Secure, reliable, intelligent,
SNMP managed switching for
growing businesses
The Linksys WebView Managed switch allows you to expand your network securely.
Configuration of the switch is secured using SSL for Web access and SSH for Telnet
access. User control is secured using 802.1x security using a RADIUS authentication
mechanism and can also be controlled using MAC filtering.
Extensive Quality of Service (QoS) features make the solution ideal for real-time
applications like Voice and Video. The 4 priority queues together with the Weighted
Round Robin and Strict Priority scheduling techniques facilitate efficient co-existence
of real-time traffic with data traffic allowing them each to meet their QoS needs.
Individual users or applications can be prioritized above others using various Class
of Service options – by port, Layer 2 priority (802.1p), Layer 3 priority (TOS or DSCP),
or IPv6 Traffic Class. Intelligent Broadcast, Multicast, and Unknown Unicast storm control
minimizes and contains the effect of these types of traffic on regular traffic. IGMP
Snooping limits bandwidth-intensive video traffic to only the requestors without
flooding to all users. Incoming traffic can be policed and outgoing traffic can be shaped
allowing you to control network access and traffic flow.
There are features that allow you to expand and grow your network of switches. Link ag-
gregation allows multiple high-bandwidth trunks between switches to be setup. Spanning
Tree, Rapid Spanning Tree, and Multiple Spanning Tree allow you to build a mesh of switch-
es increasing the availability of the system. This also provides a level of reliability in that the
system continues to operate even if one of the links breaks.
The rich management functionality of the WebView switches includes SNMP, RMON, Telnet,
and HTTP Management options, allowing you to flexibly integrate and manage these devices
in your network.
• Optimized for growing
businesses with 4 expandable
Gigabit Ports
• Secure management via SSH/SSL
and secure user control via
802.1x & MAC filtering
• IGMP snooping, L2/L3 COS,
queuing & scheduling makes
solution ideal for Voice/Video
• Intelligent traffic management
with Rate Limiting, Policing,
Shaping, and Storm Control
SRW224G4
Model No:
24-Port 10/100
+ 4-Port Gigabit
Switch
with WebView
PRODUCT SHEET
BUSINESS SERIES
Advertisement
Related Manuals for Linksys 24-Port 10/100 + 4-Port Gigabit
Summary of Contents for Linksys 24-Port 10/100 + 4-Port Gigabit
- Page 1 Secure, reliable, intelligent, 24-Port 10/100 SNMP managed switching for + 4-Port Gigabit growing businesses Switch with WebView The Linksys WebView Managed switch allows you to expand your network securely. Configuration of the switch is secured using SSL for Web access and SSH for Telnet access.
- Page 2 24-Port 10/100 + 4-Port Gigabit Switch with WebView Features • 24 - 10/100 Switched RJ-45 ports deliver up to 200Mbps of throughput per port • 4 - 10/100/1000 Switched RJ-45 Gb Uplink Ports (with 2 shared mini-GBIC ports) • Switching capacity delivers 12.8 Gig non-blocking capacity •...
- Page 3 Specifications Ports 24 RJ-45 connectors for 10BASE-T and 100BASE-TX, 4 RJ-45 connectors for 10BASE-T/100BASE-TX/1000BASE-T with 2 shared SFP slots, Auto MDI/MDI-X, Autonegotiate/Manual setting Cabling Type UTP Cat5 or better for 10BASE-T/100BASE-TX, UTP Cat5e or better for 1000BASE-T LED Indicators Power, Link/Act, Speed Performance Switching Capacity 12.8 Gig non-blocking...
- Page 4 BUSINESS SERIES Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
