SHOWN. USING ENCLOSURE ASSEMBLY AS TEMPLATE, PLACE AGAINST MOUNTING SURFACE WITH CENTERLINE 80 INCHES ABOVE FLOOR, MARK AND DRILL (4) HOLES 1/4"...
  • Page 3: Limited Warranty

    DOCUMENTS DESCRIBING THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS, OR FOR ANY OTHER USE, INCLUDING DESCRIPTION OF THE PRODUCT'S APPLICATION, OPERATION, INSTALLATION AND TESTING IS USED AT THE SOLE RISK OF THE USER AND WHEELOCK WILL NOT HAVE ANY LIABILITY FOR SUCH USE.
