Page 1: Washing Machine
WM85135LW Washing Machine User's Manual Document Number 2820522882/ 21-04-12.(15:18) - Page 2 Please read this user manual first! Dear Customer, Thank you for prefering an Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important instructions for safety and 5.8 Temperature selection....23 environment 5.9 Spin speed selection....23 5.10 Programme and consumption table. -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that • Do not force open the locked loading door. The will help protect from risk of personal injury loading door will be ready to open just a few or property damage. Failure to follow these minutes after the washing cycle comes to an instructions shall void any warranty. -
Page 5: Children's Safety
Important instructions for safety and environment 1.3 Children's safety 1.6 Compliance with WEEE Directive • Packaging materials are dangerous to children. This appliance’s packaging material is Keep packaging materials in a safe place away recyclable. Help recycle it and protect from reach of the children. the environment by dropping it off in • Electrical products are dangerous for the the municipal receptacles provided for... -
Page 6: Your Washing Machine
Your washing machine 2.1 Overview 1- Power cable 5- Adjustable feet 2- Top panel 6- Loading door 3- Control panel 7- Detergent drawer 4- Filter cap 8- Drain hose 6 / 40 EN Washing Machine /User’s Manual... -
Page 7: Package Contents
Your washing machine 2.2 Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronical water shut-off a- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual... -
Page 8: Technical Specifications
Your washing machine 2.3 Technical specifications Models (EN) WM85135LW Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) 230 V / 50Hz Electrical input (V/Hz) Total current (A) 2200 Total power (W) 1300 Spin speed (rpm max.) 1.40... -
Page 9: Installation
Installation 3.2 Removing packaging Refer to the nearest Authorised Service Agent for installation of the product. To make the product reinforcement ready for use, review the information in the user Tilt the machine backwards to remove the manual and make sure that the electricity, tap packaging reinforcement. -
Page 10: Connecting Water Supply
Installation inlet. Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the future. WARNING: Ensure that the cold and hot Never move the product without the water connections are made correctly when transportation safety bolts properly fixed installing the product. -
Page 11: Adjusting The Feet
Installation 3.6 Adjusting the feet • The hose should be attached to a height of at least 40 cm, and 100 cm at most. WARNING: In order to ensure that • In case the hose is elevated after laying it on the product operates more silently and the floor level or close to the ground (less than vibration-free, it must stand level and 40 cm above the ground), water discharge balanced on its feet. -
Page 12: Electrical Connection
Installation Destroy the old plug, which is cut off as a plug WARNING: Do not use any tools to with a bared cord could cause a shock hazard if loosen the lock nuts. Otherwise, they will inserted into a socket elsewhere in the house. get damaged. - Page 13 Installation Transportation of the product 1. Unplug the product before transporting it. 2. Remove water drain and water supply connections. 3. Drain all water that has remained in the product. See 7.5 4. Install transportation safety bolts in the reverse order of removal procedure;...
-
Page 14: Preparation
Preparation 4.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying Suitable for No Iron Do not dry- Sensitive / Do not dry Do not dry Symbols... -
Page 15: Preparing Laundry For Washing
Preparation 4.2 Preparing laundry for washing but do not overload; see, "Programme and consumption table". • Laundry items with metal attachments such as, • Always follow the instructions on the detergent underwired bras, belt buckles or metal buttons packaging. will damage the machine. Remove the metal • Wash slightly soiled laundry at low pieces or wash the clothes by putting them in a temperatures. -
Page 16: Correct Load Capacity
Preparation 4.5 Correct load capacity 4.7 Using detergent and softener The maximum load capacity depends on the type When using detergent, softener, starch, of laundry, the degree of soiling and the washing fabric dye, bleach or limescale remover programme desired. read the manufacturer's instructions The machine automatically adjusts the amount on the package carefully and follow the... - Page 17 Preparation Using liquid detergents • Use different detergents for coloured and white laundry. If the product contains a liquid detergent cup: • Wash your delicate clothes only with special • Make sure that you have placed the liquid detergents (liquid detergent, wool shampoo, detergent cup in compartment nr. "2". etc.) used solely for delicate clothes. • If the liquid detergent has lost its fluidity, dilute • When washing dark coloured clothes and quilts, it with water before putting in the detergent it is recommended to use liquid detergent.
- Page 18 Preparation Using limescale remover Tablet detergents may leave residues • When required, use limescale removers in the detergent compartment. If you manufactured specifically for washing machines encounter such a case, place the tablet only. detergent between the laundry, close to the lower part of the drum in future washings.
