Features of the FOUR.1 :
• Stereo graphic equalization
• Para-BASS low frequency controls
• Pre-amp gain of 20dB
• Line driver: 13 volts peak output
• Balanced differential inputs and outputs
• High-headroom PWM switching power supply
• Main and auxiliary switchable inputs
• Switchable backlighting color (amber/green)
• Master volume and fader control
• Selectable ground isolation
• Optimum voltage LED
2
®
Owner's Enjoyment Manual
QUICK INSTALLATION INFO
For those of you who are short on time and brimming
with confidence, or caffeine for that matter, refer to pages 10
and 11 (Figures 6, 7, & 8). As a matter of reference the FOUR.1i
is shipped in the following configuration:
Shipped
Illumination Green
Inputs Balanced
Outputs Unbalanced
Ground Isolation Isolated
Input Gain 0dB
It is important to know that we recommend that you
allow your authorized AudioControl dealer to install your
FOUR.1i. When they install your FOUR.1i, we will warranty
your FOUR.1i for an unbelievable 5 years parts and labor.
Should you opt to install the FOUR.1i on your own, the
warranty is for 1 year.
Option Page #
Amber 7
Unbalanced 6
Balanced 7
200ohm or
Ground 7
0dB to +20dB 11
