T
ECHNICAL
General
Standards
Protocol
Data Transfer
Rate
Topology
Network Cables
Number of
Ports

Physical and Environmental

AC inputs
Power
Consumption
Temperature
Humidity
Dimensions
EMI:
Safety
S
PECIFICATIONS
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.1p Compliance
CSMA/CD
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
Star
10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568 100-ohm STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568 100-ohm STP
24 x 10/100Mbps Auto-MDI ports
100 to 240 VAC, 50 or 60 Hz internal universal power supply
7.9 watts. (max.)
Operating: 0° ~ 40° C (32º to 104º F), Storage: -10° ~ 70° C
(14º to 158º F)
Operating: 10% ~ 90%, Storage: 5% ~ 90%
Width: 11.02 in. (280mm)
Depth: 7.09 in. (180mm)
Height: 1.73 in. (44mm)
FCC Class A, CE Mark Class A, VCCI Class A
CUL