-
Page 19: Tips For Efficient Washing
Preparation 4.8 Tips for efficient washing Clothes Light colours and Delicates/Woolens/ Colours Dark colours whites Silks (Recommended (Recommended (Recommended (Recommended temperature range temperature range temperature range temperature range based on soiling level: based on soiling level: based on soiling based on soiling 40-90ºC) cold-40ºC) level: cold-40ºC) -
Page 20: Operating The Product
Operating the product 5.1 Control panel Spin Speed Adjustment button On / Off button Display Delayed Start buttons (+ / -) Temperature Adjustment button Auxiliary Function buttons Programme Selection knob Start / Pause / Cancel button 5.2 Display symbols - Spin Speed indicator - Temperature indicator - Spin symbol - Temperature symbol... -
Page 21: Preparing The Machine
Operating the product 5.3 Preparing the machine •Synthetics Use this programme to wash your synthetic 1. Make sure that the hoses are connected tightly. clothes (shirts, blouses, synthetic/cotton blends, 2. Plug in your machine. etc.). It washes with a gentle action and has a 3. -
Page 22: Special Programmes
Operating the product • Hand wash • Self Clean Use this programme to wash your woolen/delicate Use this programme regularly (once in every clothes that bear “not machine- washable” tags 1-2 months) to clean the drum and provide the and for which hand wash is recommended. It required hygiene. -
Page 23: Temperature Selection
Operating the product 5.8 Temperature selection 5.9 Spin speed selection Whenever a new programme is selected, Whenever a new programme is selected, the the maximum temperature for the selected recommended spin speed of the selected programme appears on the temperature indicator. programme is displayed on the spin speed indicator. -
Page 24: Programme And Consumption Table
Operating the product 5.10 Programme and consumption table Auxiliary functions Selectable Programme (°C) temperature range °C Cottons 2.40 1600 • • • • • • 90-Cold Cottons 1.70 1600 • • • • • • 90-Cold Cottons 0.95 1600 • •... -
Page 25: Auxiliary Function Selection
Operating the product 5.11 Auxiliary function selection • Quicker Wash This function can be used in Cottons and Select the desired auxiliary functions before Synthetics programmes. It decreases the washing starting the programme. Furthermore, you may times and also the number of rinsing steps for also select or cancel auxiliary functions that are lightly soiled laundry. -
Page 26: Time Display
Operating the product • Pet hair removal 3. Set the desired delayed start time by pressing the Delayed Start + or - buttons. Delayed Start This function helps to remove pet hair that remain symbol flashes. on your garments more effectively. 4. -
Page 27: Starting The Programme
Operating the product 5.13 Starting the programme 5.15 Loading door lock 1. Press Start / Pause / Cancel button to start the There is a locking system on the loading door of programme. the machine that prevents opening of the door in 2. -
Page 28: Child Lock
Operating the product 5.18 Cancelling the programme 4. Close the Loading Door. 5. Make changes in auxiliary functions, Press and hold Start / Pause / Cancel button temperature and speed settings if necessary. for 3 seconds. Start symbol flashes. Symbol of 6. -
Page 29: Quick User Guide
Quick User Guide 6.1 Preparing the machine 6.6 Cancelling the programme 1. Make sure that the hoses are connected tightly. Press and hold Start / Pause / Cancel button 2. Plug in your machine. for 3 seconds. Start symbol flashes. Symbol of 3. -
Page 30: Maintenance And Cleaning
Maintenance and cleaning Service life of the product extends and frequently If your detergent drawer is the one indicated in the faced problems decrease if cleaned at regular following figure: intervals. 7.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 31: Cleaning The Body And Control Panel
Maintenance and cleaning 2. Remove the nuts of the water intake hoses to access the filters on the water intake valves. Clean them with an appropriate brush. If the filters are too dirty, take them out by means of pliers and clean them. 3. - Page 32 Maintenance and cleaning c. When draining of water is finished, close the end by the plug again and fix the hose in its place. d. Turn the pump filter to take it out. Discharging the water when the product does not have an emergency draining hose: If the filter cap is one piece, pull the cap from both sides at the top to open.
-
Page 33: Troubleshooting
Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> Press and hold Start / Pause / Cancel button for 3 seconds to reset the machine to factory settings. Water in the machine. • Some water might have remained in the product due to the quality control processes in the production. >>> This is not a failure; water is not harmful to the machine. There is water leaking from the bottom of the washing machine. - Page 34 Troubleshooting Washing takes longer time than specified in the manual.(*) • Water pressure is low. >>> Machine waits until taking in adequate amount of water to prevent poor washing quality due to the decreased amount of water. Therefore, the washing time extends. • Voltage might be low. >>> Washing time is prolonged to avoid poor washing results when the supply voltage is low.
- Page 35 Troubleshooting Washing performance is poor: Stains persist or the laundry is not whitened.(**) • Insufficient amount of detergent is used. >>> Use recommended amount of detergent appropriate for the laundry. • Excessive laundry was loaded in. >>> Do not load the machine in excess. Load with amounts recommended in the "Programme and consumption table". • Wrong programme and temperature were selected. >>> Select the proper programme and temperature for the laundry to be washed.
- Page 36 Troubleshooting Detergent residue in the detergent drawer.(**) • Detergent is put in wet drawer. >>> Dry the detergent drawer before putting in detergent. • Detergent has gotten damp. >>> Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. • Water pressure is low. >>> Check the water pressure. • The detergent in the main wash compartment got wet while taking in the prewash water. Holes of the detergent compartment are blocked. >>> Check the holes and clean if they are clogged.
- Page 37 Troubleshooting Machine does not start. Nothing appears on the display. Machine may be unplugged. >>> Check the plug and attach it to the socket. Fuse may be defective. >>> Check the fuse and have it replaced by a qualified electrician if necessary. Power may be out. >>> Check if there is any power outage. On / Off button might not be pressed. >>>...
-
Page 38: Product Fiche
PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 1061/201 Supplier name or trademark Beko Model name WM85135LW Rated capacity (kg) Energy efficiency class Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load 1.389 (kWh) Energy consumption of the standard 60°C cotton programme at partial load... - Page 39 If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 600 4911 e-mail:service@beko.co.uk...
- Page 40 Guarantee Your new Beko product is guaranteed against the cost of breakdown repairs for twelve months from the date of the original purchase. What is covered? • Repairs necessary as a result of faulty materials, defective components or manufacturing defect. • The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse. • Cabinet or appearance parts, including knobs, flaps, handles or container lids.
