To Stop a Timer Programme Which Has Already
Started
Press STOP/EJECT on the VCR.
Note: STOP / on the remote control will not function in the
L
Timer Recording mode.
To Correct Timer Programmes
If you want to correct an automatic timer after you finished
setting programme,
1) Repeat steps 1) to 3) in the "Timer Recording" section.
2) Select the setting you want to change using
REW / .
s
3) Enter the correct numbers using
then press F.FWD / .
B
4) Press MENU to exit.
5) Press FUNCTION to return to timer standby mode.
To Cancel or Check the Start/End Time
1) Repeat steps 1) to 2) in the "Timer Recording".
2) Select a programme number you want to check using
PLAY / or STOP / . The details of selected programme
K L
appears on the TV screen. You may cancel the entire
programme by pressing REW
3) Press MENU to exit.
Avoid Overlap of TIMER Programmes...
A timer programme does not work while another programme
is under execution.
Programme 1
Programme 2
Programme 3
9:00
Hint for Timer Recording
• If there is a power failure or if the VCR is unplugged for
more than 30 seconds, the clock setting and all timer
settings will be lost.
• If the tape runs out before the end time, the VCR will
switch to the Stop mode immediately, eject the tape and the
VCR power will be turned off. The TIMER indicator will
flash.
• If a tape is not in the VCR, Timer Recording cannot be
performed and the TIMER indicator flashes. If an erase-
prevention tab of the tape is missing, the tape will be
ejected and the TIMER indicator will flash. Please insert a
recordable tape.
• When all the Timer Recordings are completed, the TIMER
indicator also flashes. To play or eject the recorded tape,
first, and then press
press FUNCTION
To rewind the tape to the beginning of the recorded
AUTO RETURN
programmes, press
• The TV that is connected to your VCR may be turned on
or off when the VCR is in the Timer Recording mode.
• The VCR will only perform a Timer Recording after it has
been placed into timer standby mode.
Auto Return
Using the AUTO RETURN Button
When all the Timer Recordings are completed (TIMER
indicator flashes), press AUTO RETURN
VCR will rewind to the beginning of the recorded
programme(s).
F.FWD / or
B
PLAY / or STOP / ,
K L
/ .
s
10:00 11:00
PLAY / or EJECT .
K A
on the VCR.
on the VCR first. The
12
Note: If there are any remaining programmes, press
FUNCTION to turn on the VCR and then press
AUTO RETURN . In this case, if you press any other
button once and then press
AUTO RETURN will not be carried out.
Using the VCR Menu
If there are any remaining programmes including Daily,
Everyday, & Weekly, AUTO RETURN will not operate.
1) Press MENU
.
2) Press PLAY STOP
/ or / repeatedly to point to
K L
F.FWD
"SET UP", then press
3) Press PLAY STOP
/ or / to point to
K L
"AUTO RETURN", then press
[ON] will appear next to "AUTO RETURN".
4) Press MENU
.
Watch the Recorded Timer Programme
FUNCTION
Press to turn on the VCR, then press
Parental Lock
Parental Lock prevents use of the VCR by making the VCR
feature buttons on the VCR and the remote control
inoperative.
• The FUNCTION indicator on the VCR comes on.
1) Press and hold down FUNCTION
5 seconds until the TIMER, REC and TAPE IN
indicators begin flash. The Parental Lock is activated.
When you want to cancel it, press and hold
the remote control again for 5 seconds.
When Parental Lock is activated:
• You may insert a tape. However, the VCR power will
remain off.
EJECT
• You may press to remove the tape (unless a Timer
A
Recording is programmed or has finished).
• Timer Recording will take place as scheduled, even if
Parental Lock is activated. "P.L." will appear steadily on the
TV screen during the Timer Recording.
PDC (Programme Delivery Control)
Operation for 31B-254/31B-454 only
The Programme Delivery Control (PDC) is a very convenient
system which assures that the TV programmes you have
programmed for Timer Recording, will be recorded exactly
from beginning to end, even if the actual broadcasting time
differs from the scheduled time due to delayed start or
extension of the programme duration. Also, if a programme is
interrupted and, for example, some special news is broadcast,
the recording will also be interrupted automatically and
resumed when the programme continues.
When the PDC signal drop out because the broadcast signal is
weak, or when a broadcasting station does not transmit a
regular PDC signal, the Timer Recording will be performed in
the normal mode (without PDC) even if it was programmed
for PDC. When the starting time of the PDC Timer
Recording is from 0:00 to 3:59 on a given day, the PDC
function operates from 20:00 on the previous day to 4:00 on
the following day. When the starting time of the PDC Timer
Recording is from 4:00 to 23:59 on the given day, the PDC
function operates from 0:00 on the day to 4:00 on the
following day. This means that if the relevant programme is
broadcasted within this period, it will be recorded correctly. If
AUTO RETURN ,
/ .
B
F.FWD
/ .
B
PLAY
/ .
K
on the remote control for
FUNCTION on
EN
