Summary of Contents for Pharos Traveler 535v
-
Page 1: Pharos Traveler Gps 535V
Handheld English EasyGuide Pharos Traveler GPS 535v... - Page 3 Are there ..any technical problems or other questions which you would like to be clarified? Please contact: • our Hotline/Help Desk • your sales partner • your sales outlet The latest information on our products, tips, updates, etc., can be found on the internet at: www.pharosgps.com...
- Page 4 Pharos Traveler GPS 535v EasyGuide March 2008 Your Pharos Traveler GPS 535v Important notes Operating the Pharos Traveler GPS 535v Configuring the Pharos Traveler GPS 535v Connecting and networking the Pharos Traveler GPS 535v with other devices Troubleshooting and tips...
- Page 5 Adobe and Acrobat are trademarks of Adobe systems Incorporated and may be protected in certain countries. Intel is a registered trademark, XScale is trademark of Intel Corporation, U.S.A. Microsoft, Windows and ActiveSync are registered trademarks of the Microsoft Corporation. Windows Mobile is a trademark of Microsoft Corporation. The SD Logo is a trademark of Secure Digital.
-
Page 6: Table Of Contents
Switching Pharos Traveler GPS 535v off and on ... 22 Switching Pharos Traveler GPS 535v off and on during normal use ... 22 Switching the Pharos Traveler GPS 535v on and off to save the batteries ... 23 Switching on and off with soft reset (warm boot) ... 24 Resetting the Pharos Traveler GPS 535v (Cold start) ... - Page 7 Assigning chosen functions to the hardware buttons ... 40 Connecting and networking the Pharos Traveler GPS 535v with other devices ... 41 Wireless data transfer with infrared interface ... 41 Wireless connection via Wireless LAN ... 41 Wireless communication with Bluetooth ... 42 Selecting location for Bluetooth operation ...
- Page 8 For example, you can access the Internet using the Pharos Traveler GPS 535v with a wireless LAN connection at your favorite coffee shop. You can call up both web and WAP pages with the Internet Explorer.
-
Page 9: Notational Conventions
Failure to follow the instructions may lead to loss of data, invalidate your warranty, destroy the Pharos Traveler GPS 535v, or endanger your life. indicates important information which is required to use the system properly. -
Page 10: Software Overview
Software overview The following table provides an overview of the most important programs which are already installed on your Pharos Traveler GPS 535v and where you can find information on using these programs. Software Used for Word Mobile For word processing... -
Page 11: Important Notes
The WLAN radio components are initialized and become active for a short period if the batteries of the Pharos Traveler GPS 535v are changed or it is reset (cold boot or returned to delivery condition). Be aware of this if you are in an environment where radio components must not be... -
Page 12: Underway With The Pharos Traveler Gps 535V
Protect the Pharos Traveler GPS 535v from severe shocks and extreme temperatures (e.g., direct sunlight in a car). • If you wish to use your Pharos Traveler GPS 535v during a flight, check first with the airline if this is allowed and under which conditions. •... -
Page 13: Using The Pharos Traveler Gps 535V
Using the Pharos Traveler GPS 535v Store the Pharos Traveler GPS 535v in a fully charged state in a dry environment. If you store the Pharos Traveler GPS 535v for up to a month, the storage temperature should be between -20°C and +60°C. -
Page 14: Ce Marking
CE marking Products bearing the CE marking comply with the R&TTE Directive (1999/5/EC), EMC Directive (89/336/EEC), and the Low Voltage Directive (2006/95/EEC) issued by the Commission of the European Community. CE compliance of this device is valid only if powered with by a CE-marked AC Adapter provided by HTC. -
Page 16: Operating The Pharos Traveler Gps 535V
Operating the Pharos Traveler GPS 535v In this section you will find a description of the operating controls of your Pharos Traveler GPS 535v and how you operate the Pharos Traveler GPS 535v. Follow the instructions in the chapter "Important notes". -
Page 17: Back Of The Pharos Traveler Gps 535V
Back of the Pharos Traveler GPS 535v Navigation button (N) Today button Navigation key Contacts button Calendar button Slot for SD/MMC expansion cards Port for headphones or active loudspeakers Battery compartment cover Port for external GPS antenna (optional) -
Page 18: Displays (Power-On Display And Radio Display)
Please follow these steps in the given order! Before the first data synchronization between your Pharos Traveler GPS 535v and your PC/notebook, you must install the ActiveSync program on your PC/notebook. In just a few steps your Pharos Traveler GPS 535v is ready to use the first time: • Insert the battery •... -
Page 19: Inserting Battery
Inserting battery ► Pull the cover (1) off the Pharos Traveler GPS 535v in the direction of the arrow. ► Lay the battery in the battery compartment (2 +3). When doing so, watch the contact connections and hold onto the tab (4). -
Page 20: Connecting Power Adapter
Connecting Power adapter Follow the instructions in the chapter "Important notes". You can connect the Power adapter directly to the Pharos Traveler GPS 535v. ► If your power adapter includes a separate plug as shown in the figure, slide the power adapter plug into the Power adapter in the direction of the arrow until it engages. - Page 21 ► Connect the ActiveSync cable (1) to the ActiveSync port on the Pharos Traveler GPS 535v. ► Connect the power adapter cable (2) to the DC socket of the ActiveSync cable. ► Connect the Power adapter (3) to an electrical outlet.
