Directed Audio 2002 Directed Woofer Installation Manual

WOOFER
PHYSICAL
DIMENSIONS
PART MODEL
NUMBER NUMBER INCHES
21084 1084 8.06
21088 1088 8.06
21104 1104 10.06
21108 1108 10.06
21124 1124 12.06
21128 1128 12.06
22084 2084 8.06
22088 2088 8.06
22104 old 2104 10.06
22104 2104 10.55
22108 old 2108 10.06
22108 2108 10.55
22124 old 2124 12.06
22124 2124 12.36
22128 old 2128 12.06
22128 2128 12.36
22154 old 2154 15.00
22154 2154 15.16
22158 old 2158 15.00
22158 2158 15.16
23104 old 3104 10.60
23104 3104 10.70
23108 old 3108 10.60
23108 3108 10.70
23124 old 3124 12.40
23124 3124 12.60
23128 old 3128 12.40
23128 3128 12.60
24104 4104 10.60
24108 4108 10.60
24124 4124 12.40
24128 4128 12.40
24154 4154 15.20
24158 4158 15.20
25108 5108 10.56
25128 5128 12.50
25158 5158 15.50
26102 10.2 10.70
26122 12.2 12.60
26152 15.2 15.90
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
NOTE: MEASUREMENT "A" INCLUDES GRILL FOR SPEAKERS WITH GRILLS.
MEASUREMENT "C & D" SHOULD BE INCREASED BY AT LEAST 1/2" FOR ALL SPEAKERS WITH VENTS.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved.
A B C
INCHES
INCHES
7.20 3.40
7.20 3.40
9.00 4.20
9.00 4.20
11.00 4.75
11.00 4.75
7.20 3.88
7.20 3.88
9.00 4.75
9.00 4.60
9.00 4.75
9.00 4.60
11.00 5.25
11.25 5.67
11.00 5.25
11.25 5.67
13.75 6.50
14.00 6.60
13.75 6.50
14.00 6.60
9.10 4.88
9.10 5.50
9.10 4.88
6.10 5.50
11.00 5.20
11.00 6.20
11.00 5.20
11.00 6.20
9.10 5.20
9.10 5.20
11.00 5.75
11.00 5.75
13.80 6.20
13.80 6.20
9.25 5.20
11.25 6.00
14.13 7.00
9.10 5.50
11.00 6.20
12.60 7.10
D AVERAGE
REAR
VENT
INCHES DISPLACEMENT
4.00 Y 0.04 CU. FT.
4.00 Y 0.04 CU. FT.
4.50 Y 0.06 CU. FT.
4.50 Y 0.06 CU. FT.
5.25 Y 0.08 CU. FT.
5.25 Y 0.08 CU. FT.
4.25 Y 0.04 CU. FT.
4.25 Y 0.04 CU. FT.
5.13 Y 0.06 CU. FT.
5.00 Y 0.06 CU. FT.
5.13 Y 0.06 CU. FT.
5.00 Y 0.06 CU. FT.
5.88 Y 0.08 CU. FT.
6.10 Y 0.08 CU. FT.
5.88 Y 0.08 CU. FT.
6.10 Y 0.08 CU. FT.
7.13 Y 0.12 CU. FT.
7.15 Y 0.12 CU. FT.
7.13 Y 0.12 CU. FT.
7.15 Y 0.12 CU. FT.
5.25 Y 0.06 CU. FT.
6.20 Y 0.08 CU. FT.
5.25 Y 0.06 CU. FT.
6.20 Y 0.08 CU. FT.
5.60 Y 0.08 CU. FT.
6.90 Y 0.11 CU. FT.
5.60 Y 0.08 CU. FT.
6.90 Y 0.11 CU. FT.
5.60 Y 0.07 CU. FT.
5.60 Y 0.07 CU. FT.
6.20 Y 0.09 CU. FT.
6.20 Y 0.09 CU. FT.
6.50 Y 0.1 CU. FT.
6.50 Y 0.1 CU. FT.
5.81 Y 0.12 CU. FT.
6.50 Y 0.21 CU. FT.
7.75 Y 0.36 CU. FT.
6.20 Y 0.08 CU. FT.
6.90 Y 0.11 CU. FT.
7.80 Y 0.178 CU. FT.
SIZE
GRILL
INCHES Y/N
8 N
8 N
10 N
10 N
12 N
12 N
8 N
8 N
10 N
10 N
10 N
10 N
12 N
12 N
12 N
12 N
15 N
15 N
15 N
15 N
10 N
10 N
10 N
10 N
12 N
12 N
12 N
12 N
10 N
10 N
12 N
12 N
15 N
15 N
10 N
12 N
15 N
10 N
12 N
15 N
