Directed Audio RX10D4 Specifications

Model Number
Part Number
Thiele/Small Parameters
Fs (free-air resonance)
Vas (equivalent compliance)
Vas (equivalent compliance)
Qms (Q, mechanical)
Qes (Q, electrical)
Qts (total driver Q)
Re (DC resistance)
Z (nominal impedance)
Le (inductance)
Efficiency (2.83v/1M)
Xmax (one way linear excursion)
Xmax (one way linear excursion)
Pe (continuous power handling)**
Peak power handling (music)*
Mms (total moving mass)
Cms (mechanical compliance)
Bl (motor strength)
Sd (effective radiating area)
Sd (effective radiating area)
Frequency range
Energy Bandwidth Product (EBP)
Driver Physical Dimension
Speaker Displacement
Mounting hole diameter
Mounting depth
Basket diameter
Recommended Enclosures
Typical sealed enclosure
SPL sealed enclosure*
Low Qtc Sealed Enclosure (cu. ft.)**
Vented enclosure (cu. ft.)***
Port tuning frequency
Port diameter (inside, in.)
Equivalent square port
Port length
Enclosure Details
1. Parameters listed are for conventional applications only, further assist please call Tech Audio Support 1-800-876-0800 ext. 2032.
2. Volumes given are NET Box volumes, speaker and port displacement are NOT calculated into the volume of the enclosure, you will need to add these volumes to calculate
GROSS volume for the enclosure.
3. The approximate volume of air displaced by the port can be calculated by using the square port area (H x W) times the port length and then divide by 1728 to get cubic feet.
4. Please call Tech Audio Support 1-800-876-0800 ext. 2032.
* SPL usage only! Not rated for continuous use at this level.
** For SQ (sound quality applications) amps should be between Pe and Peak power ratings.
*** Subsonic filters should always be used and adjusted specifically for vented box designs.
Specifications subject to change without notice
© 2005 Directed Electronics—all rights reserved
Specifications
RX10D4
22220
26.94 Hz
1.92 cu ft
54.45 L
8.15
0.52
0.49
6.2 Ohms
8 Ohms
2.38 mH
85.0dB
0.39"
10 mm
250 Watts
500 Watts
94.83 gms
338 mm/N
13.81 Tesla-M
323.65 sq cm
50.16 sq in
30 Hz–2.5 kHz
52
0.044 cu ft
8.75"
4.75"
10.66"
0.5 cu ft
0.4 cu ft
0.66 cu ft
0.66 cu ft
40 Hz
3.00"
2.68"x2.68"
18.00"
RX12D4
22225
30.03 Hz
2.60 cu ft
73.69 L
8.76
0.51
0.48
6.4 Ohms
8 Ohms
2.04 mH
87.7dB
0.39"
10 mm
250 Watts
500 Watts
121.00 gms
210 mm/N
17.74 Tesla-M
498.76 sq cm
77.30 sq in
30 Hz–2.5 kHz
59
0.071 cu ft
11.00"
5.66"
12.40"
0.7 cu ft
0.5 cu ft
1.00 cu ft
1.00 cu ft
40 Hz
4.00"
3.50"x3.50"
18.00"
G22220.25 12-05