-
Page 22: Installing Activesync On Your Pc/Notebook
GPS 535v. The ActiveSync cable and the ActiveSync software are provided for data synchronization. ActiveSync is already installed on your Pharos Traveler GPS 535v. You need only install ActiveSync on your PC or notebook. You will find the ActiveSync program and the necessary driver on the Microsoft Getting Started CD. -
Page 23: Start The Pharos Traveler Gps 535V For The First Time
Pull out the pen (2) in the direction of the arrow. Adjusting touchscreen The display of your Pharos Traveler GPS 535v is a touchscreen. To ensure that the touchscreen of your Pharos Traveler GPS 535v reacts correctly when touched with the stylus, you will be asked to align the touchscreen after the initial start-up. -
Page 24: First Data Synchronization Between The Pharos Traveler Gps 535V And The Pc/Notebook
Switch the Pharos Traveler GPS 535v on or off with the Suspend/Resume button. After certain applications or the installation of new programs, it may be necessary to restart the Pharos Traveler GPS 535v with the soft reset. It is rarely necessary to reset the Pharos Traveler GPS 535v to the delivered state. -
Page 25: Switching The Pharos Traveler Gps 535V On And Off To Save The Batteries
Press the Suspend/Resume button (1) for more than 1 second. All programs are closed and the Pharos Traveler GPS 535v is completely switched off. The Pharos Traveler GPS 535v does not use any more power. You can store the Pharos Traveler GPS 535v for several weeks. -
Page 26: Switching On And Off With Soft Reset (Warm Boot)
After certain applications or the installation of new programs, it may be necessary to restart the Pharos Traveler GPS 535v with the soft reset. Unsaved data is lost. Shut down all programs before you restart the Pharos Traveler GPS 535v. -
Page 27: Resetting The Pharos Traveler Gps 535V (Cold Start)
Resetting the Pharos Traveler GPS 535v (Cold start) If your Pharos Traveler GPS 535v locks up and switching it on and off with the suspend/resume button and soft reset has no effect, you can reset your Pharos Traveler GPS 535v. -
Page 28: Resetting Pharos Traveler Gps 535V To Delivered State
The reset can take a few minutes. At the end an acoustic signal sounds. Please follow the further instructions on the display. When you reset your Pharos Traveler GPS 535v to the delivered state, the battery switches off so that the RAM content is lost. This means: You lose all data (documents, additionally installed programs, personal settings) that you haven't saved elsewhere. -
Page 29: Using Standard Operating Elements
Using standard operating elements Using the pen ► Briefly touch the desired element on the display with the stylus to trigger an action. ► To activate popup menus, also touch the desired element with the stylus; however allow the stylus to rest on the element for a moment. The popup menu appears and you can select an element by touching it. -
Page 30: Using The Application Buttons
Using the application buttons With the application buttons and the appropriate preset (see chapter "Configuring the Pharos Traveler GPS 535v"), you can open your preferred programs and applications directly from suspend mode or from within an application. Because the application button react differently to short or long keystrokes you can assign a total of eight different programs or applications to the application buttons. -
Page 31: Inserting And Removing Expansion Card
Press on the edge of the placeholder (1) so that the placeholder is pushed out of the slot somewhat. ► Pull the placeholder out of the Pharos Traveler GPS 535v (2). ► Carefully push the expansion card (3) into the slot. -
Page 32: Removing Expansion Card
Press on the edge of the expansion card (1) so that the expansion card jumps out of the slot slightly. ► Slide the expansion card out of the Pharos Traveler GPS 535v (2). ► Insert the placeholder (3) again into the slot if necessary. -
Page 33: Underway With The Pharos Traveler Gps 535V
The external GPS antenna is available as an accessory. Charging the battery Your Pharos Traveler GPS 535v is equipped with a powerful battery. When you're on the road your Pharos Traveler GPS 535v is supplied with power by the integrated battery. - Page 34 Follow the instructions on the Power adapter in the section "Connecting Power adapter ". Charging the battery directly via the Power adapter You can connect the Power adapter directly to the Pharos Traveler GPS 535v. There are two ways to do this: •...
- Page 35 Connecting Power adapter to Pharos Traveler GPS 535v with adapter ► Connect the adapter (1) to the ActiveSync port of the Pharos Traveler GPS 535v. ► Connect the power adapter cable (2) to the adapter. ► Connect the Power adapter (3) to an electrical outlet.
