MOUNTING METHOD
METHODE DE MONTAGE
WIRING DIAGRAM
DIAGRAMME DE CABLAGE
Main unit
Unite principal
Fiberglass panel
Panneau de fibre de verre
Speaker
Haut-parleur
Grille
Mounting screw (4)
Gril
Vis de Montage (4)
Speed nut (4)
Ecrou de vitesse (4)
"ATTENTION"
Speaker edge is very sharp.
Le bord de l'enciente
est tres tranchant.
Speaker
Haut-parleur
L
R
Part No. CM16-011205
