F u j i t s u C o m p u t e r S y s t e m s C o r p o r a t i o n
Tablet Mode Bump Case
User's Guide
I N S T R U C T I O N S
These instructions provide details on using your new bump case.
This case is designed for use with your LifeBook notebook when it is
in tablet mode (i.e., with the display facing out). The bump case
provides added protection when transporting, using, or storing the
notebook.
We strongly recommend that you read these instructions prior to
using the bump case with your computer.
Pen holder
Port/Slot Access
D-ring
Figure 1. Bump case - Front
D-ring
External monitor/LAN
adapter cable access

Advertisement

   Related Manuals for Fujitsu Convertible Bump Case none

   Summary of Contents for Fujitsu Convertible Bump Case none

  • Page 1

    F u j i t s u C o m p u t e r S y s t e m s C o r p o r a t i o n Tablet Mode Bump Case User’s Guide I N S T R U C T I O N S These instructions provide details on using your new bump case.

  • Page 2

    Installing the notebook Prior to installing the notebook into the bump case, remove the pen. Once the system is installed, you will not be able to remove the pen. Store the pen in the pen holder. (Figure 1) To install your notebook into the bump case: Be sure your notebook is in tablet mode (i.e., with the display facing out).

  • Page 3

    Battery Figure 3. Inserting notebook into bump case (front) Figure 4. Inserting notebook into bump case (rear) Attaching a Shoulder Strap At the ends of the bottom of the case are two D-rings to which you can attach the shoulder strap. To secure the shoulder strap, attach the strap clips to two of the D-rings.

  • Page 4

    front of you and it will be in the correct orientation. Since the system hangs down “head first”, however, always be sure the Velcro flap is securely fastened when the system is installed. Caring for the bump case The bump case is made of rugged materials, and is designed to withstand daily use.