-
Page 36: Charging The Battery Via A Usb Port
In the system settings you can make settings that help you save energy when using your Pharos Traveler GPS 535v. These settings enable you to use the battery operating time optimally. -
Page 37: Synchronizing Data With Activesync
Synchronizing data with ActiveSync To have the current version of the data you have processed on the road on your Pharos Traveler GPS 535v available on your PC/notebook, you must copy this data to your PC/notebook. This procedure is conveniently enabled with data synchronization:... -
Page 38: Connecting The Pharos Traveler Gps 535V With Pc/Notebook
► Switch your PC or notebook on. ► Connect the ActiveSync cable (1) to the ActiveSync port on the Pharos Traveler GPS 535v. ► Connect the ActiveSync cable to a USB port (2) of your PC/notebook. The Pharos Traveler GPS 535v is now connected to your PC/notebook. The ActiveSync partnership between your Pharos Traveler GPS 535v and your PC/notebook will be established. -
Page 39: Configuring The Pharos Traveler Gps 535V
Configuring the Pharos Traveler GPS 535v You can choose from a large number of programs when you use the Pharos Traveler GPS 535v for the first time. In addition, default settings are defined for the menu structure, energy management, memory management and security functions. -
Page 40: Using Energy-Saving Functions
► Select the number of minutes after which the display lighting is to be switched off in the battery mode when the Pharos Traveler GPS 535v is not used under Start - Settings - System - Backlight. Reducing brightness ►... -
Page 41: Adjusting Menus
If a password has been entered, you will have to enter this password the next time you switch on. If you have forgotten your password, you can restart your Pharos Traveler GPS 535v by resetting it to the delivered state (see section "Resetting Pharos Traveler GPS 535v to delivered state"). -
Page 42: Configuring Hardware Keys
Configuring hardware keys Assigning chosen functions to the hardware buttons The buttons of your Pharos Traveler GPS 535v are assigned certain functions such as running programs. However, you can change these default settings and assign the buttons the functions of your choice. -
Page 43: Connecting And Networking The Pharos Traveler Gps 535V With Other Devices
Connecting and networking the Pharos Traveler GPS 535v with other devices The Pharos Traveler GPS 535v offers a wide range of ways to exchange data with other devices or to work in a network. You are already familiar with data synchronization via ActiveSync and the ActiveSync cable in the section "Synchronizing". -
Page 44: Wireless Communication With Bluetooth
Wireless communication with Bluetooth With your Pocket PC with an integrated Bluetooth module you can communicate wirelessly with other Bluetooth devices, e.g. with another Pocket PC, a notebook or a mobile phone. In the following sections, you will find out how to put Bluetooth into operation. The help file for the software on your Pocket PC explains how you operate the software concerned. -
Page 45: Troubleshooting And Tips
Troubleshooting and tips If a fault occurs in your Pharos Traveler GPS 535v, try to eliminate it with the measures described in this chapter. If you fail to correct the problem, proceed as follows: ► Make a note of the steps and the circumstances that led to the fault. Also make a note of any error messages displayed. -
Page 46: The Pharos Traveler Gps 535V Does Not Start After Switch On
The Pharos Traveler GPS 535v does not start after switch on If the Pharos Traveler GPS 535v does not start after switch on, this may be due to one of the following: The battery is dead. ► Charge the battery. -
Page 47: No Sound Or Minimal Volume
"Safety" and "Warranty" manuals. Please have the following information ready when you call: • The model name and serial number of the Pharos Traveler GPS 535v. The serial number is located on a sticker on the backside of the Pharos Traveler GPS 535v. •... -
Page 48: Technical Data
Technical data Pharos Traveler GPS 535v Processor: Intel PXA270 624 MHz Main memory: 128 Mbyte ROM 64 Mbyte RAM Electrical data Regulations complied with: CE, FCC Part 15 Class B, EN 60950, UL, cUL Protection class: Maximum power draw: 10 W... -
Page 49: Battery (Li-Ion)
Battery (Li-Ion) Rated capacity: 1200 mAh Charging time (when not in Max. 3 hours operation): Operating time: up to 12 hours Power adapter Primary: • Rated voltage: 100 V to 240 V (automatic) • Frequency: 50 Hz to 60 Hz (automatic) Secondary: •... -
Page 51: Index
Expansion card handling, 29 inserting, 29 removing, 30 Expansion card slot, 15 First start, 21 GPS, 31 indicator, 16 GPS antenna, 15 Hardware reset, 25 Hardware, overview, 14 Headphones port, 15 Hotline/Help Desk, 45 Indicator battery charge level, 16 Bluetooth, 16... - Page 52 Infrared interface, 14, 41 Initial start-up, 16 basic operation, 21 first start, 21 Today screen, 21 touchscreen, 21 Microphone, 14 Navigation button, 15 Navigation key, 15 No sound, 45 Notational conventions, 7 Notes CE marking, 12 cleaning, 11 disposal, 11 safety, 9 On/off time, 22 Operating, basically, 21...
- Page 53 Travel, Pocket PC, 10 Troubleshooting, 43 Using navigation key, 27 Using the application buttons, 28 Using the pen, 27 Volume, minimal, 45 Warm boot, 24 Wireless data transfer, 41, 42 Wireless indicator, 16 Wireless LAN, 41 WLAN, 41 indicator, 16...
