Hardware Overview
Notification LED1
Green: Wi-Fi on
Blue: Bluetooth on
Start here.
Pharos 565 PDA
Soft Key
Configurable Key *
Start
* You can assign a specific program to a configurable key. Tap Start > Settings > Personal > Buttons, select one of these
configurable keys, and then assign a program to the selected key.
Notification LED2
Red: Low Power
Orange: Charging
Speaker
Touch Screen
Soft Key
Configurable Key *
OK
Navigation Pad
QWERTY Keypad
Stylus
Stylus
Scan Key (PTL565S)
Belt Holder 1
Power
Volume Up
Back Cover Latch
Volume Down
Configurable Key *
Reset
Back Cover
Belt Holder 2
NOTE The availability of particular features and applications for the device may vary by the model that you purchased.
Please check with your dealer for details.
IrDA Port (PTL565E)
Barcode Scanner (PTL565S)
Scan Key (PTL565S)
Earphone Jack
Card Slot
18pin IO Connector
