Getting Started
Adding memory (optional)
14 Firmly press the memory module into the memory slot's
socket at approximately a 30-degree angle (to the
horizontal surface of the computer).
(Sample Illustration) Inserting the memory module into the socket
15 Once the module's connector is fully inserted into the
socket, press downward on the top edge of the module
to seat the module into the latches at the sides of the
socket. These latches should "snap" into place securely
with the corresponding cutouts in the side of the
module. If the latches and cutouts do not line up
correctly, repeat steps 14-15.
latch
(Sample Illustration) Pressing down on the memory module
Do not force the memory module into position. The
memory module should be completely inserted into the
socket and level when secured in place.
latch
