DENSITY DETERMINATION KIT
Applicable analytical balance models
BM series
GH series
HR-i series
GR series
HR series
HA series
1WMPD4000728B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Density Determination Kit AD-1653 BM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AND Density Determination Kit AD-1653 BM Series

  • Page 1 AD-1653 AD-1653 DENSITY DETERMINATION KIT Applicable analytical balance models BM series GH series HR-i series GR series HR series HA series 1WMPD4000728B...
  • Page 2 © 2012 A&D Company, Limited. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, or translated into any language in any form by any means without the written permission of A&D Company, Limited. The contents of this manual and the specifications of the instrument covered by this manual are subject to change for improvement without notice.
  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ....................2 1.1. Precautions......................2 UNPACKING THE KIT ..................3 DENSITY MEASUREMENT PRINCIPLES ............4 3.1. Density.......................4 3.2. Specific Gravity ....................4 3.3. Archimedes’ Principle of Density Measurement..........4 3.4. Density of a Solid ....................5 3.5. Density of a Liquid .....................5 ERROR FACTORS ....................6 4.1.
  • Page 4: Introduction

    INTRODUCTION Thank you for purchasing the AD-1653 Density Determination Kit. This manual describes how to use the AD-1653 Density Determination Kit. The AD-1653, when combined with one of our electronic balances (BM series, GH series, HR-i series, GR series, HR series and HA series), allows the density of a solid and liquid to be measured easily. Before using the AD-1653, please read this manual thoroughly and keep it at hand for future reference.
  • Page 5: Unpacking The Kit

    UNPACKING THE KIT Diameter of 0.2 mm Float Wire Float hook Thermometer B44342 B49799 C42200 B44813 Density pan stand Beaker stand Beaker Thermomeler clamp B31161 B31158 PYLEX-300ML 1-608-02 Density pan Attachment for FX (obsolete product) Attachment for HX (obsolete product) 1653-1 C42219 C42220...
  • Page 6: Density Measurement Principles

    DENSITY MEASUREMENT PRINCIPLES 3.1. Density Density refers to the total mass of a sample per unit volume. ρ (Unit: g/cm , etc.) ρ : Density M : Mass V : Volume 3.2. Specific Gravity Specific gravity refers to the ratio of the density of a sample to the density of pure water at 4°C under a pressure of 1013.25 hPa.
  • Page 7: Density Of A Solid

    3.4. Density of a Solid The density of a solid can be obtained according to the weight of the sample in air, the weight of the sample in liquid and the density of the liquid. ρ ρ - d) + d A - B ρ...
  • Page 8: Error Factors

    ERROR FACTORS There are several things that can affect the accuracy of a density measurement. 4.1. Buoyancy of Air A density measurement is influenced by an upward force of 0.0010 to 0.0014 g/cm (buoyancy of air). The density of air can be obtained by the equation below: 0.0012932 P (hPa) 1 + 0.0036728 x t (°C)
  • Page 9: Temperature Of Liquid

    4.3. Temperature of Liquid The density of the liquid that is used for measuring the density of a solid varies with the liquid temperature. Therefore, the decimal places beyond the first decimal place of the measured value contain errors. Obtain the density of a liquid according to the temperature from Table 1 for distilled water or from other reference documents for other liquids.
  • Page 10: Measuring The Density Of A Solid

    MEASURING THE DENSITY OF A SOLID Assemble the kit as described in the procedure below. Note that the assembly procedure depends on the balance model. 5.1. Assembling the Kit: BM / GH / HR-i Series Note: The kit can not be used with the BM-20 and BM-22 of the BM series balances. Assembled view Density pan Thermometer...
  • Page 11: Assembling The Kit: Gr Series

    5.2. Assembling the Kit: GR Series Assembled view Density pan Thermometer Thermometer clamp Density pan stand Beaker Beaker stand Balance weights (1 small, 1 large) Weighing pan Remove the weighing pan and breeze break from Breeze break the balance. Place the density pan stand on the balance. Place one small balance weight and one large balance weight on the density pan stand.
  • Page 12: Assembling The Kit: Hr Series

    5.3. Assembling the Kit: HR Series Assembled view Density pan Thermometer Thermometer clamp Density pan stand Beaker Beaker stand Balance weights (1 small, 1 large) Remove the weighing pan and breeze break from Weighing pan the balance. Breeze break Place the density pan stand on the balance. Place one small balance weight and one large balance weight on the density pan stand.
  • Page 13: Assembling The Kit: Ha Series

    5.4. Assembling the Kit: HA Series Note: Do not use the front door to open or close the balance. Assembled view Density pan Thermometer Thermometer clamp Density pan stand Beaker Beaker stand Balance weights (1 small, only for HA-202M) Weighing pan Remove the weighing pan, balance weight, pan Breeze break ring Balance weight...
  • Page 14: Measuring The Density Of A Solid

    5.5. Measuring the Density of a Solid The density of a solid is obtained by averaging the measured values. Start the measurement when water temperature becomes stable. Example display: BM Press the RE-ZERO key to set the displayed value to zero. Place the sample on the upper pan and record its weight in air (A).
  • Page 15 Use the following equations to obtain the density. • Three significant digits • Four or more significant digits ρ ρ ρ ρ – d) + d | B | | B | ρ : Density of sample (g/cm A : Weight in air B : Weight in water ρ...
  • Page 16: Measuring The Density Of A Liquid

    MEASURING THE DENSITY OF A LIQUID Assemble the kit as described in the procedure below. 6.1. Assembling the Kit: Assembled view Thermometer Float hook Thermometer clamp Wire Float Beaker Density pan stand Beaker stand Balance weight (depends on the balance model) For the procedure up to the setting of the The volume of the beaker stand, refer to the assembly procedure...
  • Page 17: Measuring The Density Of A Liquid

    6.2. Measuring the Density of a Liquid Use the following procedure to obtain the density of a liquid. With the float hanging, press the RE-ZERO key to set the displayed value to zero. Example display: BM Pour the liquid of which you want to measure the density into the beaker.
  • Page 18: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS Questions Answers Use a liquid that has a lower density than water and I’d like to measure the density of a resin does not dissolve the sample, such as methanol pellet or sheet, which floats in water. Is it (density 0.798) or kerosene (density 0.80).
  • Page 20 3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013 JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-6148 A&D ENGINEERING, INC. 1756 Automation Parkway, San Jose, California 95131 U.S.A. Telephone: [1] (408) 263-5333 Fax: [1] (408)263-0119 A&D INSTRUMENTS LIMITED <UK Office> Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485...
